  • Page 1 Xgig1000 Hardware Guide...
  • Page 3 Xgig1000 Hardware Guide Viavi Solutions 1-844-GO-VIAVI www.viavisolutions.com...
  • Page 4 Copyright/Trademarks © Copyright 2017 Viavi Solutions Inc. All rights reserved. No part of this guide may be reproduced or transmitted, electronically or otherwise, without written permission of the ”).
  • Page 5 In the European Union, all equipment and batteries purchased from Viavi after 2005-08-13 can be returned for disposal at the end of its useful life. Viavi will ensure that all waste equipment and batteries returned are reused, recycled, or disposed of in an environmentally friendly manner, and in compliance with all applicable national and international waste legislation.
  • Page 6 Page iv Xgig1000 Hardware Guide March 2017...

  • Page 7: Table Of Contents

    ..........8 Xgig1000 4 Port 10G/16G Chassis .
  • Page 8 PATH 1: Setting Up the Xgig1000 Chassis in a DHCP Network ....86 PATH 2: Setting Up the Xgig1000 Chassis with a Static IP Address in a Non-DHCP Network .
  • Page 9 ..........133 Restarting the Xgig1000 Chassis with the Backup System Image Using USB System Recovery Drive .
  • Page 10 .........146 Cannot find an Xgig1000 chassis using the discover button in the port selection window .

  • Page 11: About This Guide

    “Purpose and Scope” on page x • “Assumptions” on page x • “What this Guide Contains” on page x • “Safety and Compliance Information” on page xi • “Conventions” on page xii • “Technical Assistance” on page xiv March 2017 Xgig1000 Hardware Guide Page ix...

  • Page 12: Purpose And Scope

    Purpose and Scope Purpose and Scope The purpose of this guide is to help you successfully use the Xgig1000 features and capa- bilities. This guide includes task-based instructions that describe how to install, configure, use, and troubleshoot the Xgig1000. Additionally, this guide provides a complete descrip- tion of Viavi’s warranty, services, and repair information, including terms and conditions of...

  • Page 13: Safety And Compliance Information

    Any discharge greater than this can damage or effectively destroy such a device while going unnoticed by a technician. Common plastics (synthetic insulating materials), clothing, and paper or cardboard are the most common source of static charges. March 2017 Xgig1000 Hardware Guide Page xi...

  • Page 14: Conventions

    This symbol indicates a note that includes important supplemental information or tips related to the main text. This symbol represents a general hazard. It may be associated with either a DANGER, WARNING, or CAUTION message. See Table 3 for more information. Page xii Xgig1000 Hardware Guide March 2017...
  • Page 15 See Table 2 for more information. When applied to software actions, indicates a situation that, if not avoided, could result in loss of data or a disruption of software opera- tion. March 2017 Xgig1000 Hardware Guide Page xiii...

  • Page 16: Technical Assistance

    About This Guide Technical Assistance Technical Assistance If you require technical assistance, call 1-844-GO-VIAVI (1-844-468-4284) or e-mail Techsupport-snt@viavisolutions.com. For the latest TAC information, go to http://www.viavisolutions.com/en/services-and-support/support/technical-assistance. Page xiv Xgig1000 Hardware Guide March 2017...

  • Page 17: Chapter 1 Xgig1000 System Overview

    Xgig1000 System Overview Chapter 1 This chapter provides a general description of the Xgig1000. Topics discussed in this chapter include the following: • “Xgig1000 Systems” on page 2 • “Xgig1000 12G SAS Chassis” on page 2 • “Xgig1000 4 Port 10G/16G Chassis” on page 11 •...

  • Page 18: Xgig1000 Systems

    Troubleshooting information for first generation chassis is located in the appendix. Xgig1000 12G SAS Chassis The Xgig1000 12G SAS is a fixed blade chassis that houses one Xgig 12G SAS blade with 8 ports (four links) that support the Analyzer, Generator, and Jammer functions in Analog Passthrough mode only.
  • Page 19 Chapter 1 Xgig1000 System Overview Xgig1000 12G SAS Chassis Figure 1 Xgig1000 12G SAS Chassis March 2017 Xgig1000 Hardware Guide Page 3...

  • Page 20: Sas System Ports/Connections/Front Panel Reset Button

    3.3V or 5.0V inputs, also active-high. Use 50 ohm cables with these ports. Cascade Ports The Cascade In and Cascade Out ports provide a means of time-synchronizing up to four Xgig, Xgig5000, and/or Xgig1000 chassis. Cascade Ports are used to share domains and send triggers between chassis. Page 4...
  • Page 21 The Clock In port functionality is TBD. This port is reserved for future use. Port Connectors The Xgig1000 has two female mini-SAS HD connectors on the front. One connector is typi- cally used for connection to the target, and the other is used for connection to the host.

  • Page 22: Sas System/Port Indicators

    Chapter 1 Xgig1000 System Overview Xgig1000 12G SAS Chassis • For Xgig 1000 units with the original motherboard (no rear power switch on the back panel), the System LED will become steady yellow when the system has shut- down. This is the indication that you can remove the power cable.
  • Page 23 Status Indicator (for the blade) The Status LED is for the blade within the Xgig1000 chassis. A solid blue LED indicates the blade is ready to be used. A flashing green LED or a red/purple alternating LED indi- cates that firmware is being updated.

  • Page 24: Sas System Specifications

    Chapter 1 Xgig1000 System Overview Xgig1000 12G SAS Chassis Signal/Triggered/Rate Indicators These LEDs are for each port. The meaning of the LEDs is defined in Table Table 4 12G SAS Blade LEDs 12G SAS Blade LEDs for Analyzer Ports Green...
  • Page 25 Chapter 1 Xgig1000 System Overview Xgig1000 12G SAS Chassis Table 5 Physical Specifications Depth 15.25 in. / 38.74 cm. Weight 12.0 lbs. / 5.44 kg Mount 18.84 in. / 47.85 cm Table 6 Power Specifications Power Consumption 375 W Fuse Protection...
  • Page 26 Chapter 1 Xgig1000 System Overview Xgig1000 12G SAS Chassis Table 8 Environmental Specifications Temperature Operational 10 to +40° C (50 to +104° F) −40 to +70° C (−40 to +158° F) Non-operational Humidity Operational Up to 90% humidity (non-condensing) at +40° C Non-operational Up to 95% humidity at +65°...

  • Page 27: Xgig1000 4 Port 10G/16G Chassis

    Xgig1000 4 Port 10G/16G Chassis Xgig1000 4 Port 10G/16G Chassis The Xgig1000 4 Port 10G/16G system is a fixed blade chassis that houses one Xgig 10G/ 16G blade with four ports (two links). The Xgig1000 4 Port 10G/16G system supports the Analyzer, Jammer, and Load Tester functions at 10.3125 Gbps in the 10 Gigabit Ethernet...
  • Page 28 Chapter 1 Xgig1000 System Overview Xgig1000 4 Port 10G/16G Chassis Figure 2 Xgig1000 4 Port 10G/16G Chassis Page 12 Xgig1000 Hardware Guide March 2017...

