- Page 1 S321-IP Network Controller hardware installation 24-10239-480 Revision F December 2017...
- Page 2 If this document is translated from the original English version by Johnson Controls, all reasonable endeavors will be used to ensure the accuracy of translation. Johnson Controls shall not be liable for any translation errors contained herein or for incidental or consequential damages in connection with the furnishing or use of this translated material.
- Page 3 Declarations of Conformity United States: This equipment, S321-IP, has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 4 Transient protection devices that are installed must not be removed or defeated. Do not connect equipment to an AC power source that is controlled by a switch. The sole use of a class 2 transformer to power the S321-IP would not provide battery standby power.
-
Page 5: Table Of Contents
NPACKING THE QUIPMENT Inspect the S321-IP shipping containers as soon as you receive them, with the delivery agent present. If a container is damaged, open it immediately, inspect the contents, and have the agent make note on the shipping document. Check the purchase order against the packing slips to ensure the order is complete. -
Page 6: Mounting
Hardware Installation 24-10239-480 Rev. F OUNTING You can mount the S321-IP controller on a flat surface, DIN rail, or in a Johnson Controls’ approved enclosure (for example: S300-DIN). For information on mounting the S321-IP in an enclosure, refer to the manual provided with the enclosure. - Page 7 Lithium Battery The S321-IP contains a lithium battery that is used for realtime clock backup. The lithium battery is shipped from the factory charged and operational.
- Page 8 To replace the lithium battery: 1. Disconnect the 24 VDC power from the S321-IP. 2. Unscrew and open the plastic enclosure. 3. With a narrow (1/8 in.) blade, carefully pry up the battery until a portion of the battery is out of the plastic holder.
-
Page 9: Description Of Signals
S321-IP Network Controller Hardware Installation 24-10239-480 Rev. F ESCRIPTION OF IGNALS READER READER POWER RDR n RDR n RDR n READER n RJ45 connector PANEL RDR n RDR n RDR n STRIKE SHUNT... - Page 10 S321-IP Network Controller Hardware Installation 24-10239-480 Rev. F Wiegand Input Description of Signals – DATA0 and DATA1 from each reader, complying with the Wiegand interface specification. Reference – These signals are referenced to logic ground (COM). Protection – Each signal has a 6 V transient voltage suppressor between it and COM.
- Page 11 Protection – There is a 750 mA PTC re-settable fuse. Network Connection RJ45 connector – Use this connector to connect the S321-IP to the network. The S321-IP communicates with the P2000 server via 10/ 100Base-T Ethernet, using the TCP/IP protocol.
- Page 12 500 feet (152 m) unshielded pair, 22 AWG to each detector When wiring more than one S321-IP, use the same type of hook-up wire and communications wire to connect subsequent controllers. Refer to reader manufacturer’s recommendations when using UL-listed readers. In the absence of other recommendations, consider these cable specifications taking into account the number of conductors that will actually be needed for installation.
-
Page 13: Cable Requirements
Cable Requirements on page 7) are not guaranteed, when the resistor value is less than 500 ohms, or when all the inputs on an S321-IP are not wired with the same resistor values. • To use the Calibrate with Resistor method, install a resistor matching the resistors wired to a 4-state input across the CAL RESISTOR contacts, and issue a “Calibrate with Resistor”... -
Page 14: Basic Commissioning
: Functionality of the browser’s Forward, Back, and Refresh buttons may differ depending on the type of browser and the page being displayed. Configuration Outline Once the S321-IP and all peripheral devices are installed, you are ready to configure the S321-IP using the controller’s embedded web interface. Figure 1 shows a flowchart for configuring an S321-IP for use as a part of the P2000 Security Management System (SMS). - Page 15 Software User Manual for instructions. settings on the Configuration page (Network menu). Note: Do not use local user interface to configure the device. You have completed the basic commissioning of an S321-IP controller. Figure 1: S321-IP Basic Commissioning Flowchart: S321-IP with P2000 SMS...
- Page 16 Power off the S321-IP. Set DIP switches #6 and #8 to ON (up). Power Does a DHCP on the S321-IP. Turn DIP switch #6 to server exist on OFF (down). the network? Log on to the S321-IP user interface using the default static IP address of 192.168.0.1 or the default controller...
- Page 17 1. Find out the controller’s Media Access Control (MAC) address. It is listed on the sticker on the left side as well as top of the S321-IP. You need to match the MAC address to the Hardware Address listed on the utility’s user interface.
- Page 18 Programs)>Lantronix>DeviceInstaller>DeviceInstaller to launch the DeviceInstaller software utility. 4. When DeviceInstaller launches, the utility automatically searches for all S321-IP controllers on the network and lists them in the right pane. 5. Locate the S321-IP controller’s MAC address under the Hardware Address column.
- Page 19 Hardware Installation 24-10239-480 Rev. F Configuring and Using a Static IP Address Use the static IP address if the S321-IP is not connected to a DHCP- enabled network. To use a Static IP Address: 1. With the S321-IP unit powered off, adjust the DIP settings for Static IP commissioning as follows: turn switch #6 and switch #8 up (ON).
-
Page 20: The S321-Ip User Interface
3. Click OK. The Main menu options appear. To log off from the S321-IP controller’s user interface: 1. To log off from the S321-IP user interface, click the Logout link at the upper-right corner of any page or simply close the browser window. - Page 21 S321-IP Network Controller Hardware Installation 24-10239-480 Rev. F Logout Link – Click to log out of the S321-IP user interface. Menu Bar Menu Options Logout Link See the diagram below for the Main menu navigation map: Main Database Network System...
- Page 22 S321-IP Network Controller Hardware Installation 24-10239-480 Rev. F See the diagram below for the Database menu navigation map: Security Level Access and Shunt Time Anti Passback Assign Schedules Report Strike/ Reader Status Debounce Time Badge ID/PIN Output Point Badge/Reader Link...
-
Page 23: Technical Specifications
S321-IP Network Controller Hardware Installation 24-10239-480 Rev. F See the diagram below for the Network menu navigation map: Main Database Network SNMP HTTP SNMP Agent DHCP Enable Certificate Timeout FTP Enable Enable IP Address Private Key System Username Maximum Bytes... -
Page 24: Maintenance
Active (ACT): On during active network communication to and from the controller. LINK and ACT are located near the RJ45 connector. Routine Maintenance Perform the following routine maintenance on the S321-IP: 1. Periodically check the continuity of the grounding circuit. 2. Perform operational testing monthly (see Testing Procedure page 21). - Page 25 4. If the controller is connected to the network, verify that the “LINK LED” is on. 5. Present a valid card to each reader connected to the S321-IP reader interface and then verify that access is granted (green lamp lights).
- Page 26 S321-IP Network Controller Hardware Installation 24-10239-480 Rev. F...
- Page 27 Security Solutions (805) 522-5555 www.johnsoncontrols.com We welcome your comments at BE-techpubs-security@jci.com.
