- Page 1 Installation and User Manual...
-
Page 2: Table Of Contents
To Delete A Zone Timer QZW-100 QZB-100 To Add A Second Zone Timer Battery Power Indicator Frequently Asked Questions Please read this manual carefully and keep it for future reference. For more details, contact ActronAir on 1800 119 229. Specifications... -
Page 3: Zone Control/Remote Sensor Installation
Zone Control / Remote Sensor Installation Dining Power Supply Options (applicable for both zone controller and remote sensor) 24.0 C Zone OFF AC OFF AAA Battery Supply Location • ENSURE that the zone device (zone controller or remote sensor) distance from wall controller (master or secondary) is within the recommended RF range of 30m. - Page 4 Run a green Cat5E cable through a 25mm diameter hole in the wall. 43mm Plug in RJ45 connector and secure the controller in the control bracket. 43mm Available ActronAir Cat5E green cable: P.N. 4070-027 7 metres P.N. 4070-031 20 metres Zone controller or...
- Page 5 Cable Installation Maximum Cable Length 8 Zone Module Zone Power Cable ITEM (see figure on previous page) DESCRIPTION MAXIMUM CABLE LENGTH Cat5E Spec Cables with RJ45 Connectors - Grey Colour 1 to 2 and 1 to 3 8-zone module to 3-way cable joiner (P.N. 4070-012) 0.175m 1 to 9 8-zone module to zone controller...
-
Page 6: Pairing A Zone Controller
