Transition Networks SISPM1040-182D User Manual

8 10/100tx + 2 10/100/1000t/mini-gbic combo with 8 poe injector industrial switch
Hide thumbs
Table of Contents

Advertisement

Quick Links

8 10/100TX + 2 10/100/1000T/Mini-GBIC
Combo with 8 PoE Injector Industrial Switch
User Manual
SISPM1040-182D
Version 1.01
October, 2009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SISPM1040-182D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Transition Networks SISPM1040-182D

Summary of Contents for Transition Networks SISPM1040-182D

  • Page 1 8 10/100TX + 2 10/100/1000T/Mini-GBIC Combo with 8 PoE Injector Industrial Switch User Manual SISPM1040-182D Version 1.01 October, 2009...

  • Page 2: Revision History

    Transition Networks SISPM1040-182D Revision History Document Date Revision Initials Release 1.00 Oct 31, 2008 First release A.E.F 1.01 Oct 21, 2009 Corrections A.E.F Technical Support: 1-800-260-1312 International: 00-1-952-941-7600...
  • Page 3 Transition Networks SISPM1040-182D Notice The contents of this manual are based on the table below listing firmware version, kernel version, and hardware version. If the switch functions are different from the description of the manual, please contact the local sale dealer for more information.

  • Page 4: Fcc Warning

    Transition Networks SISPM1040-182D FCC Warning This Equipment has been tested and found to comply with the limits for a Class-A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 5: Table Of Contents

    Transition Networks SISPM1040-182D Content Chapter 1 Introduction......... 1 Hardware Features........1 Software Features ........5 Package Contents ........8 Chapter 2 Hardware Description ......9 Physical Dimension ........9 Front Panel..........9 Bottom View ..........10 LED Indicators........... 11 Chapter 3 Hardware Installation .......
  • Page 6 Transition Networks SISPM1040-182D-LR Login in the Console Interface....30 CLI Management........32 Commands Level ........32 Chapter 6 Web-Based Management....34 About Web-based Management....34 Preparing for Web Management ....34 System Login..........35 System Information ........36 IP Configuration......... 37 DHCP Server..........
  • Page 7 Transition Networks SISPM1040-182D-LR 6.22 IGMP Configuration........ 100 6.23 X-Ring............. 102 6.24 LLDP Configuration ........ 105 6.25 Security—802.1X/Radius Configuration. 106 6.26 MAC Address Table ....... 110 6.27 Power over Ethernet....... 115 6.28 Factory Default ........117 6.29 Save Configuration......... 118 6.30 System Reboot ........
  • Page 8 Transition Networks SISPM1040-182D-LR TFTP Commands Set .......... 145 SystemLog, SMTP and Event Commands Set ..145 SNTP Commands Set.......... 147 X-ring Commands Set.......... 148 Technical Support: 1-800-260-1312 International: 00-1-952-941-7600...

  • Page 9: Chapter 1 Introduction

    Transition Networks SISPM1040-182D Chapter 1 Introduction The 8 10/100TX + 2 10/100/1000T/Mini-GBIC Combo w/8 PoE Injectors Managed Industrial Switch is a cost-effective solution and meets the high reliability requirements demanded by industrial applications. Fiber can extend the connection distance to increases the network elasticity and performance.
  • Page 10 Transition Networks SISPM1040-182D-LR MAC Address 8K MAC address table Flash ROM 4Mbytes DRAM 32Mbytes 10/100TX: 8 x RJ-45 10/100/1000T/ Mini-GBIC Combo: 2 x RJ-45 + 2 x Connector 100/1000 SFP sockets RS-232 connector: RJ-45 type 10Base-T: 2-pair UTP/STP Cat. 3, 4, 5/ 5E cable EIA/TIA-568 100-ohm (100m) 100Base-TX: 2-pair UTP/STP Cat.
  • Page 11 Transition Networks SISPM1040-182D-LR Positive (VCC+): RJ-45 pin 1,2. Negative (VCC-): RJ-45 pin 3,6. Protocol CSMA/CD Per unit: Power (Green), Power 1 (Green), Power 2 (Green), Fault (Red), Master (Green), FWD (Green) 8 port 10/100: Link/Activity (Green), Full duplex/Collision (Amber) SFP port: LNK/ACT(Green), 1000T: LNK/ACT(Green),...
  • Page 12 Transition Networks SISPM1040-182D-LR IEC60068-2-32 (Free fall), IEC60068-2-27 (Shock), Stability Testing IEC60068-2-6 (Vibration) Technical Support: 1-800-260-1312 International: 00-1-952-941-7600...

  • Page 13: Software Features

    Transition Networks SISPM1040-182D-LR 1.2 Software Features Management SNMP v1 v2c, v3/ Web/Telnet/CLI RFC 1215 Trap, RFC1213 MIBII, RFC 1157 SNMP MIB, RFC 1493 SNMP MIB Bridge MIB, RFC 2674 VLAN MIB, RFC 1643 , RFC 1757, RSTP MIB, Private MIB, LLDP MIB Port Based VLAN IEEE 802.1Q Tag VLAN (256 entries)/ VLAN ID (Up to 4K,...
  • Page 14 Transition Networks SISPM1040-182D-LR Port Mirror Supports 3 mirroring types: “RX, TX and Both packet”. Supports IGMP snooping v1,v2 IGMP 256 multicast groups and IGMP query Supports 10 IP addresses that have permission to access IP Security the switch management and to prevent unauthorized intruder.
  • Page 15 Transition Networks SISPM1040-182D-LR 4. Authorization fail 5. PD disconnect trap-PoE port event DHCP Provides DHCP Client/ DHCP Server/ Port and IP Binding Provides DNS client feature and supports Primary and Secondary DNS server SNTP Supports SNTP to synchronize system clock in Internet Firmware Update Supports TFTP firmware update, TFTP backup and restore.

  • Page 16: Package Contents

    Transition Networks SISPM1040-182D-LR 1.3 Package Contents Please refer to the package content list below to verify them against the checklist. 8 10/100TX + 2 10/100/1000T/Mini-GBIC Combo w/8 PoE Injectors Managed Industrial Switch x 1 User manual x 1 Pluggable Terminal Block x 1...

