Advantech ASMB-BMC Startup Manual

ASMB-BMC
BMC Module IPMI 2.0
Startup Manual
Packing List
Before you begin installing your card, please make sure that
the following items have been shipped:
1. ASMB-BMC module x 1
2. 2-year quality warranty card x 1
3. Startup manual x 1
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.com/suppot/
This manual is for the ASMB-BMC Series.
Part No. 20060BMC00
Print in China
P/N: 2190000902
P/N: 20060BMC00
1st Edition
July 2013
Specifications
Standard Functions
• ASMB-BMC is compliant with Intel IPMI 2.0 specification
via IPMI connector on ASMB series server boards
• Support list: ASMB-781G4, ASMB-820I, ASMB-920IR,
ASMB-822I
Mechanical
• Dimensions: 36 mm x 15 mm
• Power supply type: 3.3 V, 5 V, 5 VSB
• Power requirements: 3.3 VSB
• Operating temperature: 0 ~ 60° C
• Operating humidity: 40° C @ 85% RH, Non-Condensing
• Storage temperature: -40 ~ 85° C
• Storage humidity: 60° C @ 95% RH, Non-Condensing
• Weight: 0.01 kg
ASMB-BMC Startup Manual 1
