- Page 1 PAC 3550 PRO OPERATING MANUAL LOCAL AIR CONDITIONER...
-
Page 2: Table Of Contents
Information marked with this symbol helps you to carry out your tasks quickly and safely. Follow the manual Information marked with this symbol indicates that the operating manual must be observed. Operating manual – local air conditioner PAC 3550 PRO... -
Page 3: Safety
• Only transport the device in an upright position with an emptied condensation tank or drain hose. • Discharge the collected condensate before transport and storage. Do not drink it. Health hazard! Operating manual – local air conditioner PAC 3550 PRO... -
Page 4: Information About The Device
Do not operate the device without an inserted air filter! Without an air filter the inside of the device will be heavily contaminated, which could reduce the dehumidification performance and result in damage to the device. Operating manual – local air conditioner PAC 3550 PRO... - Page 5 Condensate outlet with sealing cap and rubber stopper Remote control Air hose (exhaust air hose and supply air hose) Air filter for air inlet Air filter for air inlet, lockable Flat nozzle, 2x Power cable holder Handle Operating manual – local air conditioner PAC 3550 PRO...
-
Page 6: Transport And Storage
• with a cover to protect it from invasive dust if necessary • Place no further devices or objects on top of the device to prevent it from being damaged. • Remote batteries from the remote control. Operating manual – local air conditioner PAC 3550 PRO... - Page 7 Without an air filter the inside of the device will be heavily contaminated, which could reduce the dehumidification performance and result in damage to the device. • Make sure that both air filters are installed before switching the device on. Operating manual – local air conditioner PAC 3550 PRO...
- Page 8 If the venting slots are open, please proceed as follows: 1. Slide the air inlet control knob (9) to closed position. ð The venting slots at the air inlet (8) are closed. Operating manual – local air conditioner PAC 3550 PRO...
- Page 9 • The dimensions of the exhaust air hose and supply air hose were especially made to fit the device. Do not replace or extend the air hoses, for it could cause a malfunction. Operating manual – local air conditioner PAC 3550 PRO...
-
Page 10: Operation
LOW = lowest stage Timer indication Illuminated when the timer is activated Operating mode Indicates the selected operating mode: indication AUTO = automatic mode COOL = cooling FAN = ventilation DRY = dehumidification Operating manual – local air conditioner PAC 3550 PRO... - Page 11 2. Select the desired fan stage by use of fan stage button (19). ð The respective stage HIGH/MID/LOW appears on the display and the respective stage F3/F2/F1 appears on the segment display (21). Operating manual – local air conditioner PAC 3550 PRO...
- Page 12 ð The displayed temperature is converted to the other unit. • Manually switching the device on disables the automatic switch-on function. • If you select 0 hours, the timer will be off. Operating manual – local air conditioner PAC 3550 PRO...
- Page 13 32 DRY mode indication Dry = dehumidification 33 Transmitter indication Indicates transmission to the device when the button is pressed 34 Remote control Communication between device and remote transmitter / receiver control Operating manual – local air conditioner PAC 3550 PRO...
-
Page 14: Errors And Faults
Trotec for repair. The device is loud or vibrates: • Check whether the device is set up in a stable and upright position. Operating manual – local air conditioner PAC 3550 PRO... -
Page 15: Error Codes
Once the coil temperature drops below 0 °C, the device will switch off. As soon as the coil temperature has increased to at least 8 °C, frost protection switches off and the device can be operated again. Operating manual – local air conditioner PAC 3550 PRO... -
Page 16: Maintenance
12. Date: ......Signature: ......Signature: ......Signature: ......Signature: ......13. Date: ......14. Date: ......15. Date: ......16. Date: ......Signature: ......Signature: ......Signature: ......Signature: ......Operating manual – local air conditioner PAC 3550 PRO... - Page 17 3. Allow the filter to dry completely. Do not insert a wet filter into the device! Operating manual – local air conditioner PAC 3550 PRO...
- Page 18 Check the rubber stopper for tight fit. 6. Screw the sealing cap onto the condensate outlet (10). ð The FL indication on the segment display (21) will go out as soon as the condensate has been drained. Operating manual – local air conditioner PAC 3550 PRO...
-
Page 19: Technical Annex
470 x 840 x 425 (mm) Minimum distance to walls and other objects: top (A): 50 cm rear (B): 50 cm sides (C): 50 cm front (D): 50 cm Wiring diagram Operating manual – local air conditioner PAC 3550 PRO... - Page 20 Spare parts drawing and list Note! The position numbers of the spare parts differ from those describing the positions of other parts mentioned in this operating manual. Operating manual – local air conditioner PAC 3550 PRO...
-
Page 21: Disposal
The device uses an environmentally and ozone-neutral cooling agent (see Technical Data). Dispose of the refrigerant appropriately and according to the national regulations. Operating manual – local air conditioner PAC 3550 PRO... - Page 24 Trotec GmbH & Co. KG Grebbener Str. 7 D-52525 Heinsberg +49 2452 962-400 +49 2452 962-200 info@trotec.com www.trotec.com...
