Troubleshooting
Q. What operating systems are supported?
A. Win XP 32/64 bit, Win 7, Win 8.
Q. Which USB cables can I use?
A. A 3 foot cable is included.Other lengths can
be purchased separately. The maximum range for
USB is 15 ft. We sell USB extenders if you need to
go further than 15 ft.
Document number – 710-11435-00_USOPTL4-xP_4516qsg
Recommended Accessories
MDR-20-24
Power Supply
SMI6-12-V-ST
Power Supply
1-888-948-2248 | Europe: +353 91 792444
advantech-bb.com
707 Dayton Road | PO Box 1040 | Ottawa, IL 61350
Phone: 815-433-5100 | Fax: 815-433-5109
www.advantech-bb.com | E-mail: support@advantech-bb.com
QUICK START
GUIDE
USOPTL4-2P & USOPTL4-4P
2-Port and 4-Port Isolated
USB to RS-422/485 Converters
Before you begin, be
sure you have
the following:
+ USOPTL4-xP
+ One Meter USB Cable
+ CD ROM and Drivers
www.advantech-bb.com
Fast and easy on the web:
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for B+B SmartWorx USOPTL4-2P
Summary of Contents for B+B SmartWorx USOPTL4-2P
-
Page 1: Troubleshooting
Power Supply USB is 15 ft. We sell USB extenders if you need to go further than 15 ft. SMI6-12-V-ST Power Supply USOPTL4-2P & USOPTL4-4P 2-Port and 4-Port Isolated USB to RS-422/485 Converters Before you begin, be sure you have... -
Page 2: Product Overview
4-Wire RS-422/485 Product Overview Set Dip Switches o RS-422 = All DIP Switches OFF Front Rear o RS-485 = DIP 1 ON, DIP 2, 4 and 4 OFF OFF=left ON=right USB Port DIP Switch Position Switch TD always enabled TD only enabled during data (TD 422) transission (TD 485) RD always enabled...
