Basic Device Configuration Using The Cli - B+B SmartWorx IE-MultiWay User Manual

BASIC DEVICE CONFIGURATION USING THE CLI

After running an initial self test, the screen will display the following message:
Press Enter for Device Configuration.
Press Enter to open the main configuration screen. This screen allows the
user to set the IP address and destination IP address for traps with the
community string, read/write access, and password as usual.
Saved Values. (These values will be active after reboot)
IP Address - 10.10.10.10
Subnet Mask - 255.255.255.0
Default Gateway - 0.0.0.0
Current Values. (These values are in use now)
IP Address - 10.10.10.10
Subnet Mask - 255.255.255.0
Default Gateway - 0.0.0.0
DHCP is Not Active
