5.5.3

Pulse mode (for Phoenix / alpha Q only)

This signal switches between standard and pulse welding in MIG/MAG processes.
X5/5
Signal active
Signal not active
5.5.4

superPuls (only Phoenix / alpha Q)

This signal switches on the superPuls mode.
X4/5
Signal active
Signal not active
1)
Use of this signal has to be enabled with the EWM Config Tool first.
5.5.5

Lift arc (only Phoenix / alpha Q MM)

This signal switches ignition to lift arc mode.
X5/5
Signal active
Signal not active
1)
Use of this signal has to be enabled with the EWM Config Tool first.
The lift arc start mode has to be selected in the Expert constants of the JOB.
5.5.6

Pulse modes (for Tetrix / forceTig only)

These signals allow the different pulse modes to be actuated in different processes. The process (DC or
AC) determines the pre-selection of the possible actuations. An actuation that is not applicable is
automatically overridden.
X5/5
Signal not
active
Signal active Signal not
Signal not
active
Signal active Signal active DC
1)
Must be supported by the welding system.
5.5.7

Reset error

This allows an existing system error to be reset. The signal must be flanked in accordance with the
actuation logic selected. A continuous signal does not cause any error suppression or automatic reset.
X4/8
Signal not
active
Signal outline
from not active
to active
In Phoenix / alpha Q and Tetrix / forceTig a distinction is drawn between error messages that can be
reset and those that cannot be reset.
099-000769-EW501
29.06.2015
Operating mode
Pulse welding activated.
Standard welding activated.
Operating mode
1)
superPuls enabled.
superPuls disabled.
Operating mode
1)
Lift arc enabled.
Lift arc disabled.
X4/5 Possible process
Signal not DC, AC
active
DC, AC
active
Signal active AC
Operating mode
No reset of an error
An existing system error is reset.
Design and function
Standard signals for free actuation
Operating mode
No pulse mode active
superPuls is active; pulsing alternates
between main and secondary program
(max. 50 Hz)
AC special pulsing (AC pulsing up to max.
50 Hz with a direct current portion in the
secondary phase)
Metallurgical DC pulsing (up to approx. 15
(1)
kHz)
17
