Transition Networks SISPM1040-3248-L Cli Reference Manual

Rack mount industrial ethernet switch, managed hardened poe+ switch, 24 10/100/1000base-t poe+ ports + 4 100/1000base-x sfp/rj-45 combo + 4 1g/10g sfp+
Hide thumbs Also See for SISPM1040-3248-L:

Advertisement


Transition Networks

SISPM1040‐3248‐L CLI Reference


SISPM1040‐3248‐L
Rack Mount Industrial Ethernet Switch
Managed Hardened PoE+ Switch, (24) 10/100/1000Base‐T PoE+ ports +
(4) 100/1000Base‐X SFP/RJ‐45 Combo + (4) 1G/10G SFP+
CLI Reference
33764 Rev. A


33764 Rev. A
https://www.transition.com
Page 1 of 250
