Radio control model
R/C Flugmodell
INSTRUCTION MANUAL
MONTAGEANLEITUNG
Designed for brushless electric motors
Entwickelt für Brushless Elektro Motoren
VOLKSPLANE
U.S VERSION: VQA133US
SPECIFICATIONS
Wingspan
Length
Electric Motor
Radio
5 Channel / 4 Servos
TECHNISCHE DATEN
Spannweite
Lange
Elektroantrieb
(siehe nächste Seite)
Fernsteuerung
5 Kanal / 4 Servos
WARNING! This radio controlled model is NOT a toy. If modified or flown carelessly it could go out of controll and
cause serious human injury or property damage. Before flying your airplane, ensure the air field is spacious enough.
Always fly it outdoors in safe areas and seek professional advice if you are unexperienced.
ACHTUNG! Dieses ferngesteuerte Modell ist KEIN Spielzeug! Es ist für fortgeschrittene Modellflugpiloten bestimmt,
die ausreichende Erfahrung im Umgang mit derartigen Modellen besitzen Bei unsachgemäßer Verwendung kann
hoher Personen- und/oder Sachschaden entstehen. Fragen Sie in einem Modellbauverein in Ihrer Nähe um
professionelle Unterstützung, wenn Sie Hilfe im Bau und Betrieb benötigen. Der Zusammenbau dieses Modells ist
durch die vielen Abbildungen selbsterklärend und ist für fortgeschrittene, erfahrene Modellbauer bestimmt.
SWISS VERSION: VQA134BLUE
62.9in.
46 in.
(See next page)
1600mm
1170mm
SWISS VERSION: VQA134RED
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for VQ Models Volksplane VQA133US
Summary of Contents for VQ Models Volksplane VQA133US
- Page 1 Radio control model R/C Flugmodell INSTRUCTION MANUAL MONTAGEANLEITUNG Designed for brushless electric motors Entwickelt für Brushless Elektro Motoren VOLKSPLANE SWISS VERSION: VQA134RED U.S VERSION: VQA133US SWISS VERSION: VQA134BLUE SPECIFICATIONS Wingspan 62.9in. Length 46 in. Electric Motor (See next page) Radio 5 Channel / 4 Servos TECHNISCHE DATEN Spannweite...
-
Page 2: Conversion Table
REQUIRED FOR OPERATION (Purchase separately) Extension for aileron servo. Motor Control Li-Po Battery, 3700mAh. Minimum 5 channel radio 650-800W Brushless Motor for airplane with 4 servos Cyanoacrylate Glue Sekundenkleber Tool Required/ Empfohlenes Werkzeug ............................................................................................ - Page 3 FUSELAGE - BOTTOM VIEW Cut away only the covering 3x15mm screw ...4 * WARNING: When removing any covering from the airframe, please ensure that you secure the cut edge with CA or similar cement. This will ensure the covering remain tight. 4mm bolt 4mm washer 4x45mm screw...
- Page 4 Cut away only the covering NOTE: cut inside the pencil lines. Trial fit the horizontal stabilizer in place on the Cut away only fuselage. Check the alignment of the horizontal stabilizer by measuring from a fixed point along the covering the center line of the fuselage to the leading edge both sides.
- Page 5 Again, push the vertical stabilizer into the fuselage. Check the alignment with the horizontal stabilizer. Secure the vertical stabilizer in place using the thin CA glue. Securely glue together. If coming off during flight, you lose control of your air plane. Cut away only the covering Thin CA...
- Page 6 3x10mm ..4 ..1 ..2 Without using glue yet, push the rudder and its hinges into the hinge slots in the trailing edge of the vertical stabilizer. When satisfied with the alignment, mark the mounting hole position, where the rudder torque rod meets the rudder with a pencil.
- Page 7 950mm steel wire ..2 Steel clevis ..2 FUSELAGE - BOTTOM VIEW FUSELAGE - TOP VIEW...
- Page 8 Using a aluminum motor mounting as a template, mark the fire-wall where the four holes are to be drilled . Remove the motor and drill a 4mm hole through the fire-wall at each of the four marks marked . 3x15mm ...4 ...4...
- Page 9 Adhesive tape 2x8mm 2x8mm ..6 2x8mm 2x8mm ..4...
- Page 10 2mm connector ...2 Rudder servo Elevator servo Fuselage - Top view Note: The holes for the connector installation are pre-drilled at factory 3mm connector ...4 Cut away only the covering...
-
Page 11: Bottom View
Control horn ..2 2x30mm ...4 Do the same way with other wing half BOTTOM - VIEW Aileron extension cord Aileron pushrod 2mm connector ..2 175mm steel wire ..2 Do the same way with other wing half Steel clevis BOTTOM - VIEW ..2... - Page 12 3x15mm screw ..2 Secure the wing in place using 3x15mm screw. Note: The hole on the surface of the top of the wing is pre-drilledat factory. 2.mm drill bit Aluminum 3x15mm screw tube inside...
- Page 13 3x12mm ..4 3x12mm 3x12mm Note: The holes on the top of the wing are pre-drilled at factory. Wing brace Note: The length of the wing brace can adjust by turn the metal hook. The recommended C.G (Center of Gravity) location for the Volksplane is 89 ~ 91mm Adjust the location of the battery pack as required to achieve this C.G location.
