RJ-45 DATA PORT PINOUT

The following table lists the pin configuration
for the RJ-45 data connector.
Pin Signal Name
1000M
1
TXD1+
2
TXD1-
3
RXD2+
4
D3+
5
D3-
6 RXD2-
7
D4+
8 D4-
*NOTE: The MDI/MDIX function will automatically adjust the direction of these signals to match the
connected unit when running 10/100Base-T. 1000Base-T will use all 4 pairs in full duplex mode.

RS-232 SERIAL CONSOLE PORT

The IE-MultiWay includes an RS-232 mini jack for the Console port allowing the
end user to launch a serial session and access a list of commands. The serial
port on the computer/terminal should be set for: 38.4K baud, 8 data bits, 1 stop
bit, no parity, no flow control. The F2 key functions as a Delete key on VT-100
emulators.
The following table lists the pin configuration for the RS-232 3-pin Mini Jack mating
connector for the console serial port.
Pin
Tip
Ring
Sleeve
Signal Direction
10/100M
Out*
Out*
In*
In*
DB9-F Pin#
2
3
5
57
Signal Name
Transmit
Receive
Return
-MultiWay
IE
Pin 1
Direction
Out of Unit
In to Unit
Return
