- Page 2 Martin M-Play™ Portability without compromises Reference guide...
- Page 3 Martin M-Play 48 pads and 12 faders with direct access to playbacks Rugged aluminum design for durability DMX port expandable to 65,000 channels...
- Page 4 48 velocity-controlled pads let you access playbacks and function keys of any kind o One DMX 512 universe for direct control of any compatible DMX device o Plug-&-Play wing for M-PC and M-Series consoles o The control surface revolution continues!
- Page 5 Perfect companion to M-PC o Martin M-Play is a USB wing for M-PC o Connects to M-PC for immediate output of one Universe o Combines with M-DMX for up to 4 Universes without the need of a Martin One-Key o Can be used with or without its M-Touch...
- Page 6 M-Play for Console Expansion o Martin M-Play can also be used as a wing/expansion for any M-Series console o When connected to a console, M-Play provides additional faders and buttons o Multiple M-Plays can be connected to the same console...
- Page 7 Innovative touch surface...
- Page 8 Force Touch o Force Touch controls are unique for a lighting Controller o Velocity sensitive pads control the intensity of effects based on touch pressure o Buttons are backlit with colored LED's for visual feedback o Force Touch features enable amazing dynamic effects, for example: o A strobe effect could have a different intensity based on the force applied to the button...
- Page 9 Force Faders o Force Faders is a new innovation in faders using Force Sensitive Resistor (FSR) technology o Provides instant, accurate and reliable intensity control at your fingertips o A column of LEDs provide visual feedback of the fade levels o Force Faders allows for unique control possibilities: o Gradual or immediate level transitions as...
- Page 10 Martin M-Play Interface o 12 Force Fade for playback control with LED visual feedback o 24 Playback Force Touch velocity pad o 24 additional Playback Force Touch velocity pad, optionally as Function keys or a Numerical Keypad o Dual bank system (2 X 24) with 2 selectors...
- Page 11 Interface details Bank Bank change 12 ForceFaders change and and indicator playback level indicator control Beat trigger Main Go section 12 ForceTouch 24 ForceTouch playback 12 ForceTouch playback function keys or numerical playback buttons buttons keypad...
- Page 12 Martin M-Play features o Rugged aluminium shell with composite inserts o DMX port: 1 x 5-pin locking XLR (on left side) o Windows PC connection/requirement: 1 x USB 2.0 o VESA 75 and 100mm mounting holes for easy attachment to stands or the M6 screen mount kit o Kensington-Lock security slot o Optional 19”...
- Page 13 No dirt or dust can impact the performance of the Martin M-Play o Easy to clean by wiping down the surface o Ideal solution for challenging environments like clubs and bars...
- Page 14 Simplicity is Key o No complex MIDI setup o MIDI devices can be difficult to configure o MIDI Configuration requires extensive knowledge and time for setup o Martin M-Play is a simple and powerful Plug&Play solution for M-Series...
- Page 15 1…2… Go! o Connectors on the Martin M-Play were conveniently placed on the left side to allow an M-Touch on the right side without obstructions o The XLR 5-pin connector will send 512 channels of DMX directly to any compatible...
- Page 16 M-Play and M-Touch o 68 playbacks o Editing keys o 22 ForceFaders o Main Go o 68 ForceTouch buttons o Beat Trigger o 3 independent banks o 2 DMX Output o 4 ForceFaders encoders o Opposite connectors...
- Page 17 M-Play and M-Touch...
- Page 18 M-Touch + M-Play = M6 Functionality...
- Page 19 DMX output chart This chart shows the number of DMX out when M-Play is used with M-PC software. M-Play(s) M-Touch M-Play M-Touch(s) M-Play M-PC Dongle alone M-DMX(s) # of DMX universe Up to 4 64 or 128 Art-Net and sACN 64 or 128 output...
- Page 20 When Size Matters o The dimensions of the Martin M-Play are perfect. o It is small enough to fit in a computer bag or backpack and large enough to be comfortable to work with o The control surface will fit perfectly in front of a laptop or tablet o Length: 394 mm (15.5 in)
- Page 21 Accessories and Packaging o Custom designed tangle free USB cable (1.5m / 4.9 ft.)
- Page 22 Ordering information o Martin M-Play P/N: 90737030 o Optional 19” bracket: 91611690...
- Page 23 Rugged aluminum design for durability o DMX port expandable to 65,000 channels o 24 assignable function keys o Flexible dual bank system o Plug-&-Play wing for M-PC and M-Series consoles o Innovative control surface like no other lighting console...
- Page 24 Thank you for watching! It’s time to Play!
