- Page 1 PRODUCT MANUAL SLOPE...
- Page 2 When the unexpected happens, we’ve got your back. Our VIP Warranty is our lifelong, fully ™ transferable promise to repair or replace your rangefinder should it become damaged, no questions asked. Gamble on the next hole. Not your rangefinder.
-
Page 3: Specifications
BLADE ™ SLOPE SPECIFICATIONS BLADE SLOPE LASER RANGEFINDER ™ A round of golf has a lot of ups and downs. Fortunately, MAGNIFICATION slope compensation will help you range them all with point OBJECTIVE LENS 21mm and shoot confidence. MAX REFLECTIVE RANGE Up to 1400 yds. -
Page 4: Basic Operation
BLADE ™ SLOPE BASIC OPERATION Battery Installation & Replacement To insert a new battery, flip up Menu Button Objective the finger tab on the Battery Cap Lens and unscrew, counterclockwise, Measure Button to remove. Insert a CR2 battery with the positive side (+) facing Diopter Focus outwards. -
Page 5: Low Battery Icon
BLADE ™ SLOPE Low Battery Icon Low Battery MENU SELECTIONS The Low Battery Icon displays once the battery reaches 25% Changing Menu Settings life and stays on until there is no The Blade Slope is factory set to Slope Mode on, ™... - Page 6 BLADE ™ SLOPE Slope Mode When Slope Mode is on, the rangefinder will display two range values. The line of sight range will display on top The Blade Slope laser rangefinder features a Slope Mode. ™ with the slope-adjusted range underneath. The slope icon To turn Slope Mode on, toggle to “Slope”...
- Page 7 BLADE ™ SLOPE Pinspotter Mode Reticle Selection ™ The Blade Slope laser rangefinder comes equipped with The Blade Slope laser rangefinder offers three reticle ™ ™ PinSpotter Mode which provides visual and vibratory options. To change your reticle, toggle to the Reticle ™...
- Page 8 BLADE ™ SLOPE Range Unit Selection Ranging The Blade Slope laser rangefinder offers distances in yards With the Blade Slope laser rangefinder powered up, ™ ™ or meters. To change your range units, toggle to the Range position the reticle on the target object you wish to range, screen in the Menu Settings.
-
Page 9: Scan Feature
BLADE ™ SLOPE Scan Feature RANGEFINDING TIPS Activate the Scan Feature by pressing and holding the Laser rangefinders work by emitting a brief pulse of light “Measure” button. Keeping aimed at a target object. Distance is determined by the the button depressed will amount of time taken for the light to emit and return to continuously measure as you the laser’s internal receiver. -
Page 10: Maintenance
BLADE ™ SLOPE Lubrication • At longer distances, larger objects will be easier to range than smaller objects. All components of the Blade Slope are permanently ™ • If you have difficulty ranging an object, try ranging a lubricated, so no additional lubricant should be applied. different nearby object, or use the Scan feature to pan Note: Other than to remove the Battery Cap, do not attempt to back and forth while watching for changes in range. -
Page 11: Fcc Requirements
BLADE ™ SLOPE FCC REQUIREMENTS SAFETY AND PRECAUTIONS The user’s manual or instruction manual for an intentional Do not stare into beam or view directly without laser eye or unintentional radiator shall caution the user that protection. Staring continuously into beam for prolonged changes or modifications not expressly approved by the periods of time could cause harm to your eyes. -
Page 12: Warranty
Virtual Patent Marking Notice by Vortex Optics This product may be protected by patents in the U.S. and elsewhere for Vortex Optics. vtx.legal website is provided to satisfy the virtual patent marking provisions of various jurisdictions including the virtual patent marking provisions of the America Invents Act and provide notice ®... - Page 13 M-00352-1 © 2023 Vortex Optics ® Registered Trademark and TM Trademark of Vortex Optics. Patent Pending All other marks are the property of their respective owners.