  • Page 17: Chapter 2 Hardware Description

    Transition Networks SISPM1040-182D Chapter 2 Hardware Description This chapter will describe the Industrial switch’s hardware spec, port, cabling information, and wiring installation. 2.1 Physical Dimension 8 10/100TX w/ X-Ring Managed Industrial Switch dimension (W x D x H) is 72mm x 105mm x 152mm 2.2 Front Panel...

  • Page 18: Bottom View

    Transition Networks SISPM1040-182D-LR 2.3 Bottom View The bottom panel of the 8 10/100TX w/ X-Ring Managed Industrial Switch has one terminal block connector for two (2) DC power inputs and one fault alarm. Bottom Panel of the industrial switch Technical Support: 1-800-260-1312...

  • Page 19: Led Indicators

    Transition Networks SISPM1040-182D 2.4 LED Indicators The diagnostic LEDs that provide real-time status information are located on the front panel of the industrial switch. The following table provides the description of the LED status and their meanings. Color Status Meaning...
  • Page 20 Transition Networks SISPM1040-182D-LR The SFP port is linking Link/Active The port is transmitting or receiving packets (P9, P10 Green Blinks from the TX device. SFP) No device attached A network device is detected. The port is transmitting or receiving packets...

  • Page 21: Chapter 3 Hardware Installation

    Transition Networks SISPM1040-182D Chapter 3 Hardware Installation This chapter describes how to physically install the 8 10/100TX w/ X-Ring Managed Industrial Switch. 3.1 Installation Steps 1. Unpack the Industrial switch 2. Check if the DIN-Rail is screwed on the Industrial switch or not. If the DIN-Rail is not screwed on the Industrial switch, please refer to DIN-Rail Mounting section for DIN- Rail installation.

  • Page 22: Din-Rail Mounting

    Transition Networks SISPM1040-182D-LR 3.2 DIN-Rail Mounting The DIN-Rail is factory installed. If the DIN-Rail is not screwed on the industrial switch, please see the following pictures. Follow the steps below to hang the industrial switch. Technical Support: 1-800-260-1312 International: 00-1-952-941-7600...
  • Page 23 Transition Networks SISPM1040-182D First, insert the top of DIN-Rail into the track. Then, lightly push the DIN-Rail into the track. Verify the DIN-Rail is tightened. To remove the industrial switch from the track, reverse above steps. Technical Support: 1-800-260-1312 International: 00-1-952-941-7600...

  • Page 24: Wall Mount Plate Mounting

    Transition Networks SISPM1040-182D 3.3 Wall Mount Plate Mounting Follow the steps below to mount the industrial switch with wall mount plate. 1. Remove the DIN-Rail from the industrial switch; loose the screws to remove the DIN- Rail. 2. Place the wall mount plate on the rear panel of the industrial switch.

  • Page 25: Wiring The Power Inputs

    Transition Networks SISPM1040-182D 3.4 Wiring the Power Inputs Please follow the steps below to insert the power wire. 1. Insert AC or DC power wires into the contacts 1 and 2 for power 1, or 5 and 6 for power 2.

  • Page 26: Wiring The Fault Alarm Contact

    Transition Networks SISPM1040-182D 3.5 Wiring the Fault Alarm Contact The fault alarm contacts are in the middle of the terminal block connector as the picture below shows. If configured the switch will detect power failure, or port link failure (available for managed model) and then form an open circuit. The following illustration shows an application example for wiring the fault alarm contacts.

  • Page 27: Cabling

    Transition Networks SISPM1040-182D 3.6 Cabling Use four twisted-pair, Category 5e or above cabling for RJ-45 port connection. The cable between the switch and the link partner (switch, hub, workstation, etc.) must be less than 100 meters (328 ft.) long. Fiber segment using single-mode connector type must use 9/125 μm single-mode fiber cable.
  • Page 28 Transition Networks SISPM1040-182D-LR To connect the transceiver and LC cable, please follow the steps shown below: First, insert the transceiver into the SFP module. Notice that the triangle mark is the bottom of the module. Transceiver to the SFP module Transceiver Inserted Second, insert the fiber cable of LC connector into the transceiver.
  • Page 29 Transition Networks SISPM1040-182D-LR LC connector to the transceiver Technical Support: 1-800-260-1312 International: 00-1-952-941-7600...
  • Page 30 Transition Networks SISPM1040-182D-LR To remove the LC connector from the transceiver, please follow the steps shown below: First, press the upper side of the LC connector to release from the transceiver and pull it out. Remove LC connector Second, push down the metal loop and pull the transceiver out by the plastic handle.

  • Page 31: Chapter 4 Network Application

    Transition Networks SISPM1040-182D Chapter 4 Network Application This chapter illustrates some example applications. Below is a typical industrial switch application: Technical Support: 1-800-260-1312 International: 00-1-952-941-7600...
  • Page 32 Transition Networks SISPM1040-182D-LR The illustration below shows an example power over Ethernet application. Technical Support: 1-800-260-1312 International: 00-1-952-941-7600...

  • Page 33: X-Ring Application

    Transition Networks SISPM1040-182D 4.1 X-Ring Application The industrial switch supports the X-Ring protocol that can help the network recover from connection failure within 20ms or less, and make the network system more reliable. The X-Ring algorithm is similar to spanning tree protocol (STP) algorithm but its recovery time is faster than STP.

  • Page 34: Coupling Ring Application

    Transition Networks SISPM1040-182D 4.2 Coupling Ring Application A network may have more than one X-Ring group. The coupling ring function can connect each X-Ring for redundant backup. It can ensure transmissions between two ring groups do not fail. The following figure illustrates a coupling ring application.

  • Page 35: Dual Homing Application

    Transition Networks SISPM1040-182D 4.3 Dual Homing Application The Dual Homing function prevents lost connection between an X-Ring group and an upper level/core switch. Assign two ports to be the Dual Homing ports in the X-Ring group. The Dual Homing function only works when the X-Ring function is active. Each X- Ring group only has one Dual Homing port.

