Information about the device

Device description
The device serves the purpose of cooling the room air. It further
filters and dehumidifies the air thus creating an agreeable room
climate.
The unit cools the room air by withdrawing warmth. The
absorbed warmth is emitted to the outside via the exhaust air
hose; cooled air is fed to the installation site by means of a fan.
Accumulating condensate drips from the evaporator onto the hot
condenser, there it evaporates and then is transported to the
outside via the exhaust air hose.
In ventilation mode the device provides the opportunity of air
circulation without cooling effect.
In dehumidification mode moisture is withdrawn from the air.
The device operates fully automatically and features a variety of
further options. The device can, for instance, be switched on or
off automatically with time delay via the timer function.
Operation of the device is possible either via the control panel at
the device or via the supplied infrared remote control.
The device was designed for universal and flexible application.
Due to its compact dimensions it can be easily transported and
used in all interior spaces.
Device depiction
1
2
3
4
5
EN
8
4
9
8
No. Designation
1 Exhaust air hose storage compartment
2 Control panel
3 Remote control receiver
4 Transport handle
5 Water funnel
6 Air outlet
7 Wheels
8 Air inlet with air filter
6
9 Cable storage compartment
10 Air inlet with air filter
11 Exhaust air hose connection
12 Air inlet with air filter
13 Condensate outlet with sealing cap and rubber stopper
14 Remote control
7
local air conditioner PAC 3500 X
ON/OFF
14
SPEED UP
TIMER DOWN
SLEEP
MODE
10
11
12
13
5