  • Page 29: Port 10G/16G System Ports/Connections/Front Panel Reset Button

    3.3V or 5.0V inputs, also active-high. Use 50 ohm cables with these ports. Cascade Ports The Cascade In and Cascade Out ports provide a means of time-synchronizing up to four Xgig, Xgig5000, and/or Xgig1000 chassis. Cascade Ports are used to share domains and send triggers between chassis. March 2017...
  • Page 30 Chapter 1 Xgig1000 System Overview Xgig1000 4 Port 10G/16G Chassis Cascade ports use standard RJ-45 connectors and straight through CAT5 cables to connect chassis, but use Viavi proprietary protocol to communicate between cascaded units. USB Ports Standard USB type A connector may be used with any USB 2.0 device. This includes the USB system recovery drive for second generation Xgig1000 chassis.

  • Page 31: Port 10G/16G System/Port Indicators

    Chapter 1 Xgig1000 System Overview Xgig1000 4 Port 10G/16G Chassis If you press and hold the Front Panel Reset button down for six seconds or longer, it forces an abrupt termination and a graceful shutdown may not have completed. •...
  • Page 32 Xgig1000 4 Port 10G/16G Chassis Status Indicator (for the blade) The Status LED is for the blade within the Xgig1000 chassis. A solid blue LED indicates the blade is ready to be used. A flashing green LED or a red/purple alternating LED indi- cates that firmware is being updated.

  • Page 33: Port 10G/16G System Specifications

    Chapter 1 Xgig1000 System Overview Xgig1000 4 Port 10G/16G Chassis Table 9 4 Port 10G/16G Blade LEDs 4 Port 10G/16G Blade LEDs for Jammer Ports Color Blue Color Green Color Orange Locked Not Locked. Indicates that The Jammer the Jammer port port is available.
  • Page 34 Chapter 1 Xgig1000 System Overview Xgig1000 4 Port 10G/16G Chassis Table 11 Power Specifications Input Frequency 50/60 Hz Inrush Current (Peak) 3.5 A @ 100 VAC Table 12 Port Specifications Console Port 9-pin serial port connects to PC (cross over cable only)
  • Page 35 Chapter 1 Xgig1000 System Overview Xgig1000 4 Port 10G/16G Chassis Table 13 Environmental Specifications Vibration Operational Random Vibration 5−500 Hz, 10 minutes per axis, 2.41g (rms) Non-operational Random vibration 5−500 Hz, 10 minutes per axis, 0.3 g (rms) Resonant search, 5−500 Hz swept sine, 1 octave/min.

  • Page 36: Xgig1000 8 Port 10G/16G Chassis

    Xgig1000 8 Port 10G/16G Chassis Xgig1000 8 Port 10G/16G Chassis The Xgig1000 8 Port 10G/16G system is a fixed blade chassis that houses one Xgig 10G/ 16G blade with eight ports (four links). The Xgig1000 8 Port 10G/16G system supports the Analyzer, Jammer, and Load Tester functions at 10.3125 Gbps in the 10 Gigabit Ethernet...
  • Page 37 Chapter 1 Xgig1000 System Overview Xgig1000 8 Port 10G/16G Chassis Figure 3 Xgig1000 8 Port 10G/16G Chassis March 2017 Xgig1000 Hardware Guide Page 21...

  • Page 38: Port 10G/16G System Ports/Connections/Front Panel Reset Button

    3.3V or 5.0V inputs, also active-high. Use 50 ohm cables with these ports. Cascade Ports The Cascade In and Cascade Out ports provide a means of time-synchronizing up to four Xgig, Xgig5000, and/or Xgig1000 chassis. Cascade Ports are used to share domains and send triggers between chassis. Page 22...
  • Page 39 Chapter 1 Xgig1000 System Overview Xgig1000 8 Port 10G/16G Chassis Cascade ports use standard RJ-45 connectors and straight through CAT5 cables to connect chassis, but use Viavi proprietary protocol to communicate between cascaded units. USB Ports Standard USB type A connector may be used with any USB 2.0 device. This includes the USB system recovery drive for second generation Xgig1000 chassis.

  • Page 40: Port 10G/16G System/Port Indicators

    Chapter 1 Xgig1000 System Overview Xgig1000 8 Port 10G/16G Chassis If you press and hold the Front Panel Reset button down for six seconds or longer, it forces an abrupt termination and a graceful shutdown may not have completed. •...
  • Page 41 Xgig1000 8 Port 10G/16G Chassis Status Indicator (for the blade) The Status LED is for the blade within the Xgig1000 chassis. A solid blue LED indicates the blade is ready to be used. A flashing green LED or a red/purple alternating LED indi- cates that firmware is being updated.

  • Page 42: Port 10G/16G System Specifications

    Chapter 1 Xgig1000 System Overview Xgig1000 8 Port 10G/16G Chassis Table 14 8 Port 10G/16G Blade LEDs (Continued) 8 Port 10G/16G Blade LEDs for Jammer Ports Color Blue Color Green Color Orange Locked Not Locked. Indicates that The Jammer the Jammer port port is available.
  • Page 43 Chapter 1 Xgig1000 System Overview Xgig1000 8 Port 10G/16G Chassis Table 16 Power Specifications Input Frequency 50/60 Hz Inrush Current (Peak) 3.5 A @ 100 VAC Table 17 Port Specifications Console Port 9-pin serial port connects to PC (cross over cable only)
  • Page 44 Chapter 1 Xgig1000 System Overview Xgig1000 8 Port 10G/16G Chassis Table 18 Environmental Specifications Vibration Operational Random Vibration 5−500 Hz, 10 minutes per axis, 2.41g (rms) Non-operational Random vibration 5−500 Hz, 10 minutes per axis, 0.3 g (rms) Resonant search, 5−500 Hz swept sine, 1 octave/min.

  • Page 45: Xgig1000 8+2 Port 10G/16G/40G Chassis

    Xgig1000 8+2 Port 10G/16G/40G Chassis Xgig1000 8+2 Port 10G/16G/40G Chassis The Xgig1000 8+2 Port 10G/16G/40G system is a fixed blade chassis that houses one Xgig 10G/16G/40G blade with eight SFP ports (four links) and two QSFP ports (one link). The eight SFP ports support the Analyzer, Jammer, and Load Tester functions at 10.3125 Gbps in the 10 Gigabit Ethernet protocol.
  • Page 46 Chapter 1 Xgig1000 System Overview Xgig1000 8+2 Port 10G/16G/40G Chassis Figure 4 Xgig1000 8+2 Port 10G/16G/40G Chassis Page 30 Xgig1000 Hardware Guide March 2017...

