Scan Feature - Vortex Impact 850 Manual

LOS Mode – Incline
When in LOS mode, an additional number is displayed below
the yardage number. This number is slope shown in degrees.
The slope incline number can be used with drop charts or field
cards to calculate precise bullet drops in mountainous terrain.
LOS Range
Incline Angle
12

SCAN FEATURE

The Scan feature can be used to range moving targets or
help range smaller targets on uniform backgrounds in either
HCD or LOS modes. Once powered up, press and hold the
Measure button and scan the laser back and forth, watching
for changes in the yardage number as the crosshairs move
across the target object. A blinking "S" display indicates
Scan Ranging is activated.
Scanning to get range:
Scan back and forth, watching for yardage number to display or change.
13
