4 Operational Check Details

4.8 Hardware Monitor Operational Check

4.8.1 CPU and System Temperatures Retrieval

Launch a console window. Execute the temp sample as follows, and confirm that the CPU and system
temperatures can be retrieved. Refer to the Readme file for details about the temp sample.
root@BX-830:~# ./temp 0 0x22
micon: Get CPU temp complete. cmd [0xa4h], dat [39.96]
micon: Get SYS temp complete. cmd [0xa5h], dat [39.41]

4.8.2 Power-supply Voltage Retrieval

Launch a console window. Execute the voltage sample as follows, and confirm that the system's power-
supply voltage can be retrieved. Refer to the Readme file for details about the voltage sample.
root@BX-830:~# ./voltage 0 0x22
Vcore : 0.928 V
+5VSB : 4.992 V
VBAT : 3.104 V
+3.3VSB : 3.312 V
+3.3VCC : 3.315 V
+5V : 5.025 V
+1.8V : 1.805 V
