SPECIFICATIONS

Ethernet Connections
SFP 1000 Base-FX
•
SFP 100 Base –FX
•
SFP 10/100/1000 Copper (SGMII)
•
10/100/1000BaseT (Fixed Copper Ports)
•
Auto Negotiation
•
Auto-Cross
•
Flow Control
•
Up to 10,240 MTU
•
Full Line-Rate Forwarding
•
Power
DC Terminal
DC Jack
Double-USB Power
Cable
AC Wall Adapter
Operating Temperature
-40 to +85 °C (-40 to +185 °F) - DC configuration
-10 to +50 °C (+14 to +122 °F) - with AC wall adapter
Storage Temperature
-55 to +125 °C (-67 to +257 °F)
Humidity
5 to 95% (non-condensing); 0 to 10000 ft. altitude
Dimensions
2H x 9.7W x 9.7D cm (0.79H x 3.82W x 3.82D in)
Current Draw
1.5A @ room temperature with data and copper SFPs
1.1A @ room temperature with fiber SFPs
48 VDC, Telco (42.5 to 56.5 VDC with 10mSec transients to
75 VDC)
5 VDC - 24 VDC
Spec 500mA
NOTE: the laptop or PC USB ports must be 2.0 or greater to provide
sufficient power to the unit.
Input: 100 to 240 ±10% VAC
Output: 5 VDC, 2A max.
