Johnson Controls S321-IP Hardware Installation page 16

S321-IP Network Controller
24-10239-480 Rev. F
Mount, wire, and power the S321-IP
controller.
Does a DHCP
server exist on
the network?
Install the Lantronix® DeviceInstaller
software utility. Use this utility to
determine which IP address the DHCP
server assigned to the S321-IP.
Log on to the S321-IP user interface.
When logging on, use the IP address
assigned by the DHCP server or the
default controller name "s321ip"
(requires a DNS server on the network).
Configure the S321-IP's input/output
(I/O) point settings for two readers, one
reader with general purpose I/Os, or no
readers (all general purpose I/Os).
Add cardholder badges to the
database. If you use FTP, you can
import badge data from a spreadsheet
or from another panel. If you use the
badge enrollment feature, add names
to the cardholder records once the
badges are enrolled in the system.
You have completed the basic
commissioning of an S321-IP
controller.
Figure 2: Basic Commissioning Flowchart: Stand-alone S321-IP
No
Yes
12
Hardware Installation
Power off the S321-IP. Set DIP
switches #6 and #8 to ON (up). Power
on the S321-IP. Turn DIP switch #6 to
OFF (down).
Log on to the S321-IP user interface
using the default static IP address of
192.168.0.1 or the default controller
name "s321ip" (when DNS service is
running).
Assign a static IP address, network
mask, and gateway to the S321-IP.
In systems with the DNS server,
assign a unique name to the
controller.
Configure the following network
protocol settings, as needed: FTP,
SSL, and HTTP.
Set the current date and time at the
S321-IP controller.
