Page 6: Operation
Button Function Standby mode Power on the matrix switcher MUTE Turn off output’s video and audio STATUS Preset output status SAVE Save current mapping mode PRESET Preset mapping mode DEFAULT EDID Begin default EDID selection LEARN EDID Begin EDID learning from one output CLEAR Clear the previous IR operation procedure TAKE... -
Page 7: Mute Output
Operation Procedure 7-Segment LED Mute Output Mute + A~D(Output 1~4) + Take 1. Press “MUTE” button Ex: Mute Output 3 2. Press number key “C” to select Output 3 3.Press “TAKE” button Output Status Status + A~D(Output 1~4) + Take 1.Press “STATUS”... - Page 8 Power ON/ Standby mode Control SW via RS-232 COM Port Selection I/O Routing Button EDID Button Rename I/O Button Network Setting & Default Reset Button Firmware Update Button...
