- Page 1 PAC 3500 E OPERATING MANUAL LOCAL AIR CONDITIONER...
-
Page 2: Table Of Contents
PAC 3500 E No liability is accepted for damages resulting from improper use. In such a case, any warranty claims be voided also. http://download.trotec.com/?sku=1210002103&id=1 Operating manual – local air conditioner PAC 3500 E... -
Page 3: Safety
• Only transport the device in an upright position with an emptied condensation tank or drain hose. • Discharge the collected condensate before transport and storage. Do not drink it. Health hazard! Operating manual – local air conditioner PAC 3500 E... -
Page 4: Information About The Device
Switch the device off and disconnect the power cable from the mains socket. Hold onto the mains plug while doing so. 2. Do not reconnect a defective device to the mains. Operating manual – local air conditioner PAC 3500 E... -
Page 5: Transport And Storage
Wait 12 - 24 hours before switching the device back on! Acting contrary might lead to compressor damage and a malfunctioning device. If so, any warranty claims will be voided. Operating manual – local air conditioner PAC 3500 E... -
Page 6: Assembly And Installation
• Keep air inlets and outlets as well as the exhaust air hose connection free. • Make sure that no curtains or other objects interfere with the air flow. Prior to initial start-up, insert the batteries in the remote control. Operating manual – local air conditioner PAC 3500 E... - Page 7 • The end of the exhaust air hose can also be hooked into a tilted bottom-hung window. For this purpose, we recommend using a window seal (optional). • Install the exhaust air hose inclined with the air direction. Operating manual – local air conditioner PAC 3500 E...
- Page 8 Do not replace or extend the hose, for it could cause a malfunction. Connecting the power cable • Insert the mains plug into a properly secured mains socket. Operating manual – local air conditioner PAC 3500 E...
-
Page 9: Operation
Display of timer condensate discharge. Display of error codes Automatic defrost Automatic defrost active indication TIMER indication Timer function active Operating manual – local air conditioner PAC 3500 E... - Page 10 ) appears on the display. 2. Press the FAN button (18) to set the desired fan speed. ð The selected fan speed (27) is displayed. ð The current room temperature is indicated on the segment display (29). Operating manual – local air conditioner PAC 3500 E...
- Page 11 ð The display changes back to the previous indication. ð The TIMER indication (31) appears on the display. ð The timer setting equals the desired number of hours. ð The device switches off after the set period of time. Operating manual – local air conditioner PAC 3500 E...
- Page 12 SWING button Adjusting the position of the ventilation flaps Transmitter indication Indicates transmission to the device when the button is pressed Remote control Communication between device and transmitter / receiver remote control Operating manual – local air conditioner PAC 3500 E...
-
Page 13: Errors And Faults
• The compressor has a built-in protective function. After switch-off, a restart of the compressor is delayed for 3 minutes. • In dehumidification mode, the compressor only starts at a room temperature of ≥ 15 °C. Operating manual – local air conditioner PAC 3500 E... -
Page 14: Maintenance
12. Date: ......Signature: ......Signature: ......Signature: ......Signature: ......13. Date: ......14. Date: ......15. Date: ......16. Date: ......Signature: ......Signature: ......Signature: ......Signature: ......Operating manual – local air conditioner PAC 3500 E... - Page 15 3. Allow the EVA air filter and the CON air filter to dry completely. Do NOT insert a wet filter into the device! 4. Reinsert the EVA air filter and the CON air filter into the device. Operating manual – local air conditioner PAC 3500 E...
- Page 16 • Reconnect the device to the mains. If you do not intend to use the device for a considerable time: • Store the device according to the Storage chapter. 5. Let the condensate run off completely. Operating manual – local air conditioner PAC 3500 E...
-
Page 17: Technical Annex
430 x 730 x 360 (mm) Minimum distance to walls and other objects: top (A): 50 cm rear (B): 50 cm sides (C): 50 cm front (D): 50 cm Wiring diagram Operating manual – local air conditioner PAC 3500 E... - Page 18 Spare parts drawing and list Note! The position numbers of the spare parts differ from those describing the positions of other parts mentioned in this operating manual. Operating manual – local air conditioner PAC 3500 E...
-
Page 19: Disposal
The device uses an environmentally and ozone-neutral cooling agent (see Technical Data). Dispose of the refrigerant appropriately and according to the national regulations. Operating manual – local air conditioner PAC 3500 E... - Page 20 Trotec GmbH & Co. KG Grebbener Str. 7 D-52525 Heinsberg +49 2452 962-400 +49 2452 962-200 info@trotec.com www.trotec.com...
