Page 1: Measurement Instructions
Configuration and Measurement Instructions Keysight Technologies M9703A Hardware Extension of 89600 VSA Software Notice: This document contains references to Agilent. Please note that Agilent’s Test and Measurement busi- ness has become Keysight Technologies. For more information, go to www.keysight.com. -
Page 2: Safety Notices
Notices COVERING THE MATERIAL IN THIS specifically in writing elsewhere in the DOCUMENT THAT CONFLICT WITH THESE EULA. Keysight shall be under no obligation TERMS, THE WARRANTY TERMS IN THE to update, revise or otherwise modify the Copyright Notice SEPARATE AGREEMENT SHALL CONTROL. - Page 3 Keysight products are designed for use safety procedures and proper use. with electrical signals that are rated use of the instrument.
- Page 4 To return unwanted products, of the product). If you are unsure about the contact your local Keysight office, or for applicability of a replacement component, more information see call an Keysight office for information.
- Page 5 Keysight M9703A Hardware Extension of 89600 VSA Soft- ware The 89601B: 89600 VSA software supports the Keysight M9703A AXIe High-Speed Digitizer. This VSA measurement hardware configuration offers broadband vector sig- nal analyzer measurements up to 625 MHz of analysis bandwidth (model dependent).
- Page 6 Keysight M9703A Hardware Extension of 89600 VSA Software d. In the box below ensure that M9703A appears as the 'ADC' entry, and if you have more than one M9703A connected - select the required unit using the drop-down list. e. You may either use the default name or specify another name for this analyzer configuration.
-
Page 7: Multi-Channel Measurements
Keysight M9703A Hardware Extension of 89600 VSA Software Multi-Channel Measurements When using the M9703A digitizer in VSA configuration, the digitizer forms the meas- urement front-end data acquisition hardware for the 89600 VSA software. The M9703A digitizer supports single channel I+jQ, multi-channel Dual I + jQ, and cross channel measurement configurations. -
Page 8: External Clock
Keysight M9703A Hardware Extension of 89600 VSA Software External Clock The option of using an external sampling clock is provided. This clock must be con- tinuously present if the mode is selected otherwise an error will occur. The range of... - Page 9 Keysight M9703A Hardware Extension of 89600 VSA Software Force Software DDC This function overrides the hardware processing which is normally performed by the M9703A, and forces the VSA software to perform the DDC operation. It is provided simply as a demonstration of the difference in performance between hardware DDC and software.
- Page 10 Measurement Setup Parameters Measurement Setup Parameters This section provides measurement and parameter setup information which are spe- cific to the 89600 VSA software when used along with the M9703A AXIe High-Speed Digitizer. This information will help you to properly setup the VSA in this hardware con- figuration to make measurements using the M9703A digitizer.
- Page 11 Measurement Setup Parameters Range: The M9703A digitizer has two range settings: 2 V (10 dBm) and 1 V (4 dBm). Coupling: DC Input Impedance: 50 Ohms. Connection: Single Ended. The frequency measurement parameters may be configured from the MeasSetup > Frequency menu.
- Page 12 Measurement Setup Parameters Trigger Type Level Default External -5 V to +5 V 2V Magnitude** 0 to 1.414 V 10 mV M9703A Hardware Extension of 89600 VSA Software...
- Page 13 Measurement Setup Parameters Trigger delays: Max Post- Trigger Max Pre-Trigger Delay Trigger Type Delay External VSA increases the record size to make the 1 second pre-trigger delay fit (limited by the amount acquisition memory available). Magnitude** –137 samples * sampling Interval 1 second *On "Segmented Capture"...
