Martin T-Rex User Manual page 2

Measurements are expressed in millimeters.
1 Lamp access
2 Focus adjustment
3 Mounting bracket
4 Swivel locks
5 Clamp hole
6 Air vent
7 AC input & main fuse
8 Microphone
© 2001 Martin Professional A/S, Denmark.
All rights reserved. No part of this manual may be
reproduced, in any form or by any means, without
permission in writing from Martin Professional A/S,
Denmark.
Printed in China.
P/N 35000101, Rev. B
490
164
1
2
3
4
5
6
190
225
7 8
www.audiovias.com
285
