SteppIR 4 Element Yagi Installation Instructions
SteppIR™ 4 element Yagi at Dayton Hamvention, 2003
SteppIR Antennas
23831 S.E. Tiger MT. RD. - Issaquah, WA 98027
Tel: 425-391-1999
Fax: 425-391-8377 Toll Free: 866.783.7747
Web: www.steppir.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4 Element Yagi and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SteppIR 4 Element Yagi

Summary of Contents for SteppIR 4 Element Yagi

  • Page 1 6WHSS,5 zVertical Yagi Dipole (Patent Pending) SteppIR 4 Element Yagi Installation Instructions SteppIR™ 4 element Yagi at Dayton Hamvention, 2003 SteppIR Antennas 23831 S.E. Tiger MT. RD. - Issaquah, WA 98027 Tel: 425-391-1999 Fax: 425-391-8377 Toll Free: 866.783.7747 Web: www.steppir.com...

  • Page 2: Table Of Contents

    I R ™ A I R ™ A I R ™ A T E P P T E P P N T E N N A S N T E N N A S T E P P N T E N N A S Topic Page Table of Contents...

  • Page 3: Pre-Assembly Tips

    Assembly Instructions: It is a good idea to make and use a working copy of the Assembly Instructions. You can download a copy from our web site and use it while building your SteppIR™. This will prevent the original from becoming torn, stained or otherwise mutilated when assembling the antenna. It is nice to retain a brand new set of instructions.

  • Page 4: Parts List

    N T E N N A S N T E N N A S PARTS LIST Description Assembly Instructions Operators Manual SteppIR™ antenna controller Power supply for controller¹ Aluminum boom sections² Boom to mast plate 11.5” x 11.5” Driven element housing unit Passive element housing unit³...
  • Page 5 I R ™ A I R ™ A I R ™ A T E P P N T E N N A S T E P P T E P P N T E N N A S N T E N N A S PARTS LIST Description TERMINAL STRIP / EHU PACK...

  • Page 6: Assembling The Antenna

    Doing so will provide you an overall idea of what needs to be done and helps avoid mak- ing time-consuming mistakes. At a minimum, read the directions for each step before starting it. Building your SteppIR™ is a straightforward process. It entails: • Building the boom •...
  • Page 7 I R ™ A I R ™ A I R ™ A T E P P N T E N N A S T E P P T E P P N T E N N A S N T E N N A S Drawing 1 below shows the layout of the boom for assembly.

  • Page 8: Step 2: Connect The Boom-To-Mast Plate To The Boom

    I R ™ A I R ™ A I R ™ A T E P P N T E N N A S T E P P T E P P N T E N N A S N T E N N A S Locate and position the seven sections of boom tubing, and the respective fasteners.

  • Page 9: Step 3: Secure The Element Housing Units To The Element-To-Boom Brackets

    I R ™ A I R ™ A I R ™ A T E P P T E P P N T E N N A S N T E N N A S T E P P N T E N N A S Locate the two boom-to-mast plates and the 3/8”...
  • Page 10 I R ™ A I R ™ A I R ™ A T E P P N T E N N A S T E P P T E P P N T E N N A S N T E N N A S Proper EHU orientation is critical to operation of the antenna.

  • Page 11: Step 4: Connect The Required Wiring

    (8 pairs of wires, each pair with one colored wire and one black wire) that goes to the shack is connected. Do NOT connect the 16 conductor cable to the SteppIR™ controller until instructed to do so. If you ordered the 16 conductor control cable, it is included in your antenna kit. The required 25 pin con- nector has been installed on one end and the factory has stripped and tinned the wires on the other end.
  • Page 12 N T E N N A S NOTE: If you are upgrading to a 4 element from a SteppIR™ 3 element Yagi, you will need to use the included 35 foot roll of 4 conductor cable to extend the control cable on each antenna housing to accommodate the longer boom length.

  • Page 13: Step 5: Attach The Wiring Enclosure And Control Cable To The Boom

    I R ™ A I R ™ A I R ™ A T E P P T E P P N T E N N A S N T E N N A S T E P P N T E N N A S STEP 5: Attach the Wiring Enclosure and Control Cable to the Boom Locate the unattached white PVC tube cap, #56 stainless steel hose clamp and black electrical tape.

  • Page 14: Step 6: Prepare The Fiberglass Element Support Tubes

    I R ™ A I R ™ A I R ™ A T E P P T E P P N T E N N A S N T E N N A S T E P P N T E N N A S STEP 6: Prepare the Fiberglass Element Support Tubes Locate the eight fiberglass poles, two rolls of black electrical tape, two rolls of Black silicone self-curing tape and your tape measure.

  • Page 15: Step 7: Attach The Fiberglass Element Support Tubes To The Element Housing Units

    I R ™ A I R ™ A I R ™ A T E P P N T E N N A S T E P P T E P P N T E N N A S N T E N N A S 3.

  • Page 16: Step 8: Install The Optional 6 Meter Passive Element (If Ordered)

    I R ™ A I R ™ A I R ™ A T E P P N T E N N A S T E P P T E P P N T E N N A S N T E N N A S 2.

  • Page 17: Step 9: Install The Boom Truss Support Assembly

    I R ™ A I R ™ A I R ™ A T E P P T E P P N T E N N A S N T E N N A S T E P P N T E N N A S Locate the small packet of connector protector.
  • Page 18 I R ™ A I R ™ A I R ™ A T E P P N T E N N A S T E P P T E P P N T E N N A S N T E N N A S Attach the cable clips to the Phillystran, with the first one as close to the end of the thimble as possible, so the cable will be “locked”...

  • Page 19: Upgrading Your Controller (For Customers Upgrading From A 3 Element Yagi Only)

    I R ™ A I R ™ A I R ™ A T E P P N T E N N A S T E P P T E P P N T E N N A S N T E N N A S Upgrading the Controller (Upgrade Kit Customers Only) 1.