  • Page 36: Dual Ring Application

    Transition Networks SISPM1040-182D 4.4 Dual Ring Application Dual ring is an advanced function that supports backup connection to ensure redundant transmission. If the connection fails, the system will recover from fwithin 20 milliseconds. Apart from that, Dual Ring only needs one unit (and only the one located in the middle) to be configured as the Ring Master switch to deploy the dual ring.

  • Page 37: Chapter 5 Console Management

    Transition Networks SISPM1040-182D Chapter 5 Console Management 5.1 Connecting to the Console Port The supplied cable has an RS-232 connector on one end and an RJ-45 connector on the other end. Attach the RS-232 connector to a PC or terminal and the other end of RJ-45 connector to the console port of the switch.

  • Page 38: Login In The Console Interface

    Transition Networks SISPM1040-182D-LR 5.3 Login in the Console Interface When the connection between the Switch and the PC is ready, turn on the PC and run a terminal emulation program or Hyper Terminal and configure its communication parameters to match the following default characteristics of the console port:...
  • Page 39 Transition Networks SISPM1040-182D-LR Console login interface Technical Support: 1-800-260-1312 International: 00-1-952-941-7600...

  • Page 40: Cli Management

    Transition Networks SISPM1040-182D 5.4 CLI Management The switch supports console management—CLI commands. After you log in to the system, you will see a command prompt. To enter CLI management interface, type “enable”. CLI command interface The following table lists the CLI commands and their description.
  • Page 41 Transition Networks SISPM1040-182D-LR Enter the To exit to Use this mode to configure privileged configure those Global command switch EXEC parameters that are Configuration while in (config)# mode, enter going to be applied to privileged exit or end your switch.

  • Page 42: Chapter 6 Web-Based Management

    Transition Networks SISPM1040-182D Chapter 6 Web-Based Management This section introduces the configuration and functions of the Web-Based management. 6.1 About Web-based Management There is an embedded HTML web server residing in flash memory in the switch. This offers advanced management features and allows users to manage the switch from anywhere on the network through a standard web browser such as Microsoft Internet Explorer.

  • Page 43: System Login

    Transition Networks SISPM1040-182D-LR 6.3 System Login Launch the Internet Explorer on the PC Key in “http:// “+” the IP address of the switch”, and then Press “Enter”. The login screen will appear right after Key in the user name and password. The default user name and password are ‘root’.

  • Page 44: System Information

    Transition Networks SISPM1040-182D-LR 6.4 System Information Users can assign the system name, description, location and contact personnel to identify the switch. The version table below is a read-only field to show the basic information of the switch. System Name: Assign the system name of the switch (The maximum length is 64 bytes) System Description: Describes the switch.

  • Page 45: Ip Configuration

    Transition Networks SISPM1040-182D 6.5 IP Configuration The switch is a network device which needs to be assigned an IP address for being identified on the network. Users have to decide a means of assigning IP address to the switch. DHCP Client: Enable or disable the DHCP client function. When DHCP client function is enabled, the switch will be assigned an IP address from the network DHCP server.
  • Page 46 Transition Networks SISPM1040-182D-LR IP configuration interface Technical Support: 1-800-260-1312 International: 00-1-952-941-7600...

  • Page 47: Dhcp Server

    Transition Networks SISPM1040-182D 6.6 DHCP Server DHCP is the abbreviation of Dynamic Host Configuration Protocol that is a protocol for assigning dynamic IP addresses to devices on a network. With dynamic addressing, a device can have a different IP address every time it connects to the network. In some systems, the device's IP address can even change while it is still connected.
  • Page 48 Transition Networks SISPM1040-182D 6.6.1 System configuration DHCP Server: Enable or Disable the DHCP Server function. Enable—the switch will be the DHCP server on your local network. Low IP Address: Type in an IP address. Low IP address is the beginning of the dynamic IP range.

  • Page 49: Client Entries

    Transition Networks SISPM1040-182D 6.6.2 Client Entries When the DHCP server function is enabled, the system will collect the DHCP client information including the assigned IP address, the MAC address of the client device, the IP assigning type, status and lease time.

  • Page 50: Port And Ip Bindings

    Transition Networks SISPM1040-182D 6.6.3 Port and IP Bindings Assign the dynamic IP address bound with the port to the connected client. The user is allowed to fill each port column with one particular IP address. When the device is connecting to the port and asks for IP assigning, the system will assign the IP address bound with the port.

  • Page 51: Tftp

    Transition Networks SISPM1040-182D 6.7 TFTP TFTP allows the user to update the switch firmware via the Trivial File Transfer Protocol (TFTP) server. Before updating, make sure the TFTP server is ready and the firmware image is located on the TFTP server.

  • Page 52: Restore Configuration

    Transition Networks SISPM1040-182D 6.7.2 Restore Configuration You can restore a previous backup configuration from the TFTP server to recover the settings. Before doing so, you must locate the image file on the TFTP server. TFTP Server IP Address: Type in the TFTP server IP.

  • Page 53: Backup Configuration

    Transition Networks SISPM1040-182D 6.7.3 Backup Configuration You can back up the current configuration from flash ROM to the TFTP server for the purpose of recovering the configuration later. It helps you save time. TFTP Server IP Address: Type in the TFTP server IP.

  • Page 54: System Event Log

    Transition Networks SISPM1040-182D 6.8 System Event Log This page allows the user to decide whether to send the system event log, and select the mode which the system event log will be sent to client only, server only, or both client and server.
  • Page 55 Transition Networks SISPM1040-182D-LR Syslog Configuration interface Technical Support: 1-800-260-1312 International: 00-1-952-941-7600...
  • Page 56 Transition Networks SISPM1040-182D 6.8.2 System Event Log—SMTP Configuration Simple Mail Transfer Protocol (SMTP) is the standard for email transmissions across the network. You can configure the SMTP server IP, mail subject, sender, mail account, password, and the recipient email addresses which the e-mail alert will send to.
  • Page 57 Transition Networks SISPM1040-182D-LR SMTP Configuration interface Technical Support: 1-800-260-1312 International: 00-1-952-941-7600...
  • Page 58 Transition Networks SISPM1040-182D 6.8.3 System Event Log—Event Configuration Having ticked the Syslog/SMTP checkboxes, the event log/email alert will be sent to the system log server and the SMTP server respectively. Also, Port event log/alert (link up, link down, and both) can be sent to the system log server/SMTP server respectively by setting the trigger condition.
  • Page 59 Transition Networks SISPM1040-182D-LR Event Configuration interface Technical Support: 1-800-260-1312 International: 00-1-952-941-7600...