  • Page 47: 8+2 Port 10G/16G/40G System Ports/Connections/Front Panel Reset Button

    3.3V or 5.0V inputs, also active-high. Use 50 ohm cables with these ports. Cascade Ports The Cascade In and Cascade Out ports provide a means of time-synchronizing up to four Xgig, Xgig5000, and/or Xgig1000 chassis. Cascade Ports are used to share domains and send triggers between chassis. March 2017...
  • Page 48 The Clock In port functionality is TBD. This port is reserved for future use. Port Connectors The Xgig1000 has eight female SFP connectors and two QSFP connectors on the front. Front Panel Reset Button To safely shutdown the operating system and power off the chassis, press and hold the Front Panel Reset button for two seconds until the System LED starts blinking yellow.

  • Page 49: 8+2 Port 10G/16G/40G System/Port Indicators

    Chapter 1 Xgig1000 System Overview Xgig1000 8+2 Port 10G/16G/40G Chassis If you press and hold the Front Panel Reset button down for six seconds or longer, it forces an abrupt termination and a graceful shutdown may not have completed. •...
  • Page 50 Xgig1000 8+2 Port 10G/16G/40G Chassis Status Indicator (for the blade) The Status LED is for the blade within the Xgig1000 chassis. A solid blue LED indicates the blade is ready to be used. A flashing green LED or a red/purple alternating LED indi- cates that firmware is being updated.

  • Page 51: 8+2 Port 10G/16G/40G System Specifications

    Chapter 1 Xgig1000 System Overview Xgig1000 8+2 Port 10G/16G/40G Chassis Table 19 8+2 Port 10G/16G/40G Blade LEDs (Continued) 8 Port 10G/16G Blade LEDs for Jammer Ports Color Blue Color Green Color Orange Locked Not Locked. Indicates that The Jammer the Jammer port port is available.
  • Page 52 Chapter 1 Xgig1000 System Overview Xgig1000 8+2 Port 10G/16G/40G Chassis Table 21 Power Specifications Input Frequency 50/60 Hz Inrush Current (Peak) 3.5 A @ 100 VAC Table 22 Port Specifications Console Port 9-pin serial port connects to PC (cross over cable only)
  • Page 53 Chapter 1 Xgig1000 System Overview Xgig1000 8+2 Port 10G/16G/40G Chassis Table 23 Environmental Specifications Vibration Operational Random Vibration 5−500 Hz, 10 minutes per axis, 2.41g (rms) Non-operational Random vibration 5−500 Hz, 10 minutes per axis, 0.3 g (rms) Resonant search, 5−500 Hz swept sine, 1 octave/min.

  • Page 54: Xgig1000 2 Port 10G/40G Chassis

    Xgig1000 2 Port 10G/40G Chassis Xgig1000 2 Port 10G/40G Chassis The Xgig1000 2 Port 10G/40G system is a fixed blade chassis that houses one Xgig 10G/ 40G blade with two QSFP ports (one link). The two QSFP ports support the Analyzer func- tion at 41.2500 Gbps in the 10 Gigabit Ethernet protocol in Analyzer Passthrough only.
  • Page 55 Chapter 1 Xgig1000 System Overview Xgig1000 2 Port 10G/40G Chassis Figure 5 Xgig1000 2 Port 10G/40G Chassis March 2017 Xgig1000 Hardware Guide Page 39...

  • Page 56: Port 10G/40G System Ports/Connections/Front Panel Reset Button

    3.3V or 5.0V inputs, also active-high. Use 50 ohm cables with these ports. Cascade Ports The Cascade In and Cascade Out ports provide a means of time-synchronizing up to four Xgig, Xgig5000, and/or Xgig1000 chassis. Cascade Ports are used to share domains and send triggers between chassis. Page 40...
  • Page 57 The Clock In port functionality is TBD. This port is reserved for future use. Port Connectors The Xgig1000 has two QSFP connectors on the front. These ports support copper and optical cabling. You can use the two 40G QSFP ports as eight 10G SFP ports by using two one-to-four copper or optical QSFP male to SFP female breakout cables.
  • Page 58 Chapter 1 Xgig1000 System Overview Xgig1000 2 Port 10G/40G Chassis Figure 6 Cabling the 40G QSFP Ports For Use As 10G SFP Ports Front Panel Reset Button To safely shutdown the operating system and power off the chassis, press and hold the Front Panel Reset button for two seconds until the System LED starts blinking yellow.

  • Page 59: Port 10G/40G System/Port Indicators

    Chapter 1 Xgig1000 System Overview Xgig1000 2 Port 10G/40G Chassis • For Xgig 1000 units with the original motherboard (no rear power switch on the back panel), holding the Front Panel Reset button for 6 seconds will force the System LED to a steady yellow.
  • Page 60 Xgig1000 2 Port 10G/40G Chassis Status Indicator (for the blade) The Status LED is for the blade within the Xgig1000 chassis. A solid blue LED indicates the blade is ready to be used. A flashing green LED or a red/purple alternating LED indi- cates that firmware is being updated.

  • Page 61: Port 10G/40G System Specifications

    Chapter 1 Xgig1000 System Overview Xgig1000 2 Port 10G/40G Chassis 2 Port 10G/40G System Specifications Table 25 Physical Specifications Height 3.50 in. / 8.89 cm. Width 9.50 in. / 24.13 cm. Depth 15.25 in. / 38.74 cm. Weight 12.00 lbs. / 5.44kg Mount 18.84 in.
  • Page 62 Chapter 1 Xgig1000 System Overview Xgig1000 2 Port 10G/40G Chassis Table 27 Port Specifications Clock Out MCX Connector for Transmit Reference Clock Output, 375 MHz, AC-coupled, Typ. 0.8V peak-peak Port Connectors two QSFPs containing FPGAs QSFPs support optical and copper cables...

  • Page 63: Xgig1000 Pcie Chassis

    Xgig1000 PCIe Chassis Xgig1000 PCIe Chassis The Xgig1000 PCIe system is a fixed blade chassis that houses one Xgig 8GT/s PCIe blade with two CXP ports (16 lanes). The Xgig1000 PCIe system supports the Analyzer function at 2.5, 5.0, and 8.0 GT/s in the PCIe protocol in Analog Passthrough only. This system supports a trace buffer of 32GB upstream and 32GB downstream per port.
  • Page 64 Chapter 1 Xgig1000 System Overview Xgig1000 PCIe Chassis Figure 7 Xgig1000 PCIe Chassis Page 48 Xgig1000 Hardware Guide March 2017...

