- Page 1 PAC 3500 X OPERATING MANUAL LOCAL AIR CONDITIONER...
-
Page 2: Table Of Contents
• Check accessories and connection parts for possible Follow the manual damage prior to every use of the device. Do not use any Information marked with this symbol indicates that the defective devices or device parts. operating manual must be observed. local air conditioner PAC 3500 X... - Page 3 Non-observance renders all claims for liability • Please note that the refrigerant is odourless. and guarantee null and void. • Only install the device in compliance with the national installation regulations. • Observe the national gas regulations. local air conditioner PAC 3500 X...
- Page 4 2. In an emergency, disconnect the device from the mains feed-in: Hold onto the mains plug while pulling the power cable out of the mains socket. 3. Do not reconnect a defective device to the mains. local air conditioner PAC 3500 X...
-
Page 5: Information About The Device
Air inlet with air filter Cable storage compartment 10 Air inlet with air filter 11 Exhaust air hose connection 12 Air inlet with air filter 13 Condensate outlet with sealing cap and rubber stopper 14 Remote control local air conditioner PAC 3500 X... -
Page 6: Transport And Storage
• Before restarting the device, check the condition of the power cable. If there are doubts as to the sound condition, contact the customer service. • Only position the device in rooms where potentially leaking refrigerant cannot accumulate. local air conditioner PAC 3500 X... - Page 7 4 air filters at the air inlets (8, 10, 12). 4. Connect the exhaust air hose to the air outlet at the rear of the device. Connecting the exhaust air hose 1. Loosen and remove the screw of the sliding cover. local air conditioner PAC 3500 X...
- Page 8 • The dimensions of the exhaust air hose were especially made to fit the device. Do not replace or extend the hose, for it could cause a malfunction. local air conditioner PAC 3500 X...
-
Page 9: Operation
Setting the target temperature for cooling between 18 °C and 32 °C 23 Increase value button 24 Sleep LED Night mode indication 25 SLEEP button Switching night mode on and off 26 SPEED button Setting the fan speed local air conditioner PAC 3500 X... - Page 10 The LEDs for automatic operation (19), cooling (19), fan speed (27) and possibly compressor operation (17) are illuminated. When combining automatic operation and ventilation, the desired fan speed may be set using the SPEED button (26). local air conditioner PAC 3500 X...
- Page 11 2. Press the SPEED button (26) to set the desired fan speed. ð The fan speed LED (27) indicates the selected fan stage. ð The ventilation LED (19) will be illuminated to indicate ventilation mode. local air conditioner PAC 3500 X...
- Page 12 ð The timer setting equals the desired number of hours. ð After the predefined time, the device switches itself off. Notes regarding automatic switch-off: • Pressing the ON/OFF button (16) deactivates the automatic switch-off function. local air conditioner PAC 3500 X...
-
Page 13: Errors And Faults
Disconnect the device from the mains and let it cool down for approx. 10 minutes before If both errors occur simultaneously, the device displays the error reconnecting it. codes alternately. local air conditioner PAC 3500 X... -
Page 14: Maintenance
11. Date: ........12. Date: ........Signature: ........ Signature: ......... Signature: ......... Signature: ......... 13. Date: ......... 14. Date: ........15. Date: ........16. Date: ........Signature: ........ Signature: ......... Signature: ......... Signature: ......... local air conditioner PAC 3500 X... - Page 15 2. Clean the filter using a slightly damp, soft, lint-free cloth. If the filter is heavily contaminated, clean it with warm water mixed with a neutral cleaning agent. 3. Allow the filter to dry completely. Do not insert a wet filter into the device! local air conditioner PAC 3500 X...
- Page 16 • Reconnect the device to the mains. If you do not intend to use the device for a considerable time: • Store the device according to the Storage chapter. 3. Drain the condensate. local air conditioner PAC 3500 X...
-
Page 17: Technical Annex
Minimum distance to walls and other objects: top (A): 50 cm rear (B): 50 cm sides (C): 50 cm front (D): 50 cm Weight 26 kg Remote control batteries Type LR03 / AAA – 1.5 V (2 pcs.) local air conditioner PAC 3500 X... - Page 18 Circuit diagram local air conditioner PAC 3500 X...
- Page 19 Overview and lists of spare parts Note: The position numbers of the spare parts differ from those describing the positions of other parts mentioned in this operating manual. local air conditioner PAC 3500 X...
- Page 20 144C SLIDE WINDOW KIT C 120A VERTICAL LOUVER A PROTECTION BOX FOR Φ50 CAPACITOR 120B VERTICAL LOUVER B PROTECTION BOX (TOP) FOR CAPACITOR CONNECTING ROD FOR VERTICAL LOUVER PROTECTION BOX (BOTTOM) FOR CAPACITOR FLOAT FOR WATER CASE local air conditioner PAC 3500 X...
- Page 21 FOAM FOR ACCUMULATOR(DOWN) SEAL FOAM FOR AIR OUTLET SEAL FOAM FOR DOWN FUNNEL (A) SEAL FOAM FOR TUBE SEAL FOAM FOR DOWN FUNNEL (B) SEAL FOAM POLYFOAM FOR 4-WAY VALVE SEAL FOAM FOR BOTTOM BASE local air conditioner PAC 3500 X...
-
Page 22: Disposal
Directive 2006/66/EC of the European Parliament and of the Council of 6 September 2006 on batteries and accumulators. Please dispose of batteries and accumulators according to the relevant legal requirements. local air conditioner PAC 3500 X... - Page 23 Trotec GmbH & Co. KG Grebbener Str. 7 D-52525 Heinsberg +49 2452 962-400 +49 2452 962-200 info@trotec.com www.trotec.com...