  • Page 60: Fault Relay Alarm

    Transition Networks SISPM1040-182D 6.9 Fault Relay Alarm The Fault Relay Alarm function provides Power Failure and Port Link Down/Broken detection. With both power input 1 and power input 2 installed and the check boxes of power 1/power 2 ticked, the FAULT LED indicator will then light up if either power failure occurs.

  • Page 61: Sntp Configuration

    Transition Networks SISPM1040-182D 6.10 SNTP Configuration SNTP (Simple Network Time Protocol) is a simplified version of NTP which is an Internet protocol used to synchronize the clocks of computers to some time reference. Because time usually just advances, the time on different node stations will be different. With the communicating programs running on those devices, it would cause time to jump forward and back, a non-desirable effect.
  • Page 62 Transition Networks SISPM1040-182D-LR EST - Eastern Standard -5 hours 7 am CDT - Central Daylight CST - Central Standard -6 hours 6 am MDT - Mountain Daylight MST - Mountain Standard -7 hours 5 am PDT - Pacific Daylight PST - Pacific Standard...
  • Page 63 Transition Networks SISPM1040-182D-LR CCT - China Coast, +8 hours 8 pm USSR Zone 7 JST - Japan Standard, +9 hours 9 pm USSR Zone 8 EAST - East Australian Standard GST +10 hours 10 pm Guam Standard, USSR Zone 9...
  • Page 64 Transition Networks SISPM1040-182D-LR SNTP Configuration interface Technical Support: 1-800-260-1312 International: 00-1-952-941-7600...

  • Page 65: Ip Security

    Transition Networks SISPM1040-182D 6.11 IP Security IP security allows the user to assign 10 specific IP addresses that have permission to manage the switch through the http and telnet services. The purpose of providing limited IP addresses permission is to allow only the authorized personnel/device access to management tasks on the switch.
  • Page 66 Transition Networks SISPM1040-182D-LR IP Security interface Technical Support: 1-800-260-1312 International: 00-1-952-941-7600...

  • Page 67: User Authentication

    Transition Networks SISPM1040-182D 6.12 User Authentication Change web management login user name and password for the management security issue. User name: Type in the new user name (The default is ‘root’) Password: Type in the new password (The default is ‘root’)

  • Page 68: Port Statistics

    Transition Networks SISPM1040-182D 6.13 Port Statistics The following chart provides the current statistic information which displays the real-time packet transfer status for each port. The user might use the information to plan and implement the network, or check and find problems when collisions or heavy traffic occurs.
  • Page 69 Transition Networks SISPM1040-182D-LR Port Statistics interface Technical Support: 1-800-260-1312 International: 00-1-952-941-7600...

  • Page 70: Port Control

    Transition Networks SISPM1040-182D 6.14 Port Control In Port control you can configure the settings of each port to control the connection parameters, and the status of each port is listed beneath. Port: Use the scroll bar and click on the port number to choose the port to be configured.
  • Page 71 Transition Networks SISPM1040-182D-LR Port Control interface Technical Support: 1-800-260-1312 International: 00-1-952-941-7600...

  • Page 72: Port Trunk

    Transition Networks SISPM1040-182D 6.15 Port Trunk Port trunking is the combination of several ports or network cables to expand the connection speed beyond the limits of any one single port or network cable. Link Aggregation Control Protocol (LACP), which is a protocol running on layer 2, provides a standardized means in accordance with IEEE 802.3ad to bundle several physical...
  • Page 73 Transition Networks SISPM1040-182D-LR ports to be aggregated in a trunk group. Click and the ports focused in the right side will be shifted to the left side. To remove unwanted ports, select the ports and click Remove When LACP enabled, you can configure LACP Active/Passive status for each port on the State Activity tab.

  • Page 74: Aggregator Information

    Transition Networks SISPM1040-182D 6.15.2 Aggregator Information LACP disabled Having set up the aggregator setting with LACP disabled, you will see the local static trunk group information on the tab of Aggregator Information. Assigning 2 ports to a trunk group with LACP disabled Static Trunking Group information Group Key: This is a read-only column field that displays the trunk group ID.
  • Page 75 Transition Networks SISPM1040-182D-LR Port Member: This is a read-only column field that displays the members of this static trunk group. Technical Support: 1-800-260-1312 International: 00-1-952-941-7600...
  • Page 76 Transition Networks SISPM1040-182D LACP enabled Having set up the aggregator setting with LACP enabled, you will see the trunking group information between two switches on the tab of Aggregator Information. Switch 1 configuration Set System Priority of the trunk group. The default is 1.
  • Page 77 Transition Networks SISPM1040-182D-LR Aggregation Information of Switch 1 Click on the tab of Aggregator Information to check the trunked group information as the illustration shown above after the two switches configured. Technical Support: 1-800-260-1312 International: 00-1-952-941-7600...
  • Page 78 Transition Networks SISPM1040-182D Switch 2 configuration Switch 2 configuration interface Set System Priority of the trunk group. The default is 1. Select a trunk group ID by pull down the drop-down menu bar. Enable LACP. Include the member ports by clicking the Add button after selecting the port number and the column field of Work Ports changes automatically.
  • Page 79 Transition Networks SISPM1040-182D-LR Click on the tab of Aggregator Information to check the trunked group information as the illustration shown above after the two switches configured. Technical Support: 1-800-260-1312 International: 00-1-952-941-7600...
  • Page 80 Transition Networks SISPM1040-182D 6.15.3 State Activity Having set up the LACP aggregator on the tab of Aggregator Setting, you can configure the state activity for the members of the LACP trunk group. You can tick or cancel the checkbox beside the state label. When you remove the tick mark of the port and click Apply , the port state activity will change to Passive.
  • Page 81 Transition Networks SISPM1040-182D-LR State Activity of Switch 2 Technical Support: 1-800-260-1312 International: 00-1-952-941-7600...