  • Page 65: Pcie System Ports/Connections/Front Panel Reset Button

    Cascade Ports The Cascade In and Cascade Out ports provide a means of time-synchronizing up to four Xgig, Xgig5000, and/or Xgig1000 chassis. Cascade Ports are used to share domains and send triggers between chassis. Cascade ports use standard RJ-45 connectors and straight through CAT5 cables to connect chassis, but use Viavi proprietary protocol to communicate between cascaded units.
  • Page 66 USB Ports Standard USB type A connector may be used with any USB 2.0 device. This includes the USB system recovery drive for second generation Xgig1000 chassis. 3.0 USB type A connectors may be used with any USB 3.0 device.

  • Page 67: Pcie System/Port Indicators

    Status Indicator (for the blade) The Status LED is for the blade within the Xgig1000 chassis. A solid blue LED indicates the blade is ready to be used. A flashing green LED or a red/purple alternating LED indi- cates that firmware is being updated.
  • Page 68 If you use the Xgig client to update your chassis, the GUI message will indicate that the upgrade is complete even though there may be a subsequent Xgig1000 blade upgrade that could last for 15 more minutes. If this process fails, the Status LED is a steady red.

  • Page 69: Pcie System Specifications

    Chapter 1 Xgig1000 System Overview Xgig1000 PCIe Chassis PCIe System Specifications Table 30 Physical Specifications Height 3.50 in. / 8.89 cm. Width 9.50 in. / 24.13 cm. Depth 15.25 in. / 38.74 cm. Weight 11.70 lbs. / 5.31kg Mount 18.84 in. / 47.85 cm...
  • Page 70 Chapter 1 Xgig1000 System Overview Xgig1000 PCIe Chassis Table 32 Port Specifications Clock Out MCX Connector for Transmit Reference Clock Output, 375 MHz, AC-coupled, Typ. 0.8V peak-peak Port Connectors two x16 PCIe Gen 3 CXP connectors Table 33 Environmental Specifications...

  • Page 71: Xgig1000 4 Port 25G/32G Chassis

    Xgig1000 4 Port 25G/32G Chassis Xgig1000 4 Port 25G/32G Chassis The Xgig1000 4 Port 25G/32G system is a fixed blade chassis that houses one Xgig 25G/32G blade with four SFP ports (two links). The Xgig1000 4 Port 25G/32G system supports: •...
  • Page 72 Chapter 1 Xgig1000 System Overview Xgig1000 4 Port 25G/32G Chassis Figure 8 Xgig1000 4 Port 25G/32G Chassis Page 56 Xgig1000 Hardware Guide March 2017...

  • Page 73: Port 25G/32G System Ports/Connections/Front Panel Reset Button

    Cascade Ports The Cascade In and Cascade Out ports provide a means of time-synchronizing up to four Xgig, Xgig5000, and/or Xgig1000 chassis. Cascade Ports are used to share domains and send triggers between chassis. Cascade ports use standard RJ-45 connectors and straight through CAT5 cables to connect chassis, but use Viavi proprietary protocol to communicate between cascaded units.
  • Page 74 The Clock In port functionality is TBD. This port is reserved for future use. Port Connectors The Xgig1000 4 Port 25G/32G has four female SFP connectors on the front. Front Panel Reset Button To safely shutdown the operating system and power off the chassis, press and hold the Front Panel Reset button for two seconds until the System LED starts blinking yellow.

  • Page 75: Port 25G/32G System/Port Indicators

    Status Indicator (for the blade) The Status LED is for the blade within the Xgig1000 chassis. A solid blue LED indicates the blade is ready to be used. A flashing green LED or a red/purple alternating LED indi- cates that firmware is being updated.
  • Page 76 15 more minutes. If this process fails, the Status LED is a steady red. In order to make sure the blade upgrade process is complete, check the Status LED on the blade, or open the Xgig1000 URL, and select the Status tab. NOTE In the case of a blade upgrade failure, contact the “Technical Assistance”...

  • Page 77: Port 25G/32G System Specifications

    Chapter 1 Xgig1000 System Overview Xgig1000 4 Port 25G/32G Chassis 4 Port 25G/32G System Specifications Table 35 Physical Specifications Height 3.50 in. / 8.89 cm. Width 9.50 in. / 24.13 cm. Depth 15.25 in. / 38.74 cm. Weight 10.50 lbs. / 4.76 kg Mount 18.84 in.
  • Page 78 Chapter 1 Xgig1000 System Overview Xgig1000 4 Port 25G/32G Chassis Table 37 Port Specifications Clock In MCX Connector for Transmit Reference Clock Input 375 MHz AC-coupled, Typ. 0.8V, Max 1.2V peak-peak Clock Out MCX Connector for Transmit Reference Clock Out- 375 MHz AC-coupled, Typ.

  • Page 79: Xgig1000 8 Port 25G/32G Chassis

    Xgig1000 8 Port 25G/32G Chassis Xgig1000 8 Port 25G/32G Chassis The Xgig1000 8 Port 25G/32G system is a fixed blade chassis that houses one Xgig 25G/32G blade with eight SFP ports (four links). The Xgig1000 8 Port 25G/32G system supports: •...
  • Page 80 Chapter 1 Xgig1000 System Overview Xgig1000 8 Port 25G/32G Chassis Figure 9 Xgig1000 8 Port 25G/32G Chassis Page 64 Xgig1000 Hardware Guide March 2017...

  • Page 81: Port 25G/32G System Ports/Connections/Front Panel Reset Button

    Cascade Ports The Cascade In and Cascade Out ports provide a means of time-synchronizing up to four Xgig, Xgig5000, and/or Xgig1000 chassis. Cascade Ports are used to share domains and send triggers between chassis. Cascade ports use standard RJ-45 connectors and straight through CAT5 cables to connect chassis, but use Viavi proprietary protocol to communicate between cascaded units.
  • Page 82 The Clock In port functionality is TBD. This port is reserved for future use. Port Connectors The Xgig1000 8 Port 25G/32G has eight female SFP connectors on the front. Front Panel Reset Button To safely shutdown the operating system and power off the chassis, press and hold the Front Panel Reset button for two seconds until the System LED starts blinking yellow.

  • Page 83: Port 25G/32G System/Port Indicators

    Status Indicator (for the blade) The Status LED is for the blade within the Xgig1000 chassis. A solid blue LED indicates the blade is ready to be used. A flashing green LED or a red/purple alternating LED indi- cates that firmware is being updated.
  • Page 84 15 more minutes. If this process fails, the Status LED is a steady red. In order to make sure the blade upgrade process is complete, check the Status LED on the blade, or open the Xgig1000 URL, and select the Status tab. NOTE In the case of a blade upgrade failure, contact the “Technical Assistance”...

