Getting Started

The Quick Start section shows the basic parameter configurations
required for the Profibus-DP interfaces to establish communications.
Cyclic and non-cyclic data explanations are given in chapters 5 and 6.
NOTE
Parameters #20.01 to #20.20 and #20.50 are reserved for configuring
the Profibus-DPinterface, and should not be used in DPL programs.
4.1

Basic Communications Quick Start

Profibus-DP communications can be established with the Unidrive
Profibus-DP interface simply by configuring the node address.
•
Plug the Profibus-DP module into the Unidrive.
•
Power up the Unidrive.
•
Set the node address (#20.05) as required .
•
Set #17.19 to 1 to store #20.05 and reset the UD70.
The Profibus-DP interface will re-initialise, and configure itself with the
new node address. The data format and consistency are automatically
detected when the master controller initialises the network.
Function
Node Address
Data Rate
Network Loss
Trip
4.2

Profibus-DP Node Address

Unidrive:
Every node must be given a unique network address. If a node is
assigned an address, and that address already exists on the Profibus-
DP network, the node may prevent the network from operating. The
valid range of addresses is from 1 and 125.
If an invalid node address is set in #20.05, the Profibus-DP interface will
reject the configured address, default to 125, and update #20.05 with
the address that is actually being used.
NOTE
Changes to #20.PP parameters do not take effect in the Profibus-DP
interface until the UD70 has been reset. See section 4.7.
14
Unidrive Recommended Setting
#20.05 1 to 125
Not displayed The data rate is automatically
detected on Profibus-DP networks
#20.11 48
#20.05
Issue Number: 3
