Disconnect the
1
Check that the exterior of the UD55 is not damaged, and that the
2
multi-way connector is free from dirt and debris. Do not fit a
damaged or dirty UD55 in a Drive.
Remove the terminal cover from the Drive (for removal instructions,
3
see Installing the Drive in Chapter 2 of the Unidrive Installation Guide).
If a small option module is already fitted in the Drive, grip the recesses
4
at the ends of the module and pull the module out of the Drive. Keep
the module for re-fitting.
Position the multi-way connector on the rear of the UD55 over the
5
connector in the Drive (see Figure 1), and press on the thumb pad to
push the UD55 into place.
6
supply from the Drive.
