Parameter Descriptions
13-52 SL Controller Action
Array [20]
Option: Function:
[34] Set digital out Any output with SL output Cwill be low.
C low
[35] Set digital out Any output with SL output D will be low.
D low
[36] Set digital out Any output with SL output E will be low.
E low
[37] Set digital out Any output with SL output F will be low.
F low
[38] Set digital out Any output with SL output A will be high.
A high
[39] Set digital out Any output with SL output B will be high.
B high
[40] Set digital out Any output with SL output C will be high.
C high
[41] Set digital out Any output with SL output D will be high.
D high
[42] Set digital out Any output with SL output E will be high.
E high
[43] Set digital out Any output with SL output Fwill be high.
F high
[60] Reset Counter Resets Counter A to zero.
A
[61] Reset Counter Resets Counter B to zero.
B
[70] Start timer 3 Start Timer 3, see parameter 13-20 SL
Controller Timer for further description.
[71] Start timer 4 Start Timer 4, see parameter 13-20 SL
Controller Timer for further description.
[72] Start timer 5 Start Timer 5, see parameter 13-20 SL
Controller Timer for further description.
[73] Start timer 6 Start Timer 6, see parameter 13-20 SL
Controller Timer for further description.
[74] Start timer 7 Start Timer 7, see parameter 13-20 SL
Controller Timer for further description.
