Figure 2. T400 Housing Terminal Strips - ADTRAN T200 Installation And Maintenance Manual

Inside the housing are two terminal strips (TS1 and
TS2), shown in Figure 2 for connecting to the
network, the CPE, and to an external power source if
used. All wiring connections should be made
according to the label inside the unit cover (Figure 2).
Local power connects to terminals 17 (-48VR) and 35
(-48V) of TS1. A grounding lug is provided for frame
ground connections.
CAUTION
Ensure a frame ground connection is securely
made at ground lug (P1).
FRAME GND
DDST
RJ
ORANGE 55
T
DT
R
BLUE 49
BROWN 5
T
DR
R
GREY 15
41
T
R
47
7
T
R
13
When using plug-in cards that only require one pair (i.e., ADTRAN H2TU-R, P/N 1221026LX), use one
set of loop connection screws only (See plug in practice for pin numbers).
2
SW1
27 1, 11, 27
USE COPPER CONDUCTORS ONLY
CAUTION
RISK OF ELECTRICAL SHOCK
MAXIMUM VOLTAGES UP TO
-200VDC MAY BE PRESENT
HDSL HTU-R,
& H2TU-R
HDSL FNID
RJ RJ
GREEN 55 GREEN
DS1 FROM
T
CUSTOMER
R
RED 49 RED
ORANGE 5 ORANGE
T DS1 TO
CUSTOMER
R
BLUE 15 BLUE
41
T HDSL NTWK
LOOP 2
R
47
7 HDSL NTWK
T
LOOP 1
R
13

Figure 2. T400 Housing Terminal Strips

61242034L3-5, Issue 2
Ground Switch
Slide switch SW1 selects a ground connection to pins
1, 11, and 27 or to pin 27 only.
Rear Panel
The rear panel of the T400 Housing contains a slot for
either an RJ-48C jack (factory installed and wired for
HDSL) or an RJ-48X jack (shipped loose) for CPE
connections. The rear panel also has portals for
network, customer, and power wiring plus a ground
wire. See Figure 3.
P2
7 13 41 47 17 35 15
TS2
Pc1 94V-0
ISDN TRI-R
RJ
55 GREEN 55
DS1 FROM TO / FROM
T T
CUSTOMER CUSTOMER
R R
49 RED 49
5 5
T DS1 TO T
NC
CUSTOMER
R R
15 15
41 41
TO / FROM
T T
NC
NETWORK
R R
47 47
7 7
T T
HDSL NTWK NC
R R
13 13
5 49 55
TS1
TRDDS-R
RJ
ORANGE 55
FROM
T
CUSTOMER
R
BLUE 49
BROWN 5 TO
T
CUSTOMER
R
GREY 15
41
TO / FROM
T
NETWORK
R
47
7
T
NC
R
13
61242034L3-5B