  • Page 85: Port 25G/32G System Specifications

    Chapter 1 Xgig1000 System Overview Xgig1000 8 Port 25G/32G Chassis 8 Port 25G/32G System Specifications Table 40 Physical Specifications Height 3.50 in. / 8.89 cm. Width 9.50 in. / 24.13 cm. Depth 15.25 in. / 38.74 cm. Weight 12.00 lbs. / 5.44kg Mount 18.84 in.
  • Page 86 Chapter 1 Xgig1000 System Overview Xgig1000 8 Port 25G/32G Chassis Table 42 Port Specifications USB B 3.0 Port Type B version 3.0 Capable of up to 5 Gbps Clock In MCX Connector for Transmit Reference Clock Input 375 MHz AC-coupled, Typ. 0.8V, Max 1.2V peak-peak...

  • Page 87: Xgig1000 10 Port 25G/32G/50G/100G/128G Chassis

    Xgig1000 10 Port 25G/32G/50G/100G/128G Chassis Xgig1000 10 Port 25G/32G/50G/100G/128G Chassis The Xgig1000 10 Port 25G/32G/50G/100G/128G system is a fixed blade chassis that houses one Xgig 25G/32G/50G/100G/128G blade with eight SFP ports (four links) and two QSFP ports (one link). The Xgig1000 10 Port 25G/32G/50G/100G/128G system supports: •...
  • Page 88 Chapter 1 Xgig1000 System Overview Xgig1000 10 Port 25G/32G/50G/100G/128G Chassis The Xgig1000 10 Port 25G/32G/50G/100G/128G chassis is shown in Figure Figure 10 Xgig1000 10 Port 25G/32G/50G/100G/128G Chassis Page 72 Xgig1000 Hardware Guide March 2017...

  • Page 89: Port 25G/32G/50G/100G/128G System Ports/Connections/Front Panel Reset Button

    Cascade Ports The Cascade In and Cascade Out ports provide a means of time-synchronizing up to four Xgig, Xgig5000, and/or Xgig1000 chassis. Cascade Ports are used to share domains and send triggers between chassis. Cascade ports use standard RJ-45 connectors and straight through CAT5 cables to connect chassis, but use Viavi proprietary protocol to communicate between cascaded units.
  • Page 90 The Clock In port functionality is TBD. This port is reserved for future use. Port Connectors The Xgig1000 10 Port 25G/32G/50G/100G/128G has eight female SFP connectors and two QSFP connectors on the front. Front Panel Reset Button To safely shutdown the operating system and power off the chassis, press and hold the Front Panel Reset button for two seconds until the System LED starts blinking yellow.

  • Page 91: Port 25G/32G/50G/100G/128G System/Port Indicators

    Status Indicator (for the blade) The Status LED is for the blade within the Xgig1000 chassis. A solid blue LED indicates the blade is ready to be used. A flashing green LED or a red/purple alternating LED indi- cates that firmware is being updated.
  • Page 92 If you use the Xgig client to update your chassis, the GUI message will indicate that the upgrade is complete even though there may be a subsequent Xgig1000 blade upgrade that could last for 15 more minutes. If this process fails, the Status LED is a steady red.

  • Page 93: Port 25G/32G/50G/100G/128G System Specifications

    Chapter 1 Xgig1000 System Overview Xgig1000 10 Port 25G/32G/50G/100G/128G Chassis Table 44 10 Port 25G/32G/50G/100G/128G Blade LEDs Locked Indicates that Not Locked. The Jammer Jammer port is Left LED port locked for use is available. Xgig Maestro. Loss of Signal...
  • Page 94 Chapter 1 Xgig1000 System Overview Xgig1000 10 Port 25G/32G/50G/100G/128G Chassis Table 47 Port Specifications Cascade Ports RJ-45 connection to additional units (straight-through cable only) TTL Inputs MCX Connector for Trigger IN (thin coaxial cable only), The trigger-in can handle 3.3V or 5.0V inputs, active-high.

  • Page 95: Xgig1000 System Setup

    Xgig1000 System Setup Chapter 2 This chapter describes how to set up the Xgig1000 system. The topics discussed in this chapter are as follows: • “Unpacking the System” on page 80 • “Locating the System in Your Environment” on page 80 •...

  • Page 96: Unpacking The System

    Risk of explosion if battery is replaced by an incorrect type. Dispose of used Batteries according to the instructions of the battery manufacturer. Locating the System in Your Environment Place your Xgig1000 system in a location where you have easy access to the following: • Physical connection to your local area network •...

  • Page 97: Rack Mounting Instructions

    Use a screw driver to tighten all mounting screws. Fasten securely, but do not over tighten. Mount the Xgig1000 chassis in your equipment rack. Use the screws provided to attach the mounting bracket to the rack, two screws for each side.

  • Page 98: Xgig1000 System Overview

    (e.g. use of power strips). Xgig1000 System Overview The Xgig1000 chassis is a hardware platform that includes one fixed blade – it is part of a larger system. Performing application tasks requires PC hardware, installation of software at the PC, and making proper connections.
  • Page 99 Chapter 2 Xgig1000 System Setup Xgig1000 System Overview software applications. To set up the Xgig1000 chassis, follow the instructions in the following section, depending on the environment of your Xgig1000 system. Figure 13 shows the relationships of the components to use, update, and configure an Xgig1000 chassis in a network environment.

  • Page 100: Xgig1000 System And Application Images

    Xgig1000 System and Application Images NOTE The Xgig1000 chassis has two software images, one for system software and one for applications. All software required to run the Xgig1000 chassis comes pre-installed. All software required to run the Xgig1000 chassis comes pre-installed. Update of Xgig1000 chassis software is required with new releases.

  • Page 101: Xgig Client Software

    Network Address Translation (NAT) cannot be accessed from Xgig clients outside the firewall. For Windows users, ICMPv4 ‘Allow incoming echo request’ (used for Ping) is disabled by default. To use the Xgig Web Utility to upgrade an Xgig1000 chassis, this option must be enabled. March 2017...

  • Page 102: Setup Instructions

    Chapter 2 Xgig1000 System Setup Setup Instructions Setup Instructions To prepare the Xgig1000 chassis for use, follow one of the three paths below depending on your environment: NOTE The Xgig1000 chassis comes ready-to-use in a DHCP-configured network. This is the easiest way to setup the Xgig1000 chassis.

