Introduction The scope of this Startup Guide is to detail the processes of receiving and installing the Keysight Streamline Series P937xA vector network analyzer (VNA) and cables that compose the P937xA VNA. Additionally, installing the required software and verifying P937xA vector network analyzer operation is documented. If you have any questions after reviewing this information, please contact your local Keysight Technologies Inc. -
Page 6: Inspect For Damage
1. Review the warranty information shipped with your product. 2. Contact Keysight to obtain a Return Material Authorization (RMA) and return address. For assistance finding Keysight contact information, go to www.keysight.com/find/assist (worldwide contact information for repair and service). -
Page 7: Step 2. Check The Shipment
External Power Supply Desktop adapter 90-264AC 15VDC 6A 90W 1950-6128 China RoHS Addendum for Network Analyzer 9320-6674 Keysight safety leaflet 9320-6797 Quick start guide P9370-90005 Cable-Assembly USB 3.0 Type-A Plug to Type-C Plug 1m-LG PVC P9375-60010 Black Keysight Technologies Startup Guide... -
Page 8: Step 3. Install The Software
Refer to the above table in “System Requirements”. Latch keys (x4) and Option Y1701A – For Multi-port Configuration of P937xA jumpers(x3)—(Optional) About Installing the P937xA Products affected All P937xA vector network analyzers Estimated installation time 2 hours Keysight Technologies Startup Guide... -
Page 9: Software Installation Overview
Option 2CD which includes an IO Library Suite CD. This software must be installed first. Ensure that Keysight IO Libraries Suite IOLS 2018 Update 1 or greater is loaded into your PC controller, before you connect and power up the P937xA. -
Page 10: Power Up The Instrument With A Pc
Power Up the Instrument with a PC IMPORTANT! Before connecting your P937xA to your PC, ensure that your PC has the Keysight IO Libraries Suite (IOLS 2018 Update 1 or greater) and the P937xA firmware loaded. If not, refer to “Software Installation... -
Page 11: Step 4. Install The P937Xa Network Analyzers
— Torque driver (for use with socket adapter), set to 8 lbf-in (0.91 N.m) - not supplied. — Cable removal tool (part number 5002-3361) - not supplied. — T10 torque driver, set to 9 lbf-in (1.02 N.m) – not supplied. Keysight Technologies Startup Guide 1-11... -
Page 12: Installation Procedure
Figure 1-5 on page 13, attached to the 8 lbf-in (0.91 N.m) torque driver. a. On the first P937xA, remove the 50 ohm load from the LO Out port. Leave the load installed on the LO In port. 1-12 Keysight Technologies Startup Guide... - Page 13 Repeat steps through for the rear latches and handles using latches P9375-20018 (x2) and 0515-0664 screws (x4) and f. Use a T10 torx torque driver to tighten front and rear handle screws to 9 lb-ins. Keysight Technologies Startup Guide 1-13...
- Page 14 Getting Started STEP 4. Install the P937xA Network Analyzers Figure 1-6 Assemble front latches and screws (0515-0375 screws (x8) P9375-20017 (x2)) 1-14 Keysight Technologies Startup Guide...
- Page 15 13, attached to an 8 lbf-in (0.91 N.m) torque driver. 9. Install a semi-rigid cable (P9375-20013), seen in Figure 1-8, between the LO In port and the LO Out port on each of the P937xA pairs (1 & 2). Keysight Technologies Startup Guide 1-15...
- Page 16 P9375-20013. And, use the (5002-3361) tool for P9735-20014, and NP9375-20015 SMB jumper cables. See Figure 1-9 on page Figure 1-9 Cable Removal Tool (part number 5002-3361) You have now completed the hardware installation procedure. 1-16 Keysight Technologies Startup Guide...
-
Page 17: Front Panel Features
Utility > System > Configure > External Reference. Ref Out SMB male connector. Outputs a 10 MHz frequency reference signal for use by other test equipment. Trig In SMB male connector. Inputs a signal to trigger the network analyzer P937xA. Keysight Technologies Startup Guide 1-17... - Page 18 Getting Started STEP 4. Install the P937xA Network Analyzers Trig Out SMB male connector. Outputs a signal either before or after a measurement. Trig Ready SMB male connector. Outputs a “READY’ signal to other devices. 1-18 Keysight Technologies Startup Guide...
- Page 19 The analyzer offers great flexibility in Trig 2 configuring the trigger function. P937xA has Trigger 1 and Trigger 2 connectors. See also, the VNA Online Help (http://www.keysight.com/find/usb-vna). Lock Kensington security lock Keysight Technologies Startup Guide 1-19...