  • Page 82: Port Mirroring

    Transition Networks SISPM1040-182D 6.16 Port Mirroring Port mirroring is a method for monitoring traffic in switched networks. Traffic through ports can be monitored by one specific port, which means traffic that goes in or out monitored (source) ports will be duplicated into mirror (destination) port.

  • Page 83: Rate Limiting

    Transition Networks SISPM1040-182D 6.17 Rate Limiting You can set up every port’s bandwidth rate and frame limitation type. Ingress Limit Frame type: select the frame type that wants to filter. There are four frame types for selecting: Broadcast/Multicast/Flooded Unicast Broadcast/Multicast...
  • Page 84 Transition Networks SISPM1040-182D-LR Ingress: Enter the port effective ingress rate (The default value is “0”). Egress: Enter the port effective egress rate (The default value is “0”). And then, click to apply the settings Apply Technical Support: 1-800-260-1312 International: 00-1-952-941-7600...

  • Page 85: Vlan Configuration

    Transition Networks SISPM1040-182D 6.18 VLAN configuration A Virtual LAN (VLAN) is a logical network grouping that limits the broadcast domain, which allows you to isolate network traffic. Only the members of the same VLAN will receive traffic from those of the same VLAN. Basically, creating a VLAN on a switch is the logical equivalent of reconnecting a group of network devices to another Layer 2 switch.
  • Page 86 Transition Networks SISPM1040-182D 6.18.1 Port-based VLAN A port-based VLAN basically consists of its members—ports, which means the VLAN is created by grouping the selected ports. This method provides convenience for users to configure a simple VLAN easily without complicated steps. Packets can go among only members of the same VLAN group.
  • Page 87 Transition Networks SISPM1040-182D-LR VLAN—Port Based Add interface Enter the group name and VLAN ID. Add the selected port number into the right field to group these members to be a VLAN group, or remove any of them listed in the right field from the VLAN.
  • Page 88 Transition Networks SISPM1040-182D-LR VLAN—Port Based Edit/Delete interface Delete to delete the VLAN. Edit to modify group name, VLAN ID, or add/remove the members of the existing VLAN group. [NOTE] Remember to execute the “Save Configuration” action, otherwise the new configuration will be lost when the switch power off.
  • Page 89 Transition Networks SISPM1040-182D 6.18.2 802.1Q VLAN Virtual Local Area Network (VLAN) can be implemented on the switch to logically create different broadcast domains. When the 802.1Q VLAN function is enabled, all ports on the switch belong to default VLAN of VID 1, which means they logically are regarded as members of the same broadcast domain.
  • Page 90 Transition Networks SISPM1040-182D 802.1Q Configuration Pull down the selection item and focus on 802.1Q, then press Apply to set the VLAN Operation Mode in 802.1Q mode. Enable GVRP Protocol: GVRP (GARP VLAN Registration Protocol) is a protocol that facilitates control of virtual local area networks (VLANs) within a larger network.
  • Page 91 Transition Networks SISPM1040-182D-LR aware devices (switches). A Trunk Port, connected to the trunk link, has an understanding of tagged frame, which is used for the communication among VLANs across switches. Which frames of the specified VIDs will be forwarded depends on the values filled in the Tagged VID column field. Please insert a comma between two VIDs.
  • Page 92 Transition Networks SISPM1040-182D-LR 802.1Q VLAN interface Group Configuration Edit the existing VLAN Group. Select the VLAN group in the table list. Click Edit Technical Support: 1-800-260-1312 International: 00-1-952-941-7600...
  • Page 93 Transition Networks SISPM1040-182D-LR Group Configuration interface You can modify the VLAN group name and VLAN ID. Group Configuration interface Technical Support: 1-800-260-1312 International: 00-1-952-941-7600...
  • Page 94 Transition Networks SISPM1040-182D-LR Click Apply Technical Support: 1-800-260-1312 International: 00-1-952-941-7600...

  • Page 95: Rapid Spanning Tree

    Transition Networks SISPM1040-182D 6.19 Rapid Spanning Tree The Rapid Spanning Tree Protocol (RSTP) is an evolution of the Spanning Tree Protocol and provides for faster spanning tree convergence after a topology change. The system also supports STP and the system will auto-detect the connected device that is running STP or RSTP protocol.
  • Page 96 Transition Networks SISPM1040-182D-LR RSTP System Configuration interface Technical Support: 1-800-260-1312 International: 00-1-952-941-7600...
  • Page 97 Transition Networks SISPM1040-182D 6.19.2 Port Configuration This web page provides the port configuration interface for RSTP. You can assign higher or lower priority to each port. Rapid spanning tree will have the port with the higher priority in forwarding state and block other ports to make certain that there is no loop in the LAN.
  • Page 98 Transition Networks SISPM1040-182D-LR RSTP Port Configuration interface Technical Support: 1-800-260-1312 International: 00-1-952-941-7600...

  • Page 99: Snmp Configuration

    Transition Networks SISPM1040-182D 6.20 SNMP Configuration Simple Network Management Protocol (SNMP) is the protocol developed to manage nodes (servers, workstations, routers, switches and hubs etc.) on an IP network. SNMP enables network administrators to manage network performance, find and solve network problems, and plan for network growth.
  • Page 100 Transition Networks SISPM1040-182D-LR SNMP System Configuration interface Technical Support: 1-800-260-1312 International: 00-1-952-941-7600...

  • Page 101: Trap Configuration

    Transition Networks SISPM1040-182D 6.20.2 Trap Configuration A trap manager is a management station that receives the trap messages generated by the switch. If no trap manager is defined, no traps will be issued. To define a management station as a trap manager, assign an IP address, enter the SNMP community strings, and select the SNMP trap version.
  • Page 102 Transition Networks SISPM1040-182D 6.20.3 SNMPV3 Configuration Configure the SNMP V3 function. Context Table Configure SNMP v3 context table. Assign the context name of context table. Click to add context name. Click Remove to remove unwanted context name. User Table Configure SNMP v3 user table..
  • Page 103 Transition Networks SISPM1040-182D-LR SNMP V3 configuration interface Access Table Configure SNMP v3 access table. Context Prefix: set up the context name. Group Name: set up the group. Security Level: select the access level. Context Match Rule: select the context match rule.
  • Page 104 Transition Networks SISPM1040-182D-LR Notify View Name: set up the notify view. Click to add context name. Click to remove unwanted context name. Remove MIBview Table Configure MIB view table. ViewName: set up the name. Sub-Oid Tree: fill the Sub OID.