  • Page 103: Path 2: Setting Up The Xgig1000 Chassis With A Static Ip Address In A Non-Dhcp Network

    Xgig1000 chassis as well as the IP address. If you have a DNS name server, assign a name to the Xgig1000 chassis so users can easily locate the system. The default name for the Xgig1000 chassis is “XGIG1K” followed by the eight-digit serial number, for example, XGIG1K78256743.
  • Page 104 The Ethernet connection is required for management of the Xgig1000 chassis through application software and for configuration through the Xgig Web Utility. Plug in the Xgig1000 chassis. Attach the female end of the power cord to the Xgig1000 system power receptacle and the male end into an appropriate power source.
  • Page 105 Record the static IP address assigned to the Xgig1000 chassis. You will need this address to verify the connect to the Xgig1000 chassis and to use the Xgig Web Utility to set configuration parameters. 12 Type M and press Enter to set the Static Subnet Mask. Type in the IP address in IP dotted notation (for example, 255.255.255.0).

  • Page 106: Path 3: Setting Up The Xgig1000 Chassis In A Standalone Environment

    Command prompt, type the ping command with the new Static IP address as the argument. For example: > ping 10.10.4.34 If the ping is successful, you are ready to access the Xgig1000 chassis from the Xgig Web Utility and from Xgig software applications. If your request times out, see Chapter 4 “Tips and Troubleshooting”...
  • Page 107 Windows HyperTerminal. Plug one end of the cable into the Console port (9- pin port on the back), and the other into a COM port on the computer. This can be the same PC that will be used to connect with the Xgig1000 chassis through the Ethernet port.
  • Page 108 Press Y to continue with the reboot. When the screen shown below appears, press Enter. NOTE You must reboot for changes to take affect. Wait several minutes for the Xgig1000 chas- sis to boot. During boot, the HyperTerminal screen below will show no activity. Page 92...
  • Page 109 Command prompt, type the ping command with the new Static IP address as the argument. For example: > ping 10.10.4.4 If the ping is successful, you are ready to access the Xgig1000 chassis from the Xgig Web Utility and from Xgig software applications.

  • Page 110: Path 4: Setting Up The Xgig1000 Chassis Using Usb Direct Connect

    “System Upgrades” on page 121 instructions on upgrading the system software. The following steps instruct you on how to set up the Xgig1000 chassis to be controlled from a host computer using a USB cable connected directly to the chassis.

  • Page 111: Cascading Xgig1000 Chassis

    Once single Xgig1000 chassis are set up for operation, it is possible to cascade several chassis together using CAT-5 straight-through cables and the Cascade ports on the Xgig1000 chassis. Up to four chassis can be cascaded together to form a Sync Group. You can cascade Xgig1000 chassis together with Xgig chassis.
  • Page 112 Chapter 2 Xgig1000 System Setup Cascading Xgig1000 chassis Note that there is no connection to the Cascade In port of the master Xgig1000 chassis. Do not connect the Cascade Out port on the last Xgig in the cascade to the Cascade In port of the master in a “loop”.

  • Page 113: Sync Discovery Process

    Chapter 2 Xgig1000 System Setup Sync Discovery Process Sync Discovery Process The Xgig chassis can be cascaded together to form a Sync Group. A Sync Discovery process is run to establish the Sync Group topology. When Sync Discovery starts, all connections to the Sync Group will be severed.

  • Page 114: Xgig1000 Chassis Startup Sequence

    Sync Discovery may take several minutes. When the Xgig1000 chassis has finished booting and Sync Discovery has completed, the Cascade ports stop blinking and turn solid green if there are cascaded chassis.

  • Page 115: Xgig1000 Chassis Shutdown Sequence

    Xgig1000 Chassis Shutdown Sequence Xgig1000 Chassis Shutdown Sequence The following are the proper shutdown sequences for the Xgig1000 chassis. NOTE The LED behavior at shutdown is different between the two generations of the Xgig1000 chassis (see “Xgig1000 Systems” on page •...

  • Page 116: Shutdown Using Xgig Application

    Chapter 2 Xgig1000 System Setup Xgig1000 Chassis Shutdown Sequence Wait until the chassis shuts down completely before removing power. When the unit has completely shutdown, the behavior of the LEDs varies based on the generation of the chassis (see the note above.) Shutdown Using Xgig Application Right-click the chassis in the Port Discovery window.

  • Page 117: Administration

    Administration Chapter 3 This chapter describes how to perform the administrative tasks on the Xgig1000 chassis. The topics discussed in this chapter are as follows: • “Administration of the Xgig1000 System over the Internet” on page 102 • “Setting Client Authentication” on page 105 •...

  • Page 118: Administration Of The Xgig1000 System Over The Internet

    – change the TCP port number for the chassis. We recommend 52000. – synchronize the Xgig1000 system clock to the time on your local system – assign or change licensing for a blade within the chassis •...

  • Page 119: Accessing The Xgig1000 System For Administration

    Accessing the Xgig1000 System for Administration Once the IP address is set or assigned for the Xgig1000 chassis, use the IP address or the DNS name as the URL to reach the chassis over the Internet. For example, if the: –...

  • Page 120: System Requirements For Internet Administration

    Security menu of the Xgig Web Utility. If you forget the user name or password for the Xgig1000 chassis, you must use the Web Login Reset option from the console to reset the user name and password to the factory defaults.

  • Page 121: Setting Client Authentication

    Use the Security > Client Authentication menu of the Xgig Web Utility to set the pass- word for the Xgig1000 chassis. If authentication is not set for the Xgig1000, any user of Xgig Client software will be able to access and use the Xgig1000 chassis.

  • Page 122: Remote Administration Of The Xgig1000 System Via Usb

    This feature provides a client application in the Windows environment that allows you to perform the same configuration tasks as from the WEB Interface from the host computer using the USB interface through the USB 3.0 Type B port on the Xgig1000 chassis. Chassis Configuration Dialog Box This is the application’s main dialog box.

  • Page 123: Blade License Configuration

    Chapter 3 Administration Remote Administration of the Xgig1000 System via USB Then, fill in the required information in the Edit dialog box that is opened, press the Apply button to save the new information. An Xgig chassis reboot will be required to complete the change.
  • Page 124 Chapter 3 Administration Remote Administration of the Xgig1000 System via USB Use the button for the Blade (1-4) to select which blade to view. The buttons that have blue text are the blades that are installed in the chassis. The blade that is shown as underlined is the one currently selected.
  • Page 125 Chapter 3 Administration Remote Administration of the Xgig1000 System via USB Status will be shown on the Floating License Configuration dialog box. ATM License Configuration To view or add ATM licenses: From the Main dialog box, select the menu item Configurations\License\ATM.
  • Page 126 Chapter 3 Administration Remote Administration of the Xgig1000 System via USB To add a new license, click the Upgrade License button. A dialog box will pop up asking you to enter a 32 character license string. When entered, click the Apply button. When the process is complete, a dialog box will pop up and display the status.
  • Page 127 Chapter 3 Administration Remote Administration of the Xgig1000 System via USB • A section containing the detailed information for the first blade found. Detailed information for each blade can be viewed by either selecting the desired blade from the Blade Info menu, or using the keyboard, Ctrl + N (not case sensitive) to rotate through all of the installed blades.
  • Page 128 Chapter 3 Administration Remote Administration of the Xgig1000 System via USB The System Versions dialog box will pop up displaying the current version information. Chassis Reboot To reboot the Xgig chassis: From the main dialog box, select the menu item Server\Reboot.
  • Page 129 Chapter 3 Administration Remote Administration of the Xgig1000 System via USB A confirmation dialog box will open asking “Shutdown the System???”. Pressing the Yes button will cause the Xgig chassis to shutdown. Pressing the No button cancels the action. Sync Reset To run Sync Reset on the Xgig chassis: From the Main dialog box, select the menu item Server\Sync Reset.
  • Page 130 Chapter 3 Administration Remote Administration of the Xgig1000 System via USB Client Authentication To enable or disable client authentication: From the Main dialog box, select the menu item Security/Client Authentication. A dialog box will open and show the current status: Click the button for the state you require, then enter the password and confirm the pass- word if you have selected Enabled.

