Tektronix 2213 Instruction Manual page 222

Fig. &
Index Tektronix
Serial/Model No.
Part No. Eff
No.
2-72
-73 213-0882-00
-74 210-0457-00
-75
-76 344-0154-03
-77 342-0582-00 B010100 B020099
342-0582-01 B020100
-78
343-1025-00
386-1556-00 B010100 B015919X
361-0122-00 XB015920
211-0304-00 B010100 B015919
211-0305-00 B015920
REV OCT 1982
Dscont Qty 1 2 3 4 5
1 CRT BOARD ASSY:CURRENT LIMIT(SEE A19 REPL)
1 SCREW,TAPPING:6-32 X 0.437 TYPE C
1 NUT,PL,ASSEM WA:6-32 X 0.312,STL CD PL
4 . TERM.QIK DISC:CRT BD MT.O.ll X 0.02
. (SEE A19P801,802,803,804 REPL)
-
2
. CLIP,ELECTRICAL:FUSE,CRT BD MT
1
. INSULATOR,PLATE:TRANSISTOR,CERAMIC
1 . INSULATOR,PLATE:TRANSISTOR,CERAMIC
1 . RETAINER,XSTR:
2 SUPPORT,CRT BD:0.215 H,ACETAL
1 SPACER,SLEEVE:0.125 L X 0.12 ID BRS
1 SCREW,MACHINE:4-40 X 0.312.PNH
1 SCREW, MACHINE:4-40 X 0.437,PNH
Replaceable Mechanical Parts— 221 3 Service
Name Description
&
(ATTACHING PARTS)
(ATTACHING PARTS)
Mfr
Code Mfr Part Number
01536 OBD
83385 OBD
344-0154-03
80009
342-0582-00
80009
80009 342-0582-01
80009 343-1025-00
80009 386-1556-00
80009 361-0122-00
01536 OBD
01536 OBD
1 0 -7
