- Page 1 Installation Guide for RoboSHOT HDBT High-Performance PTZ Cameras Including RoboSHOT 12 HDBT, RoboSHOT 30 HDBT, RoboSHOT 12E HDBT, and RoboSHOT 30E HDBT Document 411-0003-31 Rev D April 2019...
-
Page 2: Table Of Contents
Contents Overview What's in this Guide Camera Features Unpacking the Camera A Quick Look at the Camera Front of the Camera Back of the Camera – RoboSHOT 12E HDBT and RoboSHOT 30E HDBT Back of the Camera – RoboSHOT 12 HDBT and RoboSHOT 30 HDBT Installing the Camera Don’t Void Your Warranty! Before You Start... -
Page 3: Overview
Overview ® This guide covers the RoboSHOT HDBT cameras: RoboSHOT 12 HDBT, North America – 999-9960-000 (silver/black) RoboSHOT 12 HDBT, Europe/UK – 999-9960-001 (silver/black) RoboSHOT 12 HDBT, Australia/New Zealand – 999-9960-009 (silver/black) RoboSHOT 12E HDBT, North America – 999-99600-000 (black); 999-99600-000W (white) RoboSHOT 12E HDBT, Europe/UK –... -
Page 4: What's In This Guide
Camera power-on Complete product information is available in the Complete Manual for RoboSHOT HDBT High- Performance PTZ Cameras. Download manuals, dimensional drawings, and other information from www.vaddio.com/support. Camera Features HDBaseT camera with simultaneous HDMI and H.264 IP streaming (RTSP or RTMP) View the RTSP stream from the camera using any standards-based media viewer ®... -
Page 5: Unpacking The Camera
RoboSHOT 12E HDBT, Australia/New Zealand – 999-99600-009 (black), 999-99600-009W (white) RoboSHOT 12E HDBT camera, black or white Thin Profile Wall Mount with mounting hardware, black or white, depending on camera color Vaddio IR Remote Commander PoE+ mid-span power injector with AC cord set(s) Quick-start guide RoboSHOT 12 HDBT, North America –... - Page 6 (white) RoboSHOT 30E HDBT camera (black or white) Thin Profile Wall Mount with mounting hardware, black or white, depending on camera color Vaddio IR Remote Commander PoE+ mid-span power injector with AC cord set(s) Quick-start guide RoboSHOT 30 HDBT, North America – 999-9963-000 (black), 999-9963-000W (white) RoboSHOT 30 HDBT, Europe and UK –...
- Page 7 RoboSHOT 12 OneLINK HDMI System for Cisco Codecs, Europe/UK – 999-9575-401 (silver/black) RoboSHOT 12 HDBT camera Thin Profile Wall Mount with mounting hardware, black Vaddio IR Remote Commander OneLINK HDMI interface 48V power supply with AC cord set(s) 10.25 in. (26 cm) Cisco CAB-PHD4XS2-SPLIT cable 3 ft.
- Page 8 RoboSHOT 12 OneLINK Bridge System for Cisco Codecs, Europe/UK – 999-9675-401 (silver/black) RoboSHOT 12 HDBT camera Thin Profile Wall Mount with mounting hardware, black Vaddio IR Remote Commander OneLINK Bridge interface 48V power supply with AC cord set(s) Phoenix-style connectors, qty. 4 10.25 in.
- Page 9 (black), 999-96450-501W (white) RoboSHOT 12E HDBT camera Thin Profile Wall Mount with mounting hardware, black or white, depending on camera color Vaddio IR Remote Commander OneLINK Bridge interface 48V power supply with AC cord set(s) 3-position Phoenix-style connectors, qty. 4 2 ft.
