Component Location For Typical Rthc Unit (Back View) - Trane RTHC Installation Operation & Maintenance

175-450 ton units (60 hz); 125-450 ton units (50 hz)
Table of Contents

Advertisement

Figure 3

Component Location for Typical RTHC Unit (Back View)

Oil Separator
Relief
Valves
Oil Distribution
System
NOTE: The evaporator inlets and outlets are located opposite from those on the RTHA and RTHB
units. The water inlet must be at the bottom of the shell for proper operation.
1 - 8
Compressor
Discharge
Lines
Condenser
Oil Separator
Oil Sump
(located between condenser and evaporator)
8" vessels have ASME nameplate
Unit Nameplate
(on side of starter/control
panel)
Lifting
Holes
Evaporator
Water Outlet
RTHC-IOM-1C
