Figure 4 Locating the controller serial number
1. Controller serial number (SN: SGxxxxxxxx)
Installation precautions
Static electricity can severely damage the electronic components on the controller. When
handling and installing the controller, follow these procedures to avoid damage from static
electricity:
Handle the controller by its bulkhead or edges and avoid touching the components and
the circuitry on the board.
When installing the controller, equalize any static charge difference between your body
and the switch by wearing a grounding wrist strap and attaching it to the metal body of
the switch, or by frequently touching the metal body of the switch.
For safe operation, proper switch cooling, and reduction of electromagnetic emissions, ensure
that a slot cover is installed on any unused controller slot. For safety, be sure that no more
than one slot is uncovered when the switch is powered on.
The temperature specifications of the controller must be followed.
Environmental specifications
Temperature
Relative humidity (non-condensing)
Maximum altitude
1
The SSD has a maximum operational wet bulb temperature of 35°C (95°F).
2
The SSD has a maximum non-operational wet bulb temperature of 40°C (104°F).
Other documentation
For information on configuring and managing the controller, see the MSM Controllers Configuration
Guide.
6
Preparing for installation
1
Operating
0°C to 45°C (32°F to 1 13°F)
15% to 95% at 40°C (104°F)
3.0 km (10,000 ft)
Non-Operating
-40°C to 70°C (-40°F to 158°F)
1
15% to 90% at 65°C (149°F)
4.6 km (15,000 ft)
2
