Optical Unit Management Screen
FOU port number
Optical loss between MU
and RU, the value is over
16dB when MU and RU are
not connected well
Note: MU transmit optical power is -4~-2dBm.
RF Unit Management Screen
Band and Remark
information
Slot number
ENU STATUS: 1-0-1
USER MANUAL FOR COMFLEX-6Q00 5W
Optical power alarm. Alarm is
triggered when optical power is
less than -10dBm. Indicator will
turn from green to red.
Figure 43: MU Device - Optical Unit
RF parameter
Figure 44: MU Device - RF Unit
Copyright - refer to title page
Commissioning
status
Click here to ON/OFF RF switch
and modify attenuator
Click here to enable/disable
optical RX/TX alarm
Downlink input
power overdrive
alarm
