8

Diagnostics

NOTE
The information from the parameters described below should always
be noted before contacting Control Techniques for technical support.
8.1

Fieldbus Code

Unidrive:
The fieldbus code identifies the hardware level in the Profibus-DP
interface.
upgrades can be performed on older modules.
The identification of the high-speed communications option module can
be read from #20.14 on the Unidrive display. This number is shown in
the form XYZ, where X is the fieldbus type, Y is the fieldbus flavour, and
Z is the hardware revision level.
#20.14 Fieldbus
100
(Profibus)
8.2

Firmware Version

Unidrive:
The version of firmware fitted to the Profibus-DP interface can be read
from #20.15.
levels that can accept each version of firmware.
#20.15
202
204
205
Issue Number: 3
#20.14
This information is vital when trying to determine what
Fieldbus
Type Flavour
1 0
(DP) (UD73A Issue 1 and UD73B Issue 1)
#20.15
The Hardware Revision column shows the hardware
Firmware Hardware
Version Revision
V2.02.00 0
V2.04.00 0
V2.05.00 0
Hardware Revision
0
