2 COMMUNICATION AND FUNCTIONING MODES

Name

Functioning mode /

Serial protocol

HMI name

2.1 Communication protocols Modbus RTU and SCMBus

Modbus RTU, SCMBus, and fast SCMBus communication protocols are accessible through AUX, USB. Modbus RTU or
Profibus only depending on version on DB9 connection.
The protocol can be changed via the « Functioning mode/ serial protocol » register (see below).
00
01
11
Note: To be applied, any modification of this setting must be followed by an EEPROM back up and device reboots
(hardware or software).
2.2 Functioning mode
The « Functioning mode/ serial protocol » register offers the possibility to change the eNod4 application according to
the following list:
bits
b b
1 0
eNod4-T
00 Transmitter
01 /
10 /
Note: To be applied, any modification of this setting must be followed by an EEPROM back up and device reboots
(hardware or software).
2.3 HMI name
The "HMI name" is a string of 4 characters freely usable to identify the node on any HMI connected to eNod.
EtherNet/IP
Modbus Class/
address Attribute
(hex/dec)
0x003E 0x64/10
0x0034 0x64/21
bits b9b8
eNod4-C
Transmitter
Checkweigher
transmitter on request
/
User manual SCAIME:
Profinet Profinet
Record cyclic Req
Index Code
R:0x02C2
0x008C
W:0x02C3
/
0x00E0
Protocol
SCMBus
Modbus RTU
Fast SCMBus
Functioning mode
eNod4-D
Transmitter
Dosing by filling
Dosing by unfilling
8/108
NU-soft-eNod4B-ETH-E-0716_236709-C.doc
EtherCAT
index/sub- Type
index
0x2000 / 0x00 Uint
0x3701 / 0x00 String
eNod4-F eNod4-B
Transmitter Transmitter
Dosing Belt scale
/ Belt weigh feeder
Access
RW
RW