  • Page 131: Utilities

    Chapter 3 Administration Remote Administration of the Xgig1000 System via USB A confirmation dialog box will open asking “Reset The WEB Login???” Pressing the Yes button will cause the WEB Login value on the Xgig chassis to be set to factory default values.

  • Page 132: Run A Test

    Chapter 3 Administration Remote Administration of the Xgig1000 System via USB The ping and trace route utilities default to the Xgig chassis IP Address and the connected Host computer IP Address. The destination IP Address can be modified by the Current IP Address control.

  • Page 133: Operating System Support

    Chapter 3 Administration Remote Administration of the Xgig1000 System via USB Operating System Support The remote administration via USB feature is supported on the same OS as the Xgig Maestro and Analyzer software. However, this feature includes a USB driver. The driver is installed by the Xgig Maestro and the Analyzer software if it isn't already installed.

  • Page 134: How To Uninstall Or Re-Install The Xgig Usb Device Driver

    Chapter 3 Administration Remote Administration of the Xgig1000 System via USB Windows 2008 Server Driver Installation On those OS’s, the following dialog box will popup twice during installation, and click "Install this driver software anyway": After the installation has completed, when you connect the Xgig chassis to the computer's...

  • Page 135: Licensing

    Xgig blade or port-pair and require an additional license key. Blade Licenses Use the Web Utility to change the licensing of any Xgig1000 blade within a chassis. Blade licenses are assigned by the Xgig Web Utility ONLY and stored on the blade.
  • Page 136 The maximum number of licenses for a chassis is 16 ports or 8 port-pairs. Attaching a dongle so that the number of licenses exceeds the maximum licenses allowed for the chassis will result in unused licenses. Page 120 Xgig1000 Hardware Guide March 2017...

  • Page 137: System Upgrades

    FTP server software program. It is not required that you use the FTP server program supplied by Viavi or set up the FTP site until you need to upgrade the software on your Xgig1000 chassis.
  • Page 138 If You Need to Create an FTP Site If you do not have an FTP site or wish to install a separate FTP site for upgrades, Viavi supplies a free-ware FTP application. To install the FTP software application, follow these steps.

  • Page 139: Updating The Ftp Server With Upgrade Images

    Use this procedure to update Xgig1000 chassis software when new versions become available. There is no need to run this procedure when you first install the Xgig1000 chassis. Upgrades for the image software are distributed on the Xgig System Server Soft- ware USB Drive.

  • Page 140: Upgrading The Xgig1000 System Image And Application Image Software

    Figure 23 Xgig1000 System Login for Upgrade If you are having a problem reaching the Xgig1000 chassis through the browser, see “Cannot connect to the Xgig1000 chassis using the web browser” on page 131 in the Tips and Troubleshooting chapter.
  • Page 141 Figure 25 System Upgrade Tab CAUTION When selecting the Xgig System Image version, ensure that you only select a version from the available system versions for the Xgig1000. Do not select a version for the Xgig or the Xgig5000. Refer to Figure 25 and note how the software version vary between Xgig chassis platforms.
  • Page 142 For either type of upgrade, press the Upgrade button. The new image is loaded to the Xgig1000 chassis. The time it takes to load the image will depend on the type of upgrade. Do not refresh the Upgrade Utility page in the browser and wait until the Xgig1000 chassis has finished rebooting.
  • Page 143 • Open the Xgig1000 URL, and select the Status tab. If the blade upgrade is not yet complete, the tab will indicate that a blade firmware update is in progress, and the blade is not available for use.
  • Page 144 During a normal upgrade process, the Xgig 1000 Blade Status LED blinks green/off at a once per second rate. If the Xgig1000 blade experiences problem the Spartan FPGA will try to go to a Recovery state, and the Blade Status LED blinks red/purple at a once per second rate.

  • Page 145: Tips And Troubleshooting

    Tips and Troubleshooting Chapter 4 This chapter describes how to correct some issues with your Xgig1000 chassis. The topics discussed in this chapter are as follows: • “Troubleshooting” on page 130 • “Restarting the Xgig1000 Chassis with the Backup System Image Using USB System Recovery Drive”...

  • Page 146: Power Up Problems Following Chassis Shutdown

    Appendix A “Accessories for the Xgig1000 System” Power up problems following chassis shutdown If after removing and then reapplying power to the Xgig1000 chassis the system does not boot properly, you can try one of the following options. If you can connect through the web interface but suspect a corrupt system image you should perform a system upgrade rather than use the USB system recovery drive.

  • Page 147: Cannot Connect To The Xgig1000 Chassis Using The Web Browser

    IP addresses are correctly entered. • Ping other devices on the same subnet as the PC. If the Xgig1000 chassis is on a different subnet, ping other devices on the same subnet as the Xgig1000 chassis. This will ensure that your network is still functional.

  • Page 148: The System Is Rebooting Repeatedly

    CAT-5 cables are required. Use of cross-over cables between chassis may result in the Sync Discovery being unable to complete. • If you are cascading chassis, make sure all the chassis have the application image version. • Power cycle the chassis. Page 132 Xgig1000 Hardware Guide March 2017...

  • Page 149: Cannot Find An Xgig1000 Chassis Using The Discover Button In The Port Selection Window

    Restarting the Xgig1000 Chassis with the Backup System Image Using USB System Recovery Drive If you cannot connect to the Xgig1000 chassis and access the system through any of the administrations interfaces, such as the serial port, USB type A, or web interface, and you...

  • Page 150: Restarting The Xgig1000 Chassis With The Backup System Image

    Chapter 4 Tips and Troubleshooting Restarting the Xgig1000 Chassis with the Backup System Image Using USB System Recovery Drive If the operating system has been corrupted, the recovery drive can allow you to access the system by switching to the backup system image on the partition that is not in use and then configuring the chassis to boot to that unused partition.