-
Page 10: A Quick Look At The Camera
Installation Guide for RoboSHOT HDBT High-Performance PTZ Cameras A Quick Look at the Camera The cameras in the RoboSHOT line are similar in appearance. RoboSHOT 12 HDBT is silver, with a black base and stepped lens bezel RoboSHOT 30 HDBT is available in black or white, and has a fluted lens bezel RoboSHOT 12E HDBT and RoboSHOT 30E HDBT are available in black or white, and have smooth lens bezels The image below shows a RoboSHOT 30 HDBT camera. -
Page 11: Back Of The Camera - Roboshot 12E Hdbt And Roboshot 30E Hdbt
Installation Guide for RoboSHOT HDBT High-Performance PTZ Cameras Back of the Camera – RoboSHOT 12E HDBT and RoboSHOT 30E HDBT Rear panel connections are identical for the RoboSHOT 12E HDBT and RoboSHOT 30E HDBT cameras. From left to right: OneLINK HDBaseT: RJ-45 connector. Connect to the network via PoE+ injector or OneLINK device for power, video, streaming, and control via the web interface or Telnet session. -
Page 12: Back Of The Camera - Roboshot 12 Hdbt And Roboshot 30 Hdbt
Installation Guide for RoboSHOT HDBT High-Performance PTZ Cameras Back of the Camera – RoboSHOT 12 HDBT and RoboSHOT 30 HDBT Rear panel connections are identical for the older RoboSHOT 12 HDBT and RoboSHOT 30 HDBT cameras. From left to right: 12 VDC, 3.0 A: EIAJ-04 jack for local power. -
Page 13: Installing The Camera
Do not install or operate this product if it has been dropped, damaged, or exposed to liquids. If any of these things happen, return it to Vaddio for safety and functional testing. Caution If using a DC power supply with this product, use the power supply included with it or recommended for use with it. -
Page 14: Installing The Wall Mount
Installation Guide for RoboSHOT HDBT High-Performance PTZ Cameras Prepare for a successful installation: Be sure you can identify all cables correctly. Check Cat-5 cables for continuity. Ensure that the video resolution rotary switch and the DIP switches (if any) are set appropriately. Talk to the network administrator. -
Page 15: Video Resolution Setting
Installation Guide for RoboSHOT HDBT High-Performance PTZ Cameras Video Resolution Setting All non-architectural RoboSHOT cameras use a rotary switch to set output resolution. Streaming resolution is set separately in the web interface. Set the desired video output resolution with the rotary switch before installing the camera. Note that the video resolutions are mapped differently on the rotary switch for the newer Elite-series cameras. -
Page 16: Camera Behavior Settings - Roboshot 12 Hdbt And Roboshot 30 Hdbt
Installation Guide for RoboSHOT HDBT High-Performance PTZ Cameras Camera Behavior Settings – RoboSHOT 12 HDBT and RoboSHOT 30 HDBT Older RoboSHOT cameras use DIP switches to set camera behaviors; the RoboSHOT Elite series cameras set all camera behaviors in the web interface. A label on the bottom of the camera provides a quick reference for setting the switches. -
Page 17: Rs-232 Serial Communication Settings
Installation Guide for RoboSHOT HDBT High-Performance PTZ Cameras RS-232 Serial Communication Settings The RS-232 serial port (color-coded blue) provides a means of controlling the camera from a third-party device. Be sure the camera is set to the same baud rate as the external control device. If the camera is powered by a OneLINK device, an RS-232 port is available on the OneLINK for an external control device. -
Page 18: Connecting The Camera
Installation Guide for RoboSHOT HDBT High-Performance PTZ Cameras Connecting the Camera Note Talk to the network administrator before you connect the equipment. If you install this equipment on a non-DHCP network (one that uses only static IP addresses), you may need to configure the camera with a static IP address before you connect it to the network. -
Page 19: Basic Connections - Roboshot 12 Hdbt Or Roboshot 30 Hdbt
Installation Guide for RoboSHOT HDBT High-Performance PTZ Cameras Basic Connections – RoboSHOT 12 HDBT or RoboSHOT 30 HDBT This diagram shows a basic installation for a RoboSHOT 12 HDBT or RoboSHOT 30 HDBT camera. -
Page 20: Basic Connections - Roboshot Hdbt With Camera Extension
Installation Guide for RoboSHOT HDBT High-Performance PTZ Cameras Basic Connections – RoboSHOT HDBT with Camera Extension This diagram shows a RoboSHOT 12 HDBT camera connected to a OneLINK HDMI interface to extend power, video, and control over a single cable. The RoboSHOT 12E HDBT, RoboSHOT 30 HDBT, and RoboSHOT 30E HDBT can be connected in the same way. -
Page 21: Basic Connections - Roboshot Hdbt Basic Conference Setup
Installation Guide for RoboSHOT HDBT High-Performance PTZ Cameras Basic Connections – RoboSHOT HDBT Basic Conference Setup This diagram shows a RoboSHOT 12 HDBT camera with a OneLINK Bridge interface in a basic conference room installation. The RoboSHOT 12E HDBT, RoboSHOT 30 HDBT, and RoboSHOT 30E HDBT can be connected in the same way. -