-
Page 20: Step 5. Verify Operation Of The Network Analyzers
6. If shorts and opens are not connected to all ports, you will be prompted to connect them as they are needed. 7. The result of the operator’s check will be shown as a PASS or FAIL next to each test (refer to Figure 1-12 on page 1-20 Keysight Technologies Startup Guide... -
Page 21: If The Operator's Check Fails
If the Operator’s Check Fails 1. Clean the test ports, and the open(s) or short(s). Torque to specification. Repeat the check. 2. If the check still fails, return the network analyzer to Keysight. See “How to Return an Instrument for Service” on page... - Page 22 Getting Started STEP 5. Verify Operation of the Network Analyzers 1-22 Keysight Technologies Startup Guide...
-
Page 23: Getting Help With Your P937Xa Usb-Network Analyzer
The P937xA Network Analyzer System Web page is another resource for help with the analyzer P937xA. You can find all P937xA network analyzer documentation and other resources at: http://www.keysight.com/find/usb-vna Check for software updates at: http://www.keysight.com/technicalsupport/main. Enter the model for your instrument and click Find... -
Page 24: Contacting Keysight
Assistance with test and measurements needs and information on finding a local Keysight office are available on the Web at: www.keysight.com/find/assist. If you do not have access to the Internet, please contact your Keysight field engineer. In any correspondence or telephone conversation, refer to the Keysight product by its model number and full serial number. -
Page 25: Safety And Regulatory Information
Do not attempt to clean internally. Shipment for Service Contact Keysight Technologies for instructions on where to ship the analyzer P937xA for service. Refer to “Contacting Keysight” on page Ship the analyzer P937xA using the original packaging materials. Shipping the analyzer P937xA in anything other than the original packaging may result in non-warranted damage. -
Page 26: Safety Symbols
Denotes a hazard. It calls attention to a procedure which, if not correctly performed or adhered to, could result in injury or loss of life. Do not proceed beyond a warning note until the indicated conditions are fully understood and met. Keysight Technologies Startup Guide... -
Page 27: General Safety Considerations
P937xA exceeds the full temperature range, always allow it to cool before touching it or removing it from the chassis. This product is designed for use in Installation Category II and Pollution Degree 2 environment. Keysight Technologies Startup Guide... -
Page 28: Regulatory Information
Declaration of Conformity): — IEC/EN 61326-1 — CISPR Pub 11 Group 1, class A — AS/NZS CISPR 11 — ICES/NMB-001 This ISM device complies with Canadian ICES-001. Cet appareil ISM est conforme a la norme NMB-001 du Canada. Keysight Technologies Startup Guide... -
Page 29: Safety
Acoustic statement (European Machinery Directive) — Acoustic noise emission — LpA <70 dB — Operator position — Normal operation mode per ISO 7779 Complies with the following standard (dates and editions are cited in the Declaration of Conformity): IEC/EN 61010-1. Keysight Technologies Startup Guide... -
Page 30: Instrument Markings
This product complies with all relevant directives. The Keysight email address is required by EU directives applicable to our product. The CSA mark is a registered trademark of the CSA International. -
Page 31: For The Ac/Dc Adapter
To prevent electrical shock do not remove covers. Use only the designated AC/DC adapter supplied with the instrument. Use a Keysight supplied power cord that is the same or better electrical rating. Operated at an ambient temperature: 0 to 40°C. - Page 32 The AC/DC adapter is for indoor use only. Never use a modified or damaged charger. Use the original AC–DC adapter ONLY. The AC/DC adapter is designed for use in Installation Category II and Pollution Degree 2 per IEC 61010-1. Keysight Technologies Startup Guide...
- Page 33 Safety and Regulatory Information Regulatory Information Equipment Installation (AC/DC Adapter) Use a Keysight supplied power cord that is the same or better electrical rating. This instrument has auto-ranging line voltage input; be sure the supply voltage is within the specified range and that voltage fluctuations do not to exceed 10 percent of the nominal supply voltage.
-
Page 34: Declaration Of Conformity
Regulatory Information Declaration of Conformity A declaration of conformity is available upon request, or a copy is available on the Keysight Technologies Web site at http://www.keysight.com/go/conformity or by contacting Keysight - see “Contacting Keysight” on page 3-10 Keysight Technologies Startup Guide... -
Page 35: Equipment Ratings
The instruments can operate with mains supply voltage fluctuations up to ± 10% of the nominal voltage. Environmental Conditions (Operating) For indoor use only Altitude up to: 3000m (9,842.2 ft) Temperature: ◦ 0 to 55 Humidity: ◦ Type tested at 95% RH, +40 Keysight Technologies Startup Guide 3-11... -
Page 36: Space Requirements
The actual warranty on your instrument depends on the date it was ordered as well as whether or not any warranty options were purchased at that time. To determine the exact warranty on your instrument, contact Keysight Technologies with the model and serial number of your instrument. Refer to “Contacting Keysight”... - Page 37 Installation Note Xxxxx-xxxxx...