  • Page 151: Tips

    Tips Pinging the Xgig1000 Chassis To “ping” the Xgig1000 chassis, click on the Start menu, select Run, and type in CMD. From the Command prompt, type the ping command with the IP address as the argument. For example: > ping 10.10.4.34 Naming the Xgig1000 Chassis The default name for the Xgig1000 chassis is “XGIG1K”...

  • Page 152: Recommended System For More Than 16 Ports

    Recommended System for More than 16 Ports Please follow the recommended system requirements listed in the Xgig Analyzer Software Installation Guide for using cascaded Xgig1000 chassis (more than 16 ports). • Pentium 4 multicore and/or multi process: clock speed 2 GHz •...

  • Page 153: Appendix A Accessories For The Xgig1000 System

    Accessories for the Xgig1000 System Appendix A This appendix describes the accessories associated with your Xgig1000 system. Topics discussed in this appendix are as follows: • “Analog Passthrough Adapters” on page 138 March 2017 Xgig1000 Hardware Guide Page 137...

  • Page 154: Analog Passthrough Adapters

    Analog Passthrough Adapters Analog Passthrough Adapters Analog Passthrough Adapters for SFP Connectors Xgig1000 chassis with 25 Gbps and 32 Gbps SFP ports are shipped with the appropriate number of analog passthrough (APT) adapters (Figure 28}. This adapter acts as a passthrough tap for both optical and electrical (copper) links.

  • Page 155: Quad Analog Passthrough (Qapt) Adapter For Qsfp Connectors

    For optical links, insert the optical QSFP transceivers into the QAPT connectors. These QSPF transceivers are specialized and are available by ordering the QSFP K-Kit from Viavi. Each K-kit includes two optical QSFP transceivers and two optical cables. You need to order Viavi part number 22110920 (which has the following description: XGIG1K-10002- MM;100GE/128G FC QSFP28 K-Kit Includes SFP28 and MM Cables).

  • Page 156: Connecting The Analog Passthrough Adapters

    For the 8-port and 10-port chassis, use SFP ports 1-2, 3-4, 5-6, or 7-8. – For the 10-port chassis, use the two QSFP ports. Figure 31 Ports on Xgig1000 25G/32G & Xgig1000 25G/32G/50G/100G/128G Chassis Page 140 Xgig1000 Hardware Guide March 2017...
  • Page 157 Appendix A Accessories for the Xgig1000 System Analog Passthrough Adapters Secure each adapter to the bracket using the thumbscrew on the bottom of the bracket. Figure 32 Installed Analog Passthrough Adapter Insert the SFPs/QSFPs/cables into the APT adapter(s). When the APT adapter is inserted into the chassis, the chassis is switched to analog passthrough mode.
  • Page 158 Appendix A Accessories for the Xgig1000 System Analog Passthrough Adapters Page 142 Xgig1000 Hardware Guide March 2017...

  • Page 159: First Generation Chassis

    Tips and Troubleshooting for Appendix B First Generation Chassis This appendix describes how to correct some issues with your first generation Xgig1000 chassis. Topics discussed in this appendix are as follows: • “Troubleshooting” on page 144 • “Restarting the Xgig1000 Chassis with the Backup System Image” on page 148 •...
  • Page 160 IP addresses are correctly entered. • Ping other devices on the same subnet as the PC. If the Xgig1000 chassis is on a different subnet, ping other devices on the same subnet as the Xgig1000 chassis. This will ensure that your network is still functional.

  • Page 161: Cannot Connect To The Xgig1000 Chassis Using The Web Browser

    “Technical Assistance” team. Cannot connect to the Xgig1000 chassis using the web browser The Xgig1000 chassis can be pinged, but the web browser returns an error message. The web application is not responding to the connection request. • Make sure you are using the correct version of the browser: IE 6.0 or greater or Firefox 1.5 or greater.

  • Page 162: The System Is Rebooting Repeatedly

    CAT-5 cables are required. Use of cross-over cables between chassis may result in the Sync Discovery being unable to complete. • If you are cascading chassis, make sure all the chassis have the application image version. • Power cycle the chassis. Page 146 Xgig1000 Hardware Guide March 2017...

  • Page 163: Cannot Find An Xgig1000 Chassis Using The Discover Button In The Port Selection Window

    Cannot find an Xgig1000 chassis using the discover button in the port selection window You are attempting to find a single Xgig1000 chassis or cascaded Xgig1000 chassis on the network using the discovery operation in Xgig application software. You cannot discover the Sync Group or the discovery process is taking an extremely long time.
  • Page 164 If the boot selection message does not appear, check the cable between the PC or terminal and the Xgig1000 chassis. If it appears to be correctly cabled and you still do not see the Xgig Command Line Options menu, contact the “Technical Assistance”...

  • Page 165: Tips

    Tips Pinging the Xgig1000 Chassis To “ping” the Xgig1000 chassis, click on the Start menu, select Run, and type in CMD. From the Command prompt, type the ping command with the IP address as the argument. For example: > ping 10.10.4.34...

  • Page 166: Recommended System For More Than 16 Ports

    Recommended System for More than 16 Ports Please follow the recommended system requirements listed in the Xgig Analyzer Software Installation Guide for using cascaded Xgig1000 chassis (more than 16 ports). • Pentium 4 multicore and/or multi process: clock speed 2 GHz •...
  • Page 167 4 Port 25G/32G chassis 8 Port 10G/16G chassis 8 Port 25G/32G chassis 8+2 Port 10G/16G/40G chassis PCIe chassis access adapter speed air flow analog passthrough adapters DHCP-configured network bracket duplex configuration March 2017 Xgig1000 Hardware Guide Page 151...
  • Page 168 8+2 Port 10G/16G/40G chassis 4 Port 10G/16G chassis PCIe chassis 4 Port 25G/32G chassis power supply 8 Port 10G/16G chassis 8 Port 25G/32G chassis 8+2 Port 10G/16G/40G chassis PCIe chassis QSFP analog passthrough adapter Page 152 Xgig1000 Hardware Guide March 2017...
  • Page 169 Index unpacking the system upgrade, software USB cable connection web administration March 2017 Xgig1000 Hardware Guide Page 153...
  • Page 170 Index Page 154 Xgig1000 Hardware Guide March 2017...
  • Page 172 March 2017 English Viavi Solutions North America: 1.844.GO VIAVI / 1.844.468.4284 Latin America +52 55 5543 6644 EMEA +49 7121 862273 APAC +1 512 201 6534 All Other Regions: viavisolutions.com/contacts email TAC@viavisolutions.com...

Table of Contents
