TELEGRAM 2
The second telegram from the master also indicates a READ cycle, but
the stamp number is now 2. The data byte would contain the parameter
number for the parameter that is to read.
Bit
Value
Data word = 0x8202
When the second telegram has been received and processed in the
slave node, it is mirrored in the non-cyclic IN word. This is the signal to
the master controller program that the second telegram of the message
has been received and understood, and the third telegram can be
transmitted.
TELEGRAM 3
The third telegram from the master acts as the indication to the slave
node to send the data high byte from the requested parameter. The
data byte is not used in this telegram, and should be set to 0.
Bit
Value
Data word = 0x8300
When the third telegram has been received and processed in the slave
node, the node will mirror the stamp number in the non-cyclic IN word,
and load the high byte of the parameter value into the data byte.
Bit
Value
Data word = 0x8305
If an invalid parameter was specified in telegrams 1 and 2, e.g.
parameter is write only, or does not exist, the Profibus-DP interface will
set the ERROR bit to 1 (b14 = 1).
significance.
Bit
Value
Data word = 0xC200
If an error is reported, it is recommended that the non-cyclic data word
is set to 0 to ensure that the non-cyclic state machine is completely
reset, and ready for the next non-cyclic READ or WRITE sequence.
