Overview of plug (jumper) configurations

Welding data monitoring signals

7.6 Welding data monitoring signals
Relay outputs (X8, 12 pole)
Pin no.: Function / Meaning
X8/1 Welding voltage
monitoring
(Phoenix / alpha Q),
process active (Tetrix /
X8/2
forceTig)
X8/3
X8/4 Welding current
monitoring,
main current signal
active (Tetrix / forceTig)
X8/5
X8/6
X8/7 Wire speed monitoring
or workpiece detection
(Phoenix / alpha Q)
Workpiece detection
X8/8
(Tetrix / forceTig)
X8/9
X8/10 Motor current
monitoring
(Phoenix / alpha Q)
I>0 auxiliary process
(Tetrix / forceTig)
X8/11
X8/12
7.7

Analogue output signals

PIN no. Function/Meaning
X11/1 Actual welding voltage value Analogue output
X11/2 0 V
X11/3 Actual welding current value Analogue output
X11/4 0 V
42
Signal form for Standardisation / logic
RINT X12
Relay output 5 2-3 ->
2-3 ->
Relay output 5 1-3 ->
1-3 ->
Relay output 5
Relay output 6 5-6 ->
5-6 ->
Relay output 6 4-6 ->
4-6 ->
Relay output 6
Relay output 7 8-9 ->
8-9 ->
Relay output 7 7-9 ->
7-9 ->
Relay output 7
Relay output 8 11-12 -> motor current OK (Phoenix /
11-12 -> I = 0 auxiliary process (Tetrix /
Relay output 8 10-12 -> motor current error (Phoenix /
10-12 -> I = 0 auxiliary process (Tetrix /
Relay output 8
Signal form for RINT X12 Standardisation logic
welding voltage OK (Phoenix /
alpha Q)
end of process (Tetrix / forceTig)
welding voltage error (Phoenix /
alpha Q)
process active (Tetrix / forceTig)
welding current OK (Phoenix /
alpha Q)
main current phase not active
(Tetrix / forceTig)
welding current error (Phoenix /
alpha Q)
main current phase active (Tetrix /
forceTig)
wire speed OK (Phoenix / alpha Q)
electrode/cold wire has not been
touched (Tetrix / forceTig)
wire speed error (Phoenix /
alpha Q)
electrode/cold wire touched
workpiece (Tetrix / forceTig)
alpha Q)
forceTig)
alpha Q)
forceTig)
0...10 V
0...100 V welding voltage
0...10 V
0...100 V welding current