  • Page 105: Qos Configuration

    Transition Networks SISPM1040-182D 6.21 QoS Configuration Quality of Service (QoS) is the ability to provide different priority to different applications, users or data flows, or to guarantee a certain level of performance to a data flow. QoS guarantees are important if the network capacity is insufficient, especially for real-time...
  • Page 106 Transition Networks SISPM1040-182D-LR QoS Configuration interface 6.21.2 Port-based Priority Configure the priority level for each port. With the drop-down selection item of Priority Type above being selected as Port-based, this control item will then be available to set Technical Support: 1-800-260-1312...
  • Page 107 Transition Networks SISPM1040-182D-LR the queuing policy for each port. Port x: Each port has 4 priority levels—High, Middle, Low, and Lowest—to be chosen. Click Apply to have the configuration take effect. 6.21.3 COS Configuration Set up the COS priority level. With the drop-down selection item of Priority Type above being selected as COS only/COS first, this control item will then be available to set the queuing policy for each port.

  • Page 108: Igmp Configuration

    Transition Networks SISPM1040-182D 6.22 IGMP Configuration The Internet Group Management Protocol (IGMP) is an internal protocol of the Internet Protocol (IP) suite. IP manages multicast traffic by using switches, routers, and hosts that support IGMP. Enabling IGMP allows the ports to detect IGMP queries, report packets, and manage IP multicast traffic through the switch.
  • Page 109 Transition Networks SISPM1040-182D-LR IGMP Configuration interface Technical Support: 1-800-260-1312 International: 00-1-952-941-7600...

  • Page 110: X-Ring

    Transition Networks SISPM1040-182D 6.23 X-Ring X-Ring provides a faster redundant recovery than Spanning Tree topology. The action is similar to STP or RSTP, but the algorithms between them are not the same. In the X- Ring topology, every switch should be enabled with X-Ring function and two ports should be assigned as the member ports in the ring.
  • Page 111 Transition Networks SISPM1040-182D-LR the 2 Ring Port to be the working port. Enable Couple Ring: To enable the couple ring function, tick the checkbox beside the Enable Couple Ring string label. Couple Port: Assign the member port which is connected to the other ring group.
  • Page 112 Transition Networks SISPM1040-182D-LR [NOTE] 1. When the X-Ring function enabled, the user must disable the RSTP. The X-Ring function and RSTP function cannot exist on a switch at the same time. 2. Remember to execute the “Save Configuration” action, otherwise the new configuration will lose when switch powers off.

  • Page 113: Lldp Configuration

    Transition Networks SISPM1040-182D 6.24 LLDP Configuration Link Layer Discovery Protocol (LLDP) is defined in the IEEE 802.1AB, it is an emerging standard which provides a solution for the configuration issues caused by expanding LANs. LLDP specifically defines a standard method for Ethernet network devices such as switches, routers and wireless LAN access points to advertise information about themselves to other nodes on the network and store the information they discover.

  • Page 114: Security-802.1X/Radius Configuration

    Transition Networks SISPM1040-182D 6.25 Security—802.1X/Radius Configuration 802.1x is an IEEE authentication specification which prevents the client from accessing a wireless access point or wired switch until it provides authority, like the user name and password that are verified by an authentication server (such as RADIUS server).
  • Page 115 Transition Networks SISPM1040-182D-LR 802.1x System Configuration interface Technical Support: 1-800-260-1312 International: 00-1-952-941-7600...

  • Page 116: Port Configuration

    Transition Networks SISPM1040-182D 6.25.2 Port Configuration You can configure the 802.1x authentication state for each port. The state provides Disable, Accept, Reject, and Authorize. Reject: The specified port is required to be held in the unauthorized state. Accept: The specified port is required to be held in the authorized state.

  • Page 117: Misc Configuration

    Transition Networks SISPM1040-182D-LR 6.25.3 Misc Configuration Quiet Period: Set the period which the port doesn’t try to acquire a supplicant. TX Period: Set the period the port waits for retransmit next EAPOL PDU during an authentication session. Supplicant Timeout: Set the period of time the switch waits for a supplicant response to an EAP request.

  • Page 118: Mac Address Table

    Transition Networks SISPM1040-182D 6.26 MAC Address Table Use the MAC address table to ensure the port security. 6.26.1 Static MAC Address You can add a static MAC address that remains in the switch's address table regardless of whether the device is physically connected to the switch. This saves the switch from having to re-learn a device's MAC address when the disconnected or powered-off device is active on the network again.
  • Page 119 Transition Networks SISPM1040-182D-LR Static MAC Addresses interface Technical Support: 1-800-260-1312 International: 00-1-952-941-7600...

  • Page 120: Mac Filtering

    Transition Networks SISPM1040-182D 6.26.2 MAC Filtering By filtering MAC address, the switch can easily filter the pre-configured MAC address and reduce the un-safety. You can add and delete filtering MAC address. MAC Filtering interface MAC Address: Enter the MAC address that you want to filter.

  • Page 121: All Mac Addresses

    Transition Networks SISPM1040-182D 6.26.3 All MAC Addresses You can view all of the MAC addresses learned by the selected port. Select the port number. The selected port of static & dynamic MAC address information will be displayed in here. Click...
  • Page 122 Transition Networks SISPM1040-182D 6.26.4 MAC Address Table—Multicast Filtering Multicasts are similar to broadcasts, they are sent to all end stations on a LAN or VLAN. Multicast filtering is the function, which end stations can receive the multicast traffic if the connected ports had been included in the specific multicast groups.

