How to Install
2.
Connect terminals 18, 27 and 37 to +24 V
(terminal 12/13)
Default settings:
18 = start
27 = coast inverse
Figure 3.23 Example of Basic Wiring
MG34M422
Operating Instructions
Danfoss A/S © Rev. 2013-07-03 All rights reserved.
3
3
23
