Automationdirect.com Productivity 1000 P1-16TR Manual

Output Specifications
Outputs per Module
Rated Voltage
Operating Voltage Range
Output Type
AC Frequency
Maximum Output Current
Minimum Load Current
Maximum Inrush Current
OFF to ON, ON to OFF
Response
Status Indicators
Commons
Maximum Applicable Fuse
Typical Relay Life
Voltage & Type of Load Operations at 1A Load Current
30VDC Resistive
30VDC Solenoid
120VAC Resistive
120VAC Solenoid
240VAC Resistive
240VAC Solenoid
Sales 800-633-0405
16
6.25–30 VDC, 6–120 VAC
5–30 VDC, 5–144 VAC
Relay FORM A (SPST)
47–63 Hz
2A / point, 8A / common for both AC and DC
2A / point, 4A / common if used with ZIPLink Cable
5mA @ 5VDC
5A for 10ms
d 10 ms
Logic Side (16 points)
2 isolated (8 points/common)
8A
100,000
100,000
100,000
100,000
100,000
100,000
1000
P1-16TR Relay Output
P1-16TR
The P1-16TR Relay Output Module provides
C1
sixteen 2A outputs with two isolated commons
for use with the Productivity1000 system.
1
2
3
4
5
6
Output Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . 1
7
Module Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
8 QR Code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Wiring Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
C2
Schematic & Wiring Diagram . . . . . . . . . . . . . . . . . . . . 3
9
General Specifications . . . . . . . . . . . . . . . . . . . . . . . . . 4
10
Terminal Block Specifications . . . . . . . . . . . . . . . . . . . . 4
11
Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
12
13
14
15
16
RELAY
OUTPUT
Terminal Block sold separately, (see wiring options on page 3).
Warranty: Thirty-day money-back guarantee. Two-year limited
replacement (See www.productivity1000.com for details).
www.productivity1000.com