  • Page 123: Power Over Ethernet

    Transition Networks SISPM1040-182D 6.27 Power over Ethernet This segment shows the Power over Ethernet function. PoE Status Maximum Power Available: Displays the maximum power supply in Watt. Actual Power Consumption: This column shows the real-time total power consumption. System Power Limit: User can modify the value to this column field to limit the total output power for the system.
  • Page 124 Transition Networks SISPM1040-182D-LR a certain period (for details, see the IEEE 802.3af specification). Capacitive Detection: If the port and capacitive detection are enabled, the capacitances state reads in the voltage result from the constant current. This is then subtracted from the pre-capacitance voltage to get a charge rate. If this charge rate is within the window of the PD signatures, the device is considered to be discovered.

  • Page 125: Factory Default

    Transition Networks SISPM1040-182D 6.28 Factory Default Reset switch to default configuration. Click Default to reset all configurations to the default value. Factory Default interface Technical Support: 1-800-260-1312 International: 00-1-952-941-7600...

  • Page 126: Save Configuration

    Transition Networks SISPM1040-182D 6.29 Save Configuration Save all configurations that you have made in the system. To ensure the all configuration will be saved. Click Save Flash to save the all configuration to the flash memory. Save Configuration interface Technical Support: 1-800-260-1312...

  • Page 127: System Reboot

    Transition Networks SISPM1040-182D 6.30 System Reboot Reboot the switch in software reset. Click Reboot to reboot the system. System Reboot interface Technical Support: 1-800-260-1312 International: 00-1-952-941-7600...

  • Page 128: Troubles Shooting

    Transition Networks SISPM1040-182D Troubles shooting Verify that is using the right power cord/adapter (DC 24-48V), please don’t use the power adapter with DC output higher than 48V, or it may damage this device. Select the proper UTP/STP cable to construct the user network. Use unshielded...

  • Page 129: Appendix A-Rj-45 Pin Assignment

    Transition Networks SISPM1040-182D Appendix A—RJ-45 Pin Assignment RJ-45 Pin Assignments The UTP/STP ports will automatically sense for Fast Ethernet (10Base-T/100Base-TX connections), or Gigabit Ethernet (10Base-T/100Base-TX/1000Base-T connections). Auto MDI/MDIX means that the switch can connect to another switch or workstation without changing straight through or crossover cabling. See the figures below for straight through and crossover cable schematic.
  • Page 130 Transition Networks SISPM1040-182D-LR 10/100Base-TX Cable Schematic The following two figures show the 10/100Base-TX cable schematic. Straight-through cable schematic Cross over cable schematic 10/100/1000Base-TX Pin outs The following figure shows the 10/100/1000 Ethernet RJ-45 pin outs. 10/100/1000Base-TX Cable Schematic Technical Support: 1-800-260-1312...
  • Page 131 Transition Networks SISPM1040-182D-LR Straight through cables schematic Cross over cables schematic Technical Support: 1-800-260-1312 International: 00-1-952-941-7600...

  • Page 132: Pin Assignment Of Poe

    Transition Networks SISPM1040-182D-LR RJ-45 Pin Assignment of PoE With 100BASE-TX/10BASE-T cable, pins 1 and 2 are used for transmitting data, and pins 3 and 6 for receiving data; pins 4, 5, 7 and 8 are used for power supplying. Pin out of Cisco non-802.3af standard PD...
  • Page 133 Transition Networks SISPM1040-182D-LR Pin out of PoE Endspan Hub/Switch Signal / Name TX+/VCC+ TX-/VCC+ TX+/VCC- TX-/VCC- Note ‘+’ and ‘-‘ signs represent the polarity of the wires that make up each wire pair. Before you power PD, please check the RJ-45 connector pin assignment follow IEEE802.3af standard;...

  • Page 134: Appendix B-Command Sets

    Transition Networks SISPM1040-182D Appendix B—Command Sets Commands Set List User EXEC Privileged EXEC Global configuration VLAN database Interface configuration System Commands Set Commands Level Description Example show config Show switch switch>show config configuration show terminal Show console switch#show terminal information...
  • Page 135 Transition Networks SISPM1040-182D-LR ip dhcp Enable DHCP client switch(config)#ip dhcp function of switch show ip Show IP information of switch#show ip switch no ip dhcp Disable DHCP client switch(config)#no ip dhcp function of switch Halt and perform a cold reload...

  • Page 136: Port Commands Set

    Transition Networks SISPM1040-182D-LR ipbinding 192.168.1.1 show dhcpserver Show configuration of switch#show dhcpserver configuration DHCP server configuration show dhcpserver clients Show client entries of switch#show dhcpserver clients DHCP server show dhcpserver ip- Show IP-Binding switch#show dhcpserver ip- binding information of DHCP...
  • Page 137 Transition Networks SISPM1040-182D-LR duplex Use the duplex switch(config)#interface [full | half] configuration fastEthernet 2 command to specify switch(config-if)#duplex full the duplex mode of operation for Fast Ethernet. speed Use the speed switch(config)#interface [10|100|1000|auto] configuration fastEthernet 2 command to specify switch(config-if)#speed 100...
  • Page 138 Transition Networks SISPM1040-182D-LR bandwidth type Set interface ingress switch(config)#interface broadcast-multicast limit frame type to fastEthernet 2 “accept broadcast and switch(config-if)#bandwidth type multicast frame” broadcast-multicast bandwidth type Set interface ingress switch(config)#interface broadcast-only limit frame type to fastEthernet 2 “only accept broadcast switch(config-if)#bandwidth type frame”...

  • Page 139: Trunk Commands Set

    Transition Networks SISPM1040-182D-LR form of this command to disable the port. show interface show interface switch(config)#interface configuration configuration status fastEthernet 2 switch(config-if)#show interface configuration show interface status show interface actual switch(config)#interface status fastEthernet 2 switch(config-if)#show interface status show interface show interface statistic...

  • Page 140: Vlan Commands Set

    Transition Networks SISPM1040-182D-LR list separate by a comma(ex.2, 3, 6) [Workport]: The amount of work ports, this value could not be less than zero or be large than the amount of member ports. aggregator group Assign a static trunk switch(config)#aggregator group [GroupID] [Port-list] group.
  • Page 141 Transition Networks SISPM1040-182D-LR [portbase| 802.1q | mode. gvrp] switch(vlan)#vlanmode 802.1q switch(vlan)#vlanmode gvrp no vlan No VLAN Switch(vlan)#no vlan Ported based VLAN configuration vlan port-based Add new port based switch(vlan)#vlan port-based grpname VALN grpname test grpid 2 port 2-4 [Group Name]...

