Lubrication
All Aviator™ spool valves are pre-lubricated and will operate dry
(with no additional lubrication). The use of lubricated air will not
interfere with the Aviator's functioning.
Bill of Material
Item Part #
1 XM0268
2 X00903
3 X00878
4 X00838
5 1079352
6 X00892
7 X00814
8 X00779
9 X00837
10A Varies
11A 100158
12A X00893
13A XM0276
10B Varies
11B X00895
12B X00894
13B XM0292
LML0002-1 (AUTO-32) 3/03
© 2003, Flowserve Corporation, Printed in U.S.A.
Installation, Operation and Maintenance Instructions
1350 N. Mountain Springs Parkway
Springville, Utah 84663-3004
Phone: 801 489 8611
Description Qty.
Housing Base 1
1 / " Muffler 1
8
Spool Valve 1
10-32 x 1 1 / SHCS 3
8
Breather 2
O-Ring 2
O-Ring 1
O-Ring 3
1 / x 2 Tubing 1
8
2 Watt Solenoid Pilot 2
4-40 x 1 PHS 1
O-Ring 1
Manifold Block 1
.67 Watt Solenoid Pilot 1
O-Ring 1
O-Ring 1
Manifold Block 1
Automax Valve Automation Systems
If air lubrication is used, the oils listed below are popular, easily
obtainable fluids that are recommended for use with the Aviator™
Spool valve: Gulf Harmony 47, Mobil DTE Medium, Shell Tellus
29, Texaco Rondo B, Sohivis 47 and Sunnis 921. Many other
lubricants are acceptable providing they do not contain detergents
that will attack Nitrile or Viton Seals.
Item Part # Description
14 100167 8-32 x 1
15 X00410 1 / " Tube Fittings
8
16 X00410G Gasket
17 Varies Switch Card
18 105915 #6-32 x
19 103627 Ground Screw
20 105626 Cup Washer
21 X00801 5 / -18 bolts
16
22 XM0269 Housing Cover
23 X00663 Rotor
24 X00677 O-Ring
25 X00662 Dome
26 X00676 #10-24 x
27 Varies Shaft Assembly
28 103603 O-Ring
29 101810 Snap Ring
1978 Foreman Dr.
Cookeville, TN 38501
Phone: 931 432 4021
Qty.
/ PHS 4
2
2
2
1
1 / PHS 2
4
1
1
5
1
1
1
1
1 /
PHS 4
2
1
2
1
