Unpacking - Martin T-Rex User Manual

• Keep all combustible materials (for example fabric, wood, paper) at least 0.3
meters (12 inches) away from the fixture. Keep flammable materials well away
from the fixture.
• Do not illuminate surfaces within 0.1 meters (4 inches) of the fixture.
• Provide a minimum clearance of 1 meter (39 inches) around fans and air vents.
• Replace the lamp if it becomes defective or worn out, or before usage exceeds the
maximum service life. When replacing the lamp, allow the fixture to cool for at
least 5 minutes before opening the fixture or removing the lamp. It can take up to
15 minutes for the fixture to cool completely.
• Never place filters or other materials over the lens or mirrors.
• The exterior of the fixture can reach temperatures up to 60° C (140° F). Allow the
fixture to cool for at least 5 minutes before handling.
• Do not operate the fixture if the ambient temperature (Ta) exceeds 40° C (104°
F).
• Do not stare directly into the light.
P r e v en ti ng i nj ur i e s due to fal ls
• When suspending the fixture above ground level, verify that the structure can
hold at least 10 times the weight of all installed devices.
• Verify that all external covers and rigging hardware are securely fastened and use
an approved means of secondary attachment such as a safety cable.
• Block access below the work area whenever installing or removing the fixture.
U N P A C K I N G
The packing material is carefully designed to protect the fixture during shipment
- always use it to transport the fixture.
The T-Rex comes with:
• Mounting bracket
• 1.5-meter, 3-wire IEC power cable
• User manual
Introduction
