EQUIPMENT CONSTITUTION

MU consists of the following parts:
Module Description
Master Unit Chassis includes eight slots for RF Unit, two slots for Fiber Optical
MU01-RACK
Unit, and one slot for Power Supply Unit.
iDAS Master Unit Power Supply Unit (PSU) converts the input voltage into stable
MU01-PSU
DC to supply power for other modules of Master Unit.
Master Unit Fiber Optical Unit (FOU) completes optical signal and RF signal
MU01-FOU conversion. One FOU has four optical ports, which means each FOU can support
up to four RUs.
Master Unit RF Unit completes separation and combination of uplink and downlink
MU01-RFU
signal with independent gain control, supports either simplex or duplex.
RU consists of the following parts:
Module Description
Medium Power Remote Unit (5W); A compact and slim design which supports 3
MRU01-6Q00
bands, including 600MHz, WCS and TDD 2500MHz bands.
Remote Unit Power Supply Unit (PSU) converts the input AC voltage into stable
LRU01-PSU DC, to supply power for Remote Unit. It can be installed on RU or on wall beside
RU.
ENU STATUS: 1-0-1
USER MANUAL FOR COMFLEX-6Q00 5W
Table 1: MU Components
Table 2: RU Components
