ACCOUNTS

The three levels for CLI or Telnet account access:
User View status, change own password, and reboot.
Operator
All User privileges mentioned above, plus ability to change settings.
Administrator Operator privileges as above, plus ability to add / delete
accounts and reinitialize unit to default settings (cleandb).

VLAN CONFIGURATION

The ports can be assigned as a Trunk or Access port. Once you assign the type of port,
then you can enter a VID of your choice.

TRUNK PORT VS ACCESS PORT

A Trunk port allows multiple VLANs to pass between two switches.
An Access Port allows one VLAN ID, assigned a VLAN ID as well as Priority.
When configuring a trunk port, an Ethertype can be user-defined (a trunk port is also
defined as a provider port, based on 802.1ad). If an Ethertype value comes in a trunk port
and is different than the user-defined Ethertype, it will be treated as an unrecognized LAN
tagged frame. If configuring the port as an access port, enter a VLAN ID between 1 and
4,094. Possible priority settings are 0 (lowest priority) through 7 (highest priority).
