Kit Contents

• One (1) eZ80
• Four (4) AA batteries
• One (1) ZPAK II Debug Interface Module (includes TIM)
• One (1) 40-connector ribbon cable
• One (1) DB9-DB9 Serial I/O Cable
• One (1) ID10 to DB9 cable
• One (1) Ethernet Hub
• One (1) Ethernet Hub User Manual
• Two (2) 7.5V AC Power supplies for Ethernet hub (one international)
• Two (2) 5V AC Power supplies with adapters
• One (1) CDROM with ZDS II software, sample projects, and documentation
• Three (3) Cat-5 Patch Cables
Note:

Introduction

The eZ80
conducting training programs and demonstrations using a number of ZiLOG
microcontroller and microprocessor devices. A ZiLOG eZ80
module plugs into this platform.
Figure 1 shows the top view of the eZ80

Figure 1. The eZ80

User Manual
®
Sales Demonstration Platform with LCD Display and module
®
The eZ80 Sales Demonstration Platform works with the eZ80L92,
eZ80F91, and eZ80F92 modules. For simplicity, this document refers to
the eZ80L92 module. Instructions apply to all three modules, however.
®
Sales Demonstration Platform provides a flexible, portable platform for
®
Sales Demonstration Platform, Top View
UM015201-0603
ZiLOG Development Platforms
®
eZ80 Sales Demonstration Platform
®
processor-equipped
®
Sales Demonstration Platform.
1
