Optional 4-Cable Installation Kit
The optional Extron SMK A 4C 4-aircraft cable installation kit
allows the SF 26PT speaker to be suspended from 4 overhead
points or 5 overhead points such as a pipe or eye bolt (when
also using the PCC-2 cable).
Steel
45°
Cables (4)
1 1
45°
2" min.
Four Mounting Points
Four mounting points
1. Route the four cables from the kit to overhead mounting
locations such that the angle between each cable and the
vertical position directly above the speaker is 45°
2. The angle between each of the 4 cables and its adjacent
cable is 90°.
3. Use cable locks to secure the 4 cables from the kit to the
mounting locations
NOTE: In order to ensure that all cable locks are
not unintentionally unlocked, keep the area
within 2 inches of all cable locks in any direction
free of any other objects. See the Warning at
the beginning of this guide.
4. Connect the 4 swaged steel cable ends from the kit
through the speaker cap and to the hook
For information on safety guidelines, regulatory compliances, EMI/EMF compatibility, accessibility, and related topics, see the
Extron Safety and Regulatory Compliance Guide
©
2018 Extron Electronics All rights reserved. All trademarks mentioned are the property of their respective owners.
6
0° Vertical
Speaker
Wires (2)
45°
2 2
45°
Cable Lock
3 3
.
2
.
3
on the Extron website.
Five mounting points
Steel
Cables (4)
1. Route the cut end of both PCC-2 steel cables to an
overhead anchor point
secure the cables in place.
2. Route the four cables from the kit to the overhead
mounting locations
cables and the 0° vertical position directly above the
speaker is 45°.
3. The angle between each of the 4 kit cables and its
.
1
adjacent cable is 90°.
4. Use cable locks to secure the 4 cables from the kit to
the mounting locations
NOTE:
unintentionally unlocked, keep the area within
2 inches of all cable locks in any direction free
of any other objects. See the Warning at the
beginning of this guide.
5. Connect the 6 swaged steel cable ends (2 from the
PCC-2 cable and 4 from the kit) through the speaker
cap and to the hook
NOTE: See the user guide for painting instructions.
See the SF 26PT User Guide for further details.
0° Vertical
4 4
PCC-2
1 1
45° 45°
2 2
45° 45°
5 5
2" min.
Five Mounting Points
using the cable locks to
1
such that angle between those
2
.
3
In order to ensure that the cable lock is not
.
5
www.extron.com
3 3
Cable Lock
