B+B SmartWorx IE-MiniFiberLinX-II Series Quick Start Manual

6

Troubleshooting

SNMP Questions
To manage the product, assign an IP address and subnet
mask.
Which port have you assigned to use for management
(SNMP)?
Do you have SNMP services from the WIN CD installed?
iView²
The IE-MiniFiberLinX-II is supported by the iView²
Webserver version.
Check Type of Cable Used
A Cat 5 Ethernet cable is required for the RJ-45 ports.
Make sure that the pins are not pulled out of the
connector's casing, which will cause damage to the
device's copper ports.
PING Test
A PING test can be performed to test connectivity of the
device - either on the copper port or the fiber port.
To perform a PING test, Port 3 must be set to "enable" for
SNMP.
Resources
For optimal performance of the device, make sure to
download the latest version of software and firmware for
the device. These are available on the B+B SmartWorx
website.
For information about product specifications, please refer to
the datasheet.
For information about warranty, please refer to the the
website.
Document Number:
IE-MiniFiberLinX-II_Telco-LastGasp_56-85722-01_R2_3217qsg
Recommended Accessories
iView Network
2
Management Software
-Free download
Ethernet Cables
- Sold separately
1-888-948-2248 | Europe: +353 91 792444
advantech-bb.com
707 Dayton Road | PO Box 1040 | Ottawa, IL 61350
Phone: 815-433-5100 | Fax: 815-433-5109
www.advantech-bb.com | E-mail: support@advantech-bb.com

QUICK START

GUIDE
IE-MiniFiberLinX-II Series
Compact Optical Demarcation Device
with Telco/LastGasp
Before you begin, be
sure you have the following:
+ IE-MiniFiberLinX-II
+ 100/240V AC input, 5V power adapter
Power Supply (included)
+ Console port mini-jack adapter (included)
www.advantech-bb.com
Fast and easy on the web:
