USER NOTE: EDG-4100W Series
EDG-4100W
1-Port RS-232 to WLAN Data Gateway Embedded Module
EDG-4110W
1-Port RS-422/485 to WLAN Data Gateway Embedded Module
EDG-4100WDK
EDG-4100W, EDG-4110W development kits
User Note
Copyright
The documentation and the software included with this product are copyrighted 2005 by
Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make
improvements in the products described in this manual at any time without notice. No part of this
manual may be reproduced, copied, translated or transmitted in any form or by any means without
the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended
to be accurate and reliable. However, Advantech Co., Ltd. assumes no responsibility for its use,
nor for any infringements of the rights of third parties, which may result from its use.
Acknowledgements
Intel and Pentium are trademarks of Intel Corporation. Microsoft Windows and MS-DOS are
registered trademarks of Microsoft Corp. All other product names or trademarks are properties of
their respective owners.
Part No. 2003410000 1st Edition
Printed in Taiwan, November 2005
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that each of its products will be free from
defects in materials and workmanship for two years from the date of purchase.
This warranty does not apply to any products which have been repaired or altered by persons
other than repair personnel authorized by Advantech, or which have been subject to misuse,
abuse, accident or improper installation. Advantech assumes no liability under the terms of this
warranty as a consequence of such events.
Because of Advantech's high quality-control standards and rigorous testing, most of our
customers never need to use our repair service. If an Advantech product is defective, it will be
repaired or replaced at no charge during the warranty period. For out-of-warranty repairs, you will
be billed according to the cost of replacement materials, service time and freight. Please consult
your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU speed,
Advantech products used, other hardware and software used, etc.) Note anything abnormal and
list any onscreen messages you get when the problem occurs.
1
EDG-4100W Series User Note
Advertisement
Table of Contents
Related Manuals for Advantech EDG-4100 Series
Summary of Contents for Advantech EDG-4100 Series
- Page 1 Because of Advantech’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Advantech product is defective, it will be repaired or replaced at no charge during the warranty period. For out-of-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.
- Page 2 This product has passed the pretest of CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This kind of cable is available from Advantech. Please contact your local supplier for ordering information. FCC Class B This equipment has passed the pretest of FCC and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
-
Page 3: Introduction Description
Introduction Description EDG-4100W and EDG-4110W are fast and cost-effective 802.11b wireless networking-enabled board modules. EDG-4100W provides one RS-232 port, while EDG-4110W provides one RS-422/485 port. The modules enable nearly any device to communicate with 802.11b wireless LAN and shared networks, and they allow those devices to be remotely monitored, managed, and controlled. -
Page 4: Specifications
Specifications • Protocol: TCP/IP • Network: 802.11b • Serial Ports: 1 • Serial Type: RS-232 (EDG-4100W) RS-422/485 (EDG-4110W) • Transmission Speeds: 50 bps ~ 230 kbps • Parity Bits: Odd, even, none, space, mark • Data Bits: 5, 6, 7, 8 •... - Page 5 LED (only on EDG-4100WDK) There is an LED status display located on the EDG-4100WDK. Color Status Description Work Green Blinking (1 time/sec) Not working WLAN Data being transmitted or received No data action Signal1(Green) Red/Green OFF/OFF 0 ~ 20% signal strength Signal2(Red) Red/Green OFF/Half-On...
- Page 6 Dimensions EDG-4100W Series User Note...
- Page 7 Connectors EDG-4100W/4110W have 2 connectors (CON2 and CON3), and the pin definitions are as follows: EDG-4100W Series User Note...
- Page 8 CON3 EDG-4100W EDG-4110W CON2 EDG-4100W/10W Description Description Description SOUT LED SIN LED WORK LED WLAN LED SIGNAL1 LED SIGNAL2 LED HW reset HW reset MODE MODE The EDG-4100WDK has 2 connectors (Serial DB9, power and DI/O), and the pin definition is as follows: DB9 Male RS-232...
- Page 9 Flexible Design and Easy-to-Manage S/W Support EDG-4100W and EDG-4110W have been designed to be very flexible and easy-to-use to assist OEM/ODM customers. EDG-4100W and EDG-4110W can easily fit to almost any serial device available. EDG-4100 provides pin headers to connect the Wireless LAN, DI/O, power, and RS-232/422/485 onto the customer’s own boards.
-
Page 10: Troubleshooting
EDG-4100W/EDG-4110W. If you are still having problems after reading this chapter, contact your dealer, or e-mail Advantech support for help. 1. Check the WORK LED. If it is off, make sure the EDG device power cable is plugged in, and make sure the input voltage is set to +5V 2.