  • Page 142: Spanning Tree Commands Set

    Transition Networks SISPM1040-182D-LR can’t be applied. trunk-link tag 3-20 vlan 8021q port Assign a hybrid link for switch(vlan)#vlan 8021q port 3 [PortNumber] VLAN by port, if the hybrid-link untag 4 tag 3,6,8 hybrid-link untag [UntaggedVID] port belong to a trunk...
  • Page 143 Transition Networks SISPM1040-182D-LR configuration command to change the interval between messages the spanning tree receives from the root switch. If a switch does not receive a bridge protocol data unit (BPDU) message from the root switch within this interval, it...
  • Page 144 Transition Networks SISPM1040-182D-LR learning states last before the port begins forwarding. stp-path-cost Use the spanning-tree switch(config)#interface [1~200000000] cost interface fastEthernet 2 configuration switch(config-if)#stp-path-cost 20 command to set the path cost for Spanning Tree Protocol (STP) calculations. In the event of a loop,...

  • Page 145: Qos Commands Set

    Transition Networks SISPM1040-182D-LR interface. switch(config-if)#stp-admin-edge True stp-admin-non-stp Admin NonSTP of switch(config)#interface [True|False] STP priority on this fastEthernet 2 interface. switch(config-if)#stp-admin-non- stp False show spanning-tree Displays a summary of switch>show spanning-tree the spanning-tree states. no spanning-tree Disable spanning-tree. switch(config)#no spanning-tree QOS Commands Set...

  • Page 146: Igmp Commands Set

    Transition Networks SISPM1040-182D-LR IGMP Commands Set Commands Level Description Example igmp enable Enable IGMP switch(config)#igmp enable snooping function Igmp-query auto Set IGMP query to switch(config)#Igmp-query auto auto mode Set IGMP query to switch(config)#Igmp-query force Igmp-query force force mode igmp unregister flooding...

  • Page 147: Snmp Commands Set

    Transition Networks SISPM1040-182D-LR show mac-address-table Show static MAC switch#show mac-address-table static address table static show mac-address-table Show filter MAC switch#show mac-address-table filter address table. filter no mac-address-table Remove an entry of switch(config)#interface static hwaddr MAC address table of fastEthernet 2...
  • Page 148 Transition Networks SISPM1040-182D-LR community information and trap-version v1 [Community-string] community string (remove) trap-version Switch(config)# [v1|v2c] no snmp-server host 192.168.1.50 snmpv3 context-name Configure the context switch(config)#snmpv3 context- [Context Name ] name name Test Configure the switch(config)#snmpv3 user snmpv3 user [User Name]...
  • Page 149 Transition Networks SISPM1040-182D-LR [OID] show snmp Show SNMP switch#show snmp configuration no snmp community- Remove the specified switch(config)#no snmp strings [Community] community. community-strings public no snmp-server host Remove the SNMP switch(config)#no snmp-server [Host-address] server host. host 192.168.1.50 no snmpv3 user...

  • Page 150: Port Mirroring Commands Set

    Transition Networks SISPM1040-182D-LR Port Mirroring Commands Set Commands Level Description Example monitor Configure source port switch(config)#interface [RX|TX|Both] of monitor function fastEthernet 2 switch(config-if)#monitor RX monitor rx [Port ID] Set RX destination switch(config)#monitor rx 2 port of monitor function monitor tx...
  • Page 151 Transition Networks SISPM1040-182D-LR [port ID] system server port serverport 1812 global configuration command to change the radius server port 8021x system Use the 802.1x switch(config)# 8021x system accountport system account port accountport 1813 [port ID] global configuration command to change...
  • Page 152 Transition Networks SISPM1040-182D-LR configuration command to set the supplicant timeout. 8021x misc Use the 802.1x misc switch(config)#8021x misc servertimeout [sec.] server timeout global servertimeout 20 configuration command to set the server timeout. 8021x misc maxrequest Use the 802.1x misc switch(config)# 8021x misc...

  • Page 153: Tftp Commands Set

    Transition Networks SISPM1040-182D-LR TFTP Commands Set Commands Level Description Defaults Example backup Save configuration to switch(config)#backup flash:backup_cfg TFTP and need to flash:backup_cfg specify the IP of TFTP server and the file name of image. restore Get configuration from switch(config)#restore flash:restore_cfg...
  • Page 154 Transition Networks SISPM1040-182D-LR [IP address] server IP 192.168.1.5 smtp authentication Enable SMTP switch(config)#smtp authentication authentication smtp account Configure switch(config)#smtp account [account] authentication account John smtp password Configure switch(config)#smtp password [password] authentication 1234 password Configure Rcpt e-mail switch(config)#smtp rcptemail 1 smtp rcptemail...

  • Page 155: Sntp Commands Set

    Transition Networks SISPM1040-182D-LR no event authentication- Disable Authentication switch(config)#no event failure failure event typ authentication-failure no event ring-topology- Disable X-ring switch(config)#no event ring- change topology changed topology-change event type no event systemlog Disable port event for switch(config)#interface system log fastethernet 3...

  • Page 156: X-Ring Commands Set

    Transition Networks SISPM1040-182D-LR sntp daylight-offset Set offset of daylight switch(config)#sntp daylight- [Minute] saving time, if SNTP offset 3 function is inactive, this command can’t be applied. sntp ip Set SNTP server IP, if switch(config)#sntp ip 192.169.1.1 [IP] SNTP function is inactive, this command can’t be...
  • Page 157 Transition Networks SISPM1040-182D-LR [1st Ring Port] [2nd Ring Port Ring Port] ring couplingport Configure Coupling switch(config)#ring couplingport [Coupling Port] Port ring controlport Configure Control Port switch(config)#ring controlport 2 [Control Port] ring homingport Configure Dual switch(config)#ring homingport 3 [Dual Homing Port]...

Table of Contents
