Unidrive Sequencing Mode - Control Techniques Profibus-DP User Manual

9.2

Unidrive Sequencing Mode 3

The default sequencing mode for Unidrive is the Wire-Proof PLC Mode.
If PLC Mode is selected (#6.04 = 3), the sequencing bits (#6.30 - #6.32)
have slightly different functions.
Control
Word
b0
b1
b2
b3
ENABLE
JOG
To reset the Unidrive using the Profibus-DP network, use the non-cyclic
channel to set #10.38 to 100. The Unidrive will clear #10.38 back to 0
and reset. (See Unidrive manual for more information.)
Some example control word values for the Unidrive are given in the
tables below.
b15–b12
0000
0001
0001
0001
0001
Issue Number: 3
Parameter Sequencing Bit
#6.15 Enable
#6.30 0
#6.31 1
#6.32 2
the display will show "Inh" when set at 0, and depends on
#6.30 and #6.32 when set to 1. Setting #6.15 to 0 overrides
#6.30 and #6.32, and immediately disables the Unidrive.
The motor will coast to rest if it is running when the Unidrive
is disabled.
the jog bit must be set, along with the appropriate run and
direction signals.
b11-b8 b7-b4 b3–b0
0010 0000 0000
1110 0000 0001
1110 0000 0011
1110 0000 1011
1110 0000 1111
PLC Mode
(#6.04 = 3)
Enable
Run
Jog
Reverse
Value Action (PLC mode)
0x0200 Drive disable
0x1E01 Enabled + stopped
0x1E03 Enabled + run fwd
0x1E0B Enabled + run rev
0x1E07 Enabled + jog rev
39