Page 22: Basic Connections - Roboshot Hdbt Camera With Third-Party Control And Power
Installation Guide for RoboSHOT HDBT High-Performance PTZ Cameras Basic Connections – RoboSHOT HDBT Camera with Third-Party Control and Power This example shows basic connections using a Crestron device. This diagram shows a RoboSHOT 12 HDBT camera. The RoboSHOT 12E HDBT, RoboSHOT 30 HDBT, and RoboSHOT 30E HDBT can be connected in the same way. -
Page 23: Installing The Camera
Installation Guide for RoboSHOT HDBT High-Performance PTZ Cameras Installing the Camera Be sure you have already set the camera's switches. Caution Check your cables. Connecting a cable to the wrong port or using the wrong pin-out can result in equipment damage and will void the warranty. -
Page 24: Powering Up The Camera
Installation Guide for RoboSHOT HDBT High-Performance PTZ Cameras Powering Up the Camera Connect camera power. The camera will run a self-test routine and move to its home position. This will take a few seconds. When the camera is initialized and ready, video is available and the status light is blue. At this point, the camera is ready to accept control information. -
Page 25: Operation, Storage, And Care
Installation Guide for RoboSHOT HDBT High-Performance PTZ Cameras Operation, Storage, and Care For smears or smudges on the product, wipe with a clean, soft cloth. Use a lens cleaner on the lens. Do not use any abrasive chemicals. Keep this device away from food and liquids. Do not operate or store the device under any of the following conditions: Temperatures above 40°C (104°F) or below 0°C (32°F) High humidity, condensing or wet environments... -
Page 26: Compliance And Conformity Statements
(2) This device must accept any interference including interference that may cause undesired operation of the device. Changes or modifications not expressly approved by Vaddio can affect emission compliance and could void the user’s authority to operate this equipment. -
Page 27: European Compliance
Installation Guide for RoboSHOT HDBT High-Performance PTZ Cameras European Compliance This product has been evaluated for Electromagnetic Compatibility under the EMC Directive for Emissions and Immunity and meets the requirements for a Class A digital device. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. ... -
Page 28: Warranty And Return Policy
Vaddio Customer Service: Vaddio will test, repair, or replace the product or products without charge if the unit is under warranty. If the product is out of warranty, Vaddio will test then repair the product or products. The cost of parts and labor charge will be estimated by a technician and confirmed by the customer prior to repair. - Page 29 Initial shipments of equipment that are refused upon attempted delivery, for any reason, are subject to restocking charges. The Dealer has up to 60 days from the date of purchase to return Vaddio product for credit for future purchases of Vaddio product only.
- Page 30 Returns must be made in the original Vaddio packaging with all original materials if at all possible. Vaddio products with missing original materials will be billed to the dealer at dealer price.
- Page 31 Repair Charge Estimates: Estimates on repair charges for a specific problem will not be given before an RMA is issued and the actual product has been evaluated by a Vaddio technician. Repair estimates will be given after the repair department receives and evaluates the unit.
-
Page 32: Photo Credits
Installation Guide for RoboSHOT HDBT High-Performance PTZ Cameras Photo Credits This manual may include some or all of these photos. European Space Agency (ESA) astronaut Samantha Cristoforetti, a Flight Engineer with Expedition 42, photographs the Earth through a window in the Cupola on the International Space Station By NASA - https://blogs.nasa.gov/ISS_Science_Blog/2015/03/06/women-in-space-part-two-whats- gender-got-to-do-with-it/, Public Domain, https://commons.wikimedia.org/w/index.php?curid=38834990 Carl Sagan, Bruce Murray, Louis Friedman (founders) and Harry Ashmore (advisor), on the occasion of... -
Page 33: Index
Index mounting cameras 11-12, 21 OneLINK 9-10, 16-17 anatomy of the camera 8-10 operating environment 23 output resolution 13 behavior on power-up 22 packing lists 3 pin-out, RS-232 connector 15 cable 9-10, 15 power 9-10, 16-17, 22 connectors 9-10, 15 on and off 22 please check them (PLEASE) 15 options 10, 16-17... - Page 34 ©2019 Legrand AV Inc. Vaddio is a registered trademark of Legrand AV Inc. All other brand names or marks are used for identification purposes and are trademarks of their respective owners. All patents are protected under existing designations. Other patents pending.
